1994 Lamborghini Diablo VT USA Gearbox Control Tower (24.01.00)

Maintenance Parts:

Belts

PN	Item	Diagram
001736517	Coolant Pump Alternator Belt (From SE VIN 12043) Coolant Pump Alternator Belt		Avail to order Our Price: $323.81
004534071	Compressor Belt Compressor Belt		Avail to order Our Price: $142.47

Brakes

PN	Item
003334931	NLA (No Longer Available) E-Brake Pad	Avail to order Our Price: $399.82
003236088	Brake Pad Kit Rear - Diablo Brake Pad Kit Rear - Diablo - Full Set for Rear	Avail to order Our Price: $732.75
003136085	Brake Pad Kit Front - Diablo Diablo Brake Pad Kit	Avail to order Our Price: $1,204.66

Common repairs and upgrades

PN	Item
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO	Current Stock: 2 Our Price: $22.58
0079004387	SHOCK ABSORBER SHOCK ABSORBER FOR ANTERIOR COWLING	Current Stock: 2 Our Price: $139.79
006329689	HIGH BEAM HEADLIGHT HIGH BEAM HEADLIGHT	Avail to order Our Price: $535.96
0092004388	shock absorber for engine cowling shock absorber for engine cowling	Current Stock: 4 Our Price: $253.09

Drivetrain

PN	Item
002132599	CLUTCH PRESSURE PLATE - DIABLO CLUTCH PLATE - NLA (No Longer AVAILABLE) FROM FACTORY. PLEASE CHECK WITH US FOR ALTERNATIVES - ABOUT 2 WEEK LEAD TIME	Avail to order Our Price: $1,850.00
001505914	Oil Filter - Diablo - LM002 - Countach - Urraco - Jalpa Oil Cartridge. Note: these are ordered directly from the factory. Brand/Model/Color may differ from the picture. We have no control as to what is sent when they are ordered.	Current Stock: 21 Our Price: $86.65
002129353	THRUST SLEEVE THRUST SLEEVE - NLA (No Longer AVAILABLE) FROM FACTORY. PLEASE CHECK WITH US FOR ALTERNATIVES	Avail to order Our Price: $1,630.19
002132598	Clutch Mechanism - Early Diablo Clutch Mechanism	Avail to order Our Price: $1,674.86
002136948	Slave Clutch Cylinder Diablo / Countach Slave Clutch Cylinder	Current Stock: 5 Our Price: $134.59
004219984	Master Clutch Cylinder Clutch Cylinder Control Assembly	Avail to order Our Price: $350.78
0017002473	WATER PUMP (2WD W/O POWER STEARING) (1991-1994) WATER PUMP (2WD W/O POWER STEARING) (1991-1994)	Avail to order Our Price: $5,306.12
0017002474	Water Pump (2WD With Power Steering) (1991-1994) Coolant Pump 2WD With	Current Stock: 1 Our Price: $6,101.30
0R1320001	NLA (No Longer Available) SPEED SENSOR KIT	Avail to order Our Price: $940.84
002132599K	1991 - 1994 Diablo Clutch Disk - KEVLAR HI-PERF 1991 - 1994 Diablo Clutch Disk - KEVLAR HI-PERF - Clutchtex - TZ-3022 T3	Avail to order Our Price: $900.97
07M115561B	SPIN-ON FILTER CARTUCCIS FIL.OLIO SPIN-ON FILTER CARTUCCIS FIL.OLIO	Current Stock: 3 Our Price: $104.15

Fuel-Air

PN	Item
AMAIRD	Hi-Performance aFe Air Filter - Diablo/Murcielago - SPORT Air Filter Murcielago - Diablo After Market aFe Air Filter 30-10133	Current Stock: 1 Our Price: $145.65
400201511A	Fuel Filter - Diablo - Gallardo - Murcielago FUEL FILTER	Current Stock: 10 Our Price: $293.29
07M133843	Air Filter - LM002, Countach, Diablo, Murcielago Please Check your Part Manual for a Description For performance filters see PN: 07M133843A	Avail to order Our Price: $31.69
002024398	Fuel Pump Fuel Pump	Current Stock: 6 Our Price: $762.25
002024396	FUEL INJECTOR (Sold Ea) Manifold Upper CoverInjector	Avail to order Our Price: $405.53
07M133843A	Air Filter - SPORT PERFORMANCE FILTER Performance filter replacement for 07M133843 Air Filter - Murcielago SV LP 670-4	Avail to order Our Price: $782.61
07M133843KN	K&N Air Filter - LM002, Countach, Diablo, Murcielago K&N's replacement air filters are designed to increase horsepower and acceleration while providing excellent filtration. These filters are washable and reusable and are custom designed to fit into your existing factory air box. Their drop-in design means adding performance is simple.	Avail to order Our Price: $70.48

Fuses-Bulbs-Relays

PN	Item
006311155	Relay Relay	Avail to order Our Price: $67.32
006329694	Bulb Headlight Bulb headlight	Avail to order Our Price: $63.82
006329695	BULB FOR FOGLIGHT BULB FOR FOGLIGHT	Current Stock: 1 Our Price: $19.36
006329696	Bulb 5w Front Turn Signal 5w Bulb front turn signal	Current Stock: 6 Our Price: $3.35
N0177522	bulb Headlight LAMP 12V/3W	Current Stock: 10 Our Price: $2.17
006617094	LAMP BA 15S 21W Bulb LAMP BA 15S 21W Used in various lamps (depending on your year and model)	Current Stock: 76 Our Price: $9.90
006617091	Bulb 21w tail light 21w Bulb	Current Stock: 4 Our Price: $13.56
006617095	Bulb for license plate lamp Bulb LAMP SV8,5-8 5W	Current Stock: 42 Our Price: $11.09
006030676	Light Relay Light Relay	Current Stock: 3 Our Price: $184.13
006329698	Bulb Bulb	Avail to order Our Price: $9.02
410947413	RED DOOR LIGHT RED DOOR LIGHT - NLA (No Longer Available) TO ORDER FROM FACTORY PLEASE CONTACT US FOR OTHER OPTIONS.	Avail to order Our Price: $92.91

Gaskets

PN	Item
001535288	Grommet and Oil Seals Set - Diablo VT / SV / Roadster Grommet and Oil Seals Set - Diablo VT / SV / Roadster	Avail to order Our Price: $301.73
001535287	Engine Gasket Set Diablo VT / SV / Roadster DOES NOT INCLUDE VALVE GUIDES PN 07M109675 Diablo VT Gasket Kit See PN 1535288 for the Grommet and oil seal set	Avail to order Our Price: $2,489.56
0R1320002	Diablo REAR Differential Seal Kit Dif Seal Kit	Current Stock: 1 Our Price: $48.53
0015002552	Engine Gasket Set - Diablo VT 1998 See PN 0015002553 for the Grommet and oil seal set	Avail to order Our Price: $1,924.77

Ignition

PN	Item
DiabloWireSet	Spark Plug Wires 1991-1995 Diablo - Aftermarket Spark Plug Wires 1991 through 1995 ONLY for systems using a Distributor cap	Avail to order Our Price: $820.50
001630289	Spark Plug - Diablo Spark Plug	Current Stock: 50 Our Price: $32.83
006134023	SPARK PLUG WIRES Spark Plug Wires ONLY for systems using distributor cap. NLA FROM FACTORY CONTACT US FOR CURRENT PRICING AND AVAILABILITY Depending on production year may require different set: SEE PN: 006134279 & 001134281	Avail to order Our Price: $743.20
001627730	DIABLO IGNITION ROTOR DIABLO IGNITION ROTOR - NLA for FACTORY we have exact OE Replacement	Current Stock: 2 Our Price: $289.00
001630792N	Coil pack OE SPEC REPLACEMENT Coil pack OE SPEC REPLACEMENT	Avail to order Our Price: $1,957.58

Misc

PN	Item
009420126	WINDSHIELD WIPER BLADE WINDSHIELD WIPER BLADE	Avail to order Our Price: $36.40
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month	Avail to order Our Price: $373.98
0R0000149	CLEANER FLUID 250ml CLEANER FLUID	Current Stock: 1 Our Price: $70.78
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut	Avail to order Our Price: $1.94

Sensors

PN	Item
001327641	Potentiometer TPS Throttle Position Sensor Diablos Potentiometer	Avail to order Our Price: $199.79
004526663	Cabin Air Temperature Sensor Temperature Sensor	Avail to order Our Price: $1,965.17
001536755	OIL TEMPERATURE THERMOSTAT OIL TEMPERATURE THERMOSTAT - also used on Diablo 91-93 2wd and 94	Current Stock: 1 Our Price: $544.18
07L919501A	Water Temperature Sensor Water Temperature Sensor	Current Stock: 3 Our Price: $375.18
0017006576	THERMOSTAT FOR DIABLO WATER THERMOSTAT - -NLA (No Longer Available) DIRECT FROM LAMBORGHINI CONTACT US TO VERIFY AVAILABILITY FROM OTHER SOURCES	Current Stock: 3 Our Price: $295.00
07M905381	Phase Sensor Phase Sensor	Avail to order Our Price: $697.09
002408637	REVERSE SWITCH REVERSE SWITCH	Avail to order Our Price: $136.52
001724565	Fan Motor Thermal Contact Fan Motor Thermal Contact	Avail to order Our Price: $244.50
0R1470226	Lambda (O2 Oxygen) Sensor - DIABLO - EARLY MURCIELAGO Lambda (O2 Oxygen) Sensor - DIABLO - EARLY MURCIELAGO	Current Stock: 4 Our Price: $393.04

Tools and Tookits

PN	Item	Diagram
004129973	DIABLO FRONT TOW HITCH ASSEMBLY DIABLO FRONT TOW HITCH ASSEMBLY		Avail to order Our Price: $1,525.98

Open All

Select Group and TAV

< Previous Next >

TAV: 24.01.00 - Gearbox Control Tower

1994 Lamborghini Diablo VT USA Gearbox Control Tower (24.01.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Diablo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	002433043	NLA (No Longer Available)	1 req	*See Description
2	002434091	Gear Lever Ball Seat	1 req	Avail to order Our Price: $281.04
3	002427202	Gear Lever Cylinder	1 req	Avail to order Our Price: $99.15
4	002432167	Gear Lever Cylinder Spring	1 req	Current Stock: 1 Our Price: $14.17
5	002427204	Retainer	1 req	Current Stock: 8 Our Price: $12.01
6	008572201	O-Ring I 22 Uni 3654	1 req	Current Stock: 4 Our Price: $2.00
7	002433020	Camshaft Sliding Bush	2 req	Current Stock: 4 Our Price: $35.83
8	002433008	Gear Lever	1 req	Avail to order Our Price: $1,565.46
9	008700646	Screw M6x12 Uni 5931/8g/Zd	4 req	Current Stock: 10 Our Price: $2.00
10	WHT001197A	WASHER	4 req	Current Stock: 2 Our Price: $2.00
11	002429160	GEAR LEVER SPRING	1 req	Avail to order Our Price: $170.93
12	002427207	Gear Lever Bushing	1 req	Avail to order Our Price: $375.72
13	002429161	Gear Lever Shaft	1 req	Avail to order Our Price: $355.59
14	008900305	Door handle cable Pin	1 req	Current Stock: 10 Our Price: $2.00
15	410711615	JOINT WITH RH THREAD	1 req	Avail to order Our Price: $1,162.72
16	002432117	CV Joint Sheath	1 req	Avail to order Our Price: $77.24
17	WHT003615	M12x1.25 Uni 5589 Nut	1 req	Current Stock: 17 Our Price: $2.00
18	002434472	Gearbox Tierod	1 req	Avail to order Our Price: $45.55
19	WHT003616	M12x1.25 Sin. 8g Nut	1 req	Avail to order Our Price: $9.16
20	006133761	Reverse Switch/Odometer Impuls	1 req	Avail to order Our Price: $110.48
21	002408637	REVERSE SWITCH	1 req	Avail to order Our Price: $136.52
22	WHT002961	WASHER	8 req	Current Stock: 38 Our Price: $2.00
23	008410603	Washer D.6.4 Uni 1751/Zd	4 req	Avail to order Our Price: $2.00
24	008300624	Stud M6x12 Uni 5914 8g Zd	4 req	Avail to order Our Price: $17.25
25	N01100637	HEX.NUT	4 req	Current Stock: 18 Our Price: $2.00
26	002432932	Gear Lever Knob Adapter	1 req	Avail to order Our Price: $90.65
27	240132003	Gearbox Lever Complete	1 req	Avail to order Our Price: $1,908.36
28	WHT000771	SPRING LOCK WASHER	4 req	Current Stock: 10 Our Price: $2.00
29	008700804	Screw 8x1.5x25 5931 8g Zg	4 req	Avail to order Our Price: $2.00
30	002433874	Gear Lever Selector	1 req	Current Stock: 3 Our Price: $1,302.01
31	008740613	Stainless Steel Screw M6x1x14	2 req	Current Stock: 4 Our Price: $2.00
32	410711267	Seal Aerostop/Fa Cn/20	1 req	Avail to order Our Price: $38.49
33	002428311	Gear Lever Knob	1 req	Avail to order Our Price: $795.18
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
