TAV: 12.02.00 - Timing System

1994 Lamborghini Diablo VT USA Timing System (12.02.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Diablo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	07M109225	Idle Gear Pins	2 req	Avail to order 1 Used Available Our Price: $1,412.83
2	WHT003068	SCREW	2 req	Current Stock: 8 Our Price: $2.00
3	008900203	Elastic Pin 2.5x5 Din 1481	2 req	Avail to order Our Price: $2.00
4	07M109229	LOWER TIMING CHAIN	1 req	Avail to order Our Price: $151.12
5	07M109201	Lower Chain Fixed Guide	1 req	Avail to order Our Price: $77.72
6	07M109569	TIMING IDLE GEAR	2 req	Avail to order 2 Used Available Our Price: $1,838.63
7	008400806	Washer 15x8x1.5 Uni 1750 R40/Z	2 req	Current Stock: 5 Our Price: $2.00
8	008410820	Snap Ring D.8 Din 7980	2 req	Current Stock: 50 Our Price: $2.00
9	WHT003072	Cylinder Head Screw	2 req	Avail to order Our Price: $6.48
10	410109403	Code 30022000450	4 req	Avail to order Our Price: $421.33
11	07M109135	Roller Shim	2 req	Avail to order Our Price: $232.99
12	001231173	Shim Adjustment Washer	2 req	Avail to order Our Price: $39.44
13	008581801	O-Ring E 20 Uni 7435-75	2 req	Current Stock: 18 Our Price: $2.00
14	N01100637	HEX.NUT	2 req	Current Stock: 18 Our Price: $2.00
15	008410612	Snap Ring D.6 Din 7980	2 req	Avail to order Our Price: $2.00
16	008300660	Stud M6x1x40uni5914 8g/Zd	2 req	Avail to order Our Price: $14.87
17	07M109077A	SPROCKET	1 req	Avail to order Our Price: $876.88
18	001232196	Timing Drive Gear	1 req	Avail to order Our Price: $169.23
19	WHT003071	Screw M8x35 Uni 59318g/B	2 req	Avail to order Our Price: $7.37
20	008410820	Snap Ring D.8 Din 7980	2 req	Current Stock: 50 Our Price: $2.00
21	008400806	Washer 15x8x1.5 Uni 1750 R40/Z	2 req	Current Stock: 5 Our Price: $2.00
22	07M109203	Lower Chain Fixed Guide	1 req	Avail to order Our Price: $2,181.04
23	N01152427	WASHER	2 req	Current Stock: 16 Our Price: $2.00
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
