1984 Countach 5000s - USA

Group :

Tav :

Maintenance Parts:

Belts

PN	Item	Diagram
001613915	ALTERNATOR DRIVE BELT ALTERNATOR DRIVE BELT - NLA FROM LAMBORGHINI WAREHOUSE - SECONDARY SOURCE		Avail to order Our Price: $661.42

Brakes

PN	Item	Diagram
003113912	BRAKE PAD BRAKE PAD SET NLA FROM LAMBORGHINI WAREHOUSE - SECONDARY SOURCE		Avail to order Our Price: $48.23

Common repairs and upgrades

PN	Item
007021195	SHOCK ABSORBER COUNTACH DOOR SHOCK ABSORBER WITHOUT INTERNAL PARTS YOU MAY ALSO NEED N02214812 X1 HEX.HEAD 007021193 X1 SHOCK ABSOR.FIX.PIN TO DO 007021208 X1 SHOCK ABSORBER SECURPIN A 008580801 X1 O-RING E 8 UNI 7535-75 N01118410 X1 HEX.HEAD CLAMPING NUT WHT002962 X3 WASHER	Current Stock: 7 Our Price: $126.61
007029005	BONNET LIFTER BONNET LIFTER	Current Stock: 4 Our Price: $114.94
007029006	TRUNK LIFTER STRUT TRUNK LIFTER WITH STAB.	Current Stock: 4 Our Price: $89.17
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO	Current Stock: 2 Our Price: $22.48

Drivetrain

PN	Item
002109862	CLUTCH PLATE CLUTCH PLATE	Current Stock: 2 Our Price: $1,431.28
002109861	NLA (NO LONGER AVAILABLE) ENGINE FLYWHEEL	Avail to order Our Price: $3,123.45
002109864	THRUST BEARING THRUST BEARING	Avail to order Our Price: $7,551.46
001501188	OIL FILTER - MIURA COUNTACH ESPADA JARAMA OIL FILTER CARTRIDGE	Current Stock: 5 Our Price: $48.08

Fuel-Air

PN	Item
001320172	AIR FILTER - CARBURETED AIR FILTER EARLY COUNTACH, MIURA, JARAMA, ESPADA SEE PN 001320172KN FOR PERFORMANCE FILTER OPTION	Avail to order Our Price: $502.34
002021140	WARM UP REGULATOR / HEAT REGULATOR WARM UP REGULATOR / HEAT REGULATOR	Avail to order Our Price: $1,729.41
002021146	COLD START INJECTOR STARTER INJECTOR	Current Stock: 4 Our Price: $350.83
002021170	COUNTACH FUEL DISTRIBUTOR FUEL DISTRIBUTOR 0438100106 (043 8100 106)	Avail to order Our Price: $5,811.46
002021172	FREQUENCY VALVE FREQUENCY VALVE BOSCH 0280150300 (028 0150 300)	Avail to order Our Price: $872.46
002021173	FUEL DAMPERS FUEL DAMPERS	Avail to order Our Price: $518.87
002021174	COUNTACH INJECTION EFI ECU ECU	Avail to order Our Price: $4,741.13
001320172KN	PERFORMANCE FILTER FOR COUNTACH/ESPADA/JARAMA/MIURA HIGH FLOW PERFORMANCE FILTER.	Current Stock: 1 Our Price: $130.02
001501128	OIL FILTER SEAL OIL FILTER SEAL	Current Stock: 3 Our Price: $22.01
002021141	COUNTACH EFI FUEL INJECTION PUMP FUEL PUMP	Avail to order Our Price: $799.00
002021142B	FUEL FILTER - COUNTACH - FOR FUEL INJECTED EFI THIS IS THE ORIGINAL AND SAME FUEL FILTER USED ON ALL COUNTACH EFI SYSTEMS. IT HAS A DIFFERENT PART NUMBER, IN ORDER TO QUE THE ORDER FROM ANOTHER VENDOR RATHER THAN THE FACTORY. WE WOULD BE MORE THAN HAPPY TO GET IT FROM ITALY, BUT IT WILL BE THE SAME PUMP AND MUCH MORE EXPENSIVE. AS OF 1-3-2024 DOESN'T SHOW AVAILABILITY	Avail to order Our Price: $38.79
002021145	ACCUMULATOR ACCUMULATORS	Current Stock: 1 Our Price: $642.13
002021147	FUEL INJECTOR FOR COUNTACH FUEL INJECTOR FOR COUNTACH	Current Stock: 11 Our Price: $318.36
002021173b	FUEL DAMPERS - FOR FUEL INJECTED EFI THIS IS THE ORIGINAL AND SAME FUEL REGULATOR USED ON ALL COUNTACH EFI SYSTEMS. IT HAS A DIFFERENT PART NUMBER, IN ORDER TO QUE THE ORDER FROM ANOTHER VENDOR RATHER THAN THE FACTORY. WE WOULD BE MORE THAN HAPPY TO GET IT FROM ITALY, BUT IT WILL BE THE SAME PUMP AND MUCH MORE EXPENSIVE.	Avail to order Our Price: $339.85
002021176	LAMBDA O2 SENSOR LAMBDA SENSOR *MAY NEED TO USE YOUR EXISTING CONNECTOR	Current Stock: 4 Our Price: $863.20
002021176OE	LAMBDA SENSORS LAMDA SENSORS	Current Stock: 2 Our Price: $126.18
07M133843A	AIR FILTER - SPORT PERFORMANCE FILTER PERFORMANCE FILTER REPLACEMENT FOR 07M133843 AIR FILTER - MURCIELAGO SV LP 670-4	Avail to order Our Price: $782.63
07M133843KN	K&N AIR FILTER - LM002, COUNTACH, DIABLO, MURCIELAGO K&N'S REPLACEMENT AIR FILTERS ARE DESIGNED TO INCREASE HORSEPOWER AND ACCELERATION WHILE PROVIDING EXCELLENT FILTRATION. THESE FILTERS ARE WASHABLE AND REUSABLE AND ARE CUSTOM DESIGNED TO FIT INTO YOUR EXISTING FACTORY AIR BOX. THEIR DROP-IN DESIGN MEANS ADDING PERFORMANCE IS SIMPLE.	Avail to order Our Price: $70.48
980200016	ADDITIVO X CARB.G 001 700 03 ADDITIVO X CARB.G 001 700 03	Current Stock: 1 Our Price: $16.01

Fuses-Bulbs-Relays

PN	Item
006617091	BULB 21W TAIL LIGHT 21W BULB	Current Stock: 4 Our Price: $13.59
006617094	LAMP BA 15S 21W BULB LAMP BA 15S 21W USED IN VARIOUS LAMPS (DEPENDING ON YOUR YEAR AND MODEL)	Current Stock: 76 Our Price: $9.90
006309758	CYLINDER BULB 6411/12V 10W CYLINDER BULB 6411/12V 10W	Avail to order Our Price: $11.86
006311154	RELAY RELAY	Avail to order Our Price: $56.11
006617093	12V 5W BULB 12V 5W BULB	Avail to order Our Price: $20.28
N0177522	BULB HEADLIGHT LAMP 12V/3W	Current Stock: 10 Our Price: $2.14
006617103	3W BULB 3W BULB	Avail to order Our Price: $7.18

Gaskets

PN	Item
001526469	GROMMET AND OIL SEALS SET - COUNTACH QUATRO 5000 CARBURETED GROMMET AND OIL SEALS SET COUNTACH QUATRO 5000 CARBURETED	Avail to order Our Price: $156.07
001526489	ENGINE GASKET SET - COUNTACH QUATRO 5000 CARBURETED ENGINE GASKET KIT - COUNTACH QUATRO 5000 CARBURETED SEE PN 001526469 FOR SEALS	Avail to order Our Price: $2,229.43
001526468	COUNTACH 5000S GROMMET & OIL SEALS SET - EURO GROMMET & OIL SEALS SET	Avail to order Our Price: $148.22
001526470	COUNTACH 5000 USA - GROMMET & OIL SEALS SET GROMMET & OIL SEALS SET	Avail to order Our Price: $112.60
001526488	COUNTACH 5000 ENGINE GASKET KIT ENGINE GASKET KIT SEE PN 001526468 FOR SEALS KIT	Avail to order Our Price: $1,358.52
001526490	COUNTACH 5000 USA - ENGINE GASKET KIT ENGINE GASKET KIT SEE PN 001526470 FOR SEALS KIT	Avail to order Our Price: $1,186.06

Ignition

PN	Item	Diagram
008811403	SPARK PLUG - COUNTACH-JALPA SPARK PLUG		Current Stock: 16 Our Price: $39.99
001611403	COUNTACH WIRING HARNESS COUNTACH WIRING HARNESS		Avail to order Our Price: $2,876.02

Misc

PN	Item
006111300	LONG WIPER BLADE LONG WIPER BLADE	Current Stock: 1 Our Price: $54.16
006128790	WIPER SHORT BLADE 13 INCH WIPER SHORT BLADE (PREVIOUS PN 006111019)	Current Stock: 2 Our Price: $20.13
008200605R	OE SPEC ALTERNATIVE FOR 008200605 M6 NCM 70 URAMA SIMMON NUT	Avail to order Our Price: $1.94
0R0000149	CLEANER FLUID 250ML CLEANER FLUID	Current Stock: 1 Our Price: $70.78
400093050D	CTEK US-CD BATTERY CHARGER INPUT 110-120VAC OUTPUT MAX 4.3A, 12V BACK DRAIN LESS THAN 1.5AM/MONTH	Avail to order Our Price: $373.98

Sensors

PN	Item
002409895	REVERSE SWITCH REVERSE SWITCH NLA FROM FACTORY PLEASR CONTACT US FOR CURRENT PRICE AND AVAILABILITY	Avail to order Our Price: $127.96
001801333	OIL & COOLANT TEMPERATURE THERMOMETER OIL & COOLANT TEMPERATURE THERMOMETER NLA FROM FACTORY. CONTACT US FOR CURRENT AVAILABILITY	Avail to order Our Price: $150.16
001719309	URRACO THERMOSTAT COOLANT THERMOSTAT	Current Stock: 2 Our Price: $195.00
001724565	FAN MOTOR THERMAL CONTACT FAN MOTOR THERMAL CONTACT	Avail to order Our Price: $244.48
002021143	THERMOSTAT SWITCH - EFI COUNTACH ONLY ORIGINAL OEM THERMOSTAT SWITCH - INTERR.TERM.0.280.130.214	Current Stock: 3 Our Price: $872.46
006019052	OIL TEMPERATURE GAUGE OIL TEMPERATURE GAUGE	Avail to order Our Price: $647.04
7PP907275F	WHEEL ELECTRONICS WHEEL ELECTRONICS	Avail to order Our Price: $177.89

Tools and Tookits

PN	Item	Diagram
wheeltool	WHEEL INSTALL TOOL SCREWS INTO HUB FOR EASY INSTALLATION.		Current Stock: 95 Our Price: $19.42

Open All

Select Group and TAV

< Previous Next >

TAV: 40 - Glass, Gaskets and Controls

1984 Lamborghini Countach 5000s USA Glass, Gaskets and Controls (40)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Countach Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	006102515	EMBLEM BONNET SHIELD BADGE	1 req	Current Stock: 5 Our Price: $1,018.16
2	006119922	EMBLEM COUNTACH 5000 BRASS PLATE	1 req	Avail to order Our Price: $70.50
3	007015001	This item is no longer available	1 req
4	006106008	EMBLEM S FOR MIURA	1 req	Current Stock: 1 Our Price: $362.65
5	007090074	This item is no longer available	1 req
6	007018001	PASSEMBLYCOMP. LOWERREARWINDOW	1 req	Avail to order Our Price: $651.51
7	007090084	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
8	007090086	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	2 req	*See Description
9	007059027	GAS SHOCK ABSORB. PIN	1 req	Current Stock: 6 Our Price: $145.67
10	007090071	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	2 req	*See Description
11	007059027	GAS SHOCK ABSORB. PIN	4 req	Current Stock: 6 Our Price: $145.67
12	WHT001197A	WASHER	4 req	Current Stock: 2 Our Price: $0.30
13	N01118312	HEX.HEAD CLAMPING NUT	4 req	Avail to order Our Price: $2.14
14	007060005	ENGINE COVER BUMPER	1 req	Avail to order Our Price: $83.63
15	006111397	EMBLEM LAMBORGHINI SCRIPT IN BLACK	1 req	Current Stock: 2 Our Price: $323.29
16	006111345	EMBLEM MATTE BLACK COUNTACH SCRIPT	1 req	Current Stock: 1 Our Price: $310.69
17	006111447	EMBLEM DESIGNO BERTONE	1 req	Current Stock: 7 Our Price: $579.94
18	007059063	BONNET LOCK	3 req	Avail to order Our Price: $327.75
19	007029006	TRUNK LIFTER STRUT	1 req	Current Stock: 4 Our Price: $89.17
19	007029005	BONNET LIFTER	1 req	Current Stock: 4 Our Price: $114.94
20	007090088	FRONT BONNET SEAL	1 req	Avail to order Our Price: $209.06
21	007015002	SEE PN: 7015018 AND 7015019	1 req	Avail to order Our Price: $396.74
22	007090080	NLA (NO LONGER AVAILABLE)	2 req	*See Description
23	007059012	BONNET CABLE FIX.WASHER	3 req	Avail to order Our Price: $24.41
24	006959298	BONNET LOCK CABLE FIX.PIN	3 req	Avail to order Our Price: $35.01
25	007059015	FR BONNET AND ENGINECABLE	3 req	Avail to order Our Price: $140.18
26	007059017	BONNET CABLE	3 req	Avail to order Our Price: $140.18
27	007021110	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	2 req	*See Description
28	007021108	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	2 req	*See Description
29	007021112	NLA (NO LONGER AVAILABLE)	2 req	*See Description
30	006405010	FRONT BONNET HANDLE	1 req	Avail to order Our Price: $114.26
31	007021013	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
31	007021012	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
32	007021195	SHOCK ABSORBER COUNTACH DOOR	2 req	Current Stock: 7 Our Price: $126.61
33	007090073	COUNTACH LOWER BOTTOM DOOR SEAL - 190 CM	2 req	Current Stock: 2 Our Price: $93.64
34	007017014	NLA (NO LONGER AVAILABLE)	2 req	*See Description
35	007021148	This item is no longer available	2 req
36	007021134	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	2 req	*See Description
37	007021092	WINDOW FRAME MOLDING RIGHT	1 req	Avail to order Our Price: $690.31
37	007021093	WINDOW FRAME MOLDING LEFT	1 req	Avail to order Our Price: $690.31
38	007021035	WINDOW LIFT.CABLE PLATE	6 req	Avail to order Our Price: $86.74
39	008100506	SCREW M5X14 UNI 5739	12 req	Avail to order Our Price: $11.96
40	007021041	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	2 req	*See Description
41	007017006	NLA (NO LONGER AVAILABLE)	1 req	*See Description
41	007017005	NLA (NO LONGER AVAILABLE)	1 req	*See Description
42	007021007	MOVABLE	4 req	Current Stock: 1 Our Price: $64.85
43	007017004	RH UPPER GLASS	1 req	Avail to order Our Price: $1,218.13
43	007017003	LH UPPER GLASS	1 req	Avail to order Our Price: $1,218.13
44	007017007	RL SIDE BUTT.WINDOW	1 req	Avail to order Our Price: $547.17
44	007017008	RR SIDE BUTT.WINDOW	1 req	Avail to order Our Price: $547.17
45	006111688	INNER RADIATOR AIR INTAKE GRIL	1 req	Avail to order Our Price: $863.20
46	006111684	RADIATOR AIR OUTLET GRILLE	1 req	Avail to order Our Price: $1,125.65
47	006111686	LH UPPER AIR INTAKE GRILLE	1 req	Avail to order Our Price: $1,200.23
47	006111687	This item is no longer available	1 req
48	007059013	ENGINE COVER CABLE	2 req	Avail to order Our Price: $128.45
49	007059014	This item is no longer available	1 req
50	007059017	BONNET CABLE	1 req	Avail to order Our Price: $140.18
51	007059018	TRUNK SEC. CABLE SHEATH	1 req	Avail to order Our Price: $43.37
52	007059019	NLA (NO LONGER AVAILABLE)	1 req	*See Description
53	007059020	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
54	007021002	STRIKER FIX.PLATE	2 req	Avail to order Our Price: $62.91
55	410831407A	HINGE HALF LEFT	1 req	Avail to order Our Price: $527.06
55	410831408	LH DOOR STRICKER	1 req	Current Stock: 13 1 Used Available Our Price: $500.26
56	008700632	SCREW M6X30 UNI 59338G/ZD	8 req	Current Stock: 4 Our Price: $0.20
57	007060006	BONNET HANDLE NLA (NO LONGER AVAILABLE)	1 req	*See Description
58	007066001	REAR PLATE CARR.	1 req	Avail to order Our Price: $520.33
59	007030006	SILENCER GUARD RH BRACKET	1 req	Avail to order Our Price: $173.67
59	007030007	SILENCER GUARD LH BRACKET	1 req	Avail to order Our Price: $218.50
60	007030005	MUFFLER GUARD GRILL	1 req	Avail to order Our Price: $867.67
61	007021096	QUARTER LIGHT BEAM ASSEMBLY	2 req	Avail to order Our Price: $344.14
62	007021114	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	4 req	*See Description
63	007021192	LEFT DOOR LOCK	1 req	Avail to order Our Price: $1,417.94
63	007021191	RIGHT DOOR LOCKS	1 req	Avail to order Our Price: $1,420.95
64	007021132	BL OPEN.CONTROL LEVERPLATE	1 req	Avail to order Our Price: $68.85
64	007021129	BLOCK UNLOCK CONTROLLEVERPLATE	1 req	Avail to order Our Price: $137.79
65	007021130	OPENING LOCK CONTROLLEVER	1 req	Avail to order Our Price: $171.43
65	007021131	OPEN LOCK CONTROL LEVER	1 req	Avail to order Our Price: $208.00
66	007021190	NLA (NO LONGER AVAILABLE)	2 req	*See Description
67	007060018	ENGINE BONN.LIFTER	1 req	Current Stock: 2 Our Price: $173.67
68	007021040	OUTS.DOOR SAF.LOCK TIE ROD	2 req	Avail to order Our Price: $58.45
69	410837261	COM.SERR.HEAD 78926 /C DOOR PIECE	4 req	Avail to order Our Price: $3.69
70	007021031	L LOCK LEVER SUPPORT	2 req	Avail to order Our Price: $348.90
71	006558588	DOOR SAFETY LOCK	2 req	Avail to order Our Price: $16.48
72	006921178	NLA	2 req	*See Description
73	007021041	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	2 req	*See Description
74	007059004	BONNET LEFT HINGE	2 req	Avail to order Our Price: $175.36
75	007021034	MOV.GLASS SUPPORT	2 req	Avail to order Our Price: $433.88
76	N01021626	HEXAGON HEAD BOLT	6 req	Current Stock: 8 Our Price: $1.50
77	008410601	WASHER 12X6.1X0.6 C72	6 req	Avail to order Our Price: $0.00
78	N01152427	WASHER	6 req	Current Stock: 16 Our Price: $0.30
79	N01100637	HEX.NUT	3 req	Current Stock: 18 Our Price: $0.40
80	WHT001187	WASHER 10X5.3X1 UNI 6952 CAT-A	3 req	Avail to order Our Price: $0.90
81	007059026	FRONT HOOD DAMPER	1 req	Avail to order Our Price: $82.95
82	007017001	LH FIXED BUTT.WINDOW	1 req	Avail to order Our Price: $812.54
82	007017002	RH FIXED BUTT.WINDOW	1 req	Avail to order Our Price: $812.54
83	007021113	REAR VELOUR CHANNEL	2 req	Avail to order Our Price: $111.00
84	007090069	COUNTACH UPPER FORWARD DOOR SEAL - 150 CM	2 req	Current Stock: 2 Our Price: $80.27
85	007021115	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	4 req	*See Description
86	007021193	SHOCK ABSOR.FIX.PIN TO DOOR	2 req	Current Stock: 6 Our Price: $35.49
87	007017032	LH LATER. QUARTER LIGHT BEZEL	1 req	Avail to order Our Price: $341.13
87	007017031	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
88	006958530	PASSEMBLY TRIM	2 req	Current Stock: 1 Our Price: $37.44
89	007090067	COUNTACH FRONT BONNET SEAL 1 OF 2 PIECES	2 req	Current Stock: 1 Our Price: $117.30
90	007090067	COUNTACH FRONT BONNET SEAL 1 OF 2 PIECES	1 req	Current Stock: 1 Our Price: $117.30
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
