1984 Lamborghini Countach 5000s USA Gearbox (18)

Maintenance Parts:

Belts

PN	Item	Diagram
001613915	Alternator Drive Belt Alternator Drive Belt		Avail to order Our Price: $625.53

Brakes

PN	Item	Diagram
003113912	Brake Pad Front and Rear Countach Brake Pad		Avail to order Our Price: $44.90

Drivetrain

PN	Item	Diagram
001501188	Oil Filter - Miura Countach Espada Jarama Oil Filter Cartridge		Avail to order Our Price: $45.47
002109862	Clutch Plate Clutch Plate		Current Stock: 2 Our Price: $1,332.37
002109861	NLA (No Longer Available) Engine Flywheel		Avail to order Our Price: $2,909.20
002109864	Thrust Bearing Thrust Bearing		Avail to order Our Price: $7,026.38
001504611	Oil Filter Oil Filter		Avail to order Our Price: $474.63

Fuel-Air

PN	Item	Diagram
001320172	Air Filter - Carbureted Air Filter Early Countach, Miura, Jarama, Espada SEE PN 001320172KN for Performance filter option		Avail to order Our Price: $474.94
002021140	Warm Up Regulator Heat Regulator 0438140004 (043 8140 004)		Avail to order Our Price: $1,608.28
002021172	Frequency Valve Frequency Valve Bosch 0280150300 (028 0150 300)		Avail to order Our Price: $825.35
002021173	Fuel Dampers Dampers		Avail to order Our Price: $483.20
002021146	Cold Start Injector Starter Injector		Current Stock: 4 Our Price: $331.59
002021170	Countach Fuel Distributor Fuel Distributor 0438100106 (043 8100 106)		Avail to order Our Price: $5,502.31
002021174	Countach Injection EFI ECU ECU		Avail to order Our Price: $4,410.25
002021141	Countach EFI Fuel Injection Pump SEE ALSO PN 002021141B Fuel Pump		Avail to order Our Price: $1,486.77
002021147	Countach Fuel Injector Injector		Current Stock: 11 Our Price: $295.93
002021176	Lambda O2 Sensor (READ DESCRIPTION) Lambda Sensor The Exact OEM replacement for this is PN 002021176OE you can save by simply using your existing connector.		Avail to order Our Price: $803.43
002021141B	Countach EFI Fuel Injection Pump OEM This is the original and SAME fuel pump used on all Countach EFI systems. It has a different part number, in order to que the order from another vendor rather than the Factory. We would be more than happy to get it from Italy, but it will be the same pump and much more expensive.		Current Stock: 1 Our Price: $117.00
001320172KN	Performance filter for Countach/Espada/Jarama/Miura High Flow performance filter.		Current Stock: 1 Our Price: $125.33
002021142B	Fuel Filter - Countach - For Fuel Injected EFI This is the original and SAME fuel filter used on all Countach EFI systems. It has a different part number, in order to que the order from another vendor rather than the Factory. We would be more than happy to get it from Italy, but it will be the same pump and much more expensive. As of 1-3-2024 doesn't show availability		Current Stock: 1 Our Price: $37.39
002021145	Accumulator Accumulators		Current Stock: 1 Our Price: $606.71
002021173b	Fuel Dampers - For Fuel Injected EFI This is the original and SAME fuel regulator used on all Countach EFI systems. It has a different part number, in order to que the order from another vendor rather than the Factory. We would be more than happy to get it from Italy, but it will be the same pump and much more expensive.		Avail to order Our Price: $327.60
002021176OE	Lambda Sensors Original Equipment Lambda Sensors		Current Stock: 2 Our Price: $121.63
07M133843A	Air Filter - SPORT PERFORMANCE FILTER Performance filter replacement for 07M133843 Air Filter - Murcielago SV LP 670-4		Avail to order Our Price: $733.78
07M133843KN	K&N Air Filter - LM002, Countach, Diablo, Murcielago K&N's replacement air filters are designed to increase horsepower and acceleration while providing excellent filtration. These filters are washable and reusable and are custom designed to fit into your existing factory air box. Their drop-in design means adding performance is simple.		Avail to order Our Price: $67.93
980200016	ADDITIVO X CARB.G 001 700 03 ADDITIVO X CARB.G 001 700 03		Current Stock: 1 Our Price: $15.04

Fuses-Bulbs-Relays

PN	Item	Diagram
006617091	Bulb 21w tail light 21w Bulb		Current Stock: 5 Our Price: $12.67
006617094	Check Parts Manual for location Bulb LAMP BA 15S 21W Used in various lamps (depending on your year and model)		Current Stock: 77 Our Price: $9.28
N0177522	bulb Headlight LAMP 12V/3W		Current Stock: 10 Our Price: $2.01
006311154	Relay Relay		Avail to order Our Price: $52.25
006617093	12v 5w Bulb 12v 5w Bulb		Avail to order Our Price: $18.99
006309758	Cylinder Bulb 6411/12v 10w Cylinder Bulb 6411/12v 10w		Avail to order Our Price: $11.01
006617103	3w Bulb 3w Bulb		Avail to order Our Price: $6.69

Gaskets

PN	Item	Diagram
001526489	Engine Gasket Set - Countach Quatro 5000 Carbureted Engine Gasket Kit - Countach Quatro 5000 Carbureted see pn 001526469 for seals		Avail to order Our Price: $2,106.81
001526469	Grommet and Oil Seals Set - Countach Quatro 5000 Carbureted Grommet and Oil Seals Set Countach Quatro 5000 Carbureted		Avail to order Our Price: $146.98
001526488	Countach 5000 Engine Gasket Kit Engine Gasket Kit see pn 001526468 for seals kit		Avail to order Our Price: $1,284.36
001526468	Countach 5000s Grommet & Oil Seals Set - EURO Grommet & Oil Seals Set		Avail to order Our Price: $140.17
001526490	Countach 5000 USA - Engine Gasket Kit Engine Gasket Kit see pn 001526470 for seals kit		Avail to order Our Price: $1,120.74
001526470	Countach 5000 USA - Grommet & Oil Seals Set Grommet & Oil Seals Set		Avail to order Our Price: $104.79

Ignition

PN	Item	Diagram
008811403	Spark Plug - Countach-Jalpa Spark Plug		Avail to order Our Price: $61.84
001611403	Countach Wiring Harness Countach Wiring Harness		Avail to order Our Price: $2,801.84

Misc

PN	Item	Diagram
006111300	Long Wiper Blade Long Wiper Blade		Avail to order Our Price: $50.47
006128790	Wiper Short Blade 13 inch Wiper Short Blade (Previous PN 006111019)		Current Stock: 1 Our Price: $18.73
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut		Avail to order Our Price: $1.87
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month		Avail to order Our Price: $317.22
900000381	NLA (No Longer Available) Comes with Eyelet connects, Clamp connectors and Cigar Lighter Adapter.		Avail to order Our Price: $190.57
900000382	NLA use PN 400093050D for USA replacement		Avail to order Our Price: $190.57

Sensors

PN	Item	Diagram
002409895	NLA (No Longer Available) Reverse Switch		Avail to order Our Price: $120.91
001801333	NLA (No longer Available to order) Oil & Coolant Temperature Thermometer		Avail to order Our Price: $141.76
002021143	Thermostat Switch - EFI Countach only Original OEM Thermostat Switch - INTERR.TERM.0.280.130.214		Current Stock: 3 Our Price: $825.35
001724565	Fan Motor Thermal Contact Fan Motor Thermal Contact		Avail to order Our Price: $230.95

Open All

Select Group and TAV

< Previous Next >

TAV: 18 - Gearbox

1984 Lamborghini Countach 5000s USA Gearbox (18)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Countach Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	008252501	M25x1.5x38 Ring Nut	1 req	Avail to order Our Price: $32.75
2	002412262	Propeller Shaft Shim	1 req	Avail to order Our Price: $149.40
3	008502508	Bearing	1 req	Avail to order Our Price: $199.43
4	002412263	Spacer	1 req	Avail to order Our Price: $219.44
5	002412264	Propeller Shaft Journal Shim	1 req	Avail to order Our Price: $350.25
6	002427487	Propeller Shaft Journal Gear	1 req	Avail to order Our Price: $2,080.04
7	008524009	Bearing	1 req	Avail to order Our Price: $199.43
8	002407972	Propeller Shaft Journal	1 req	Avail to order Our Price: $1,280.90
9	N0123501	RETAINER RING 80X2.5	1 req	Current Stock: 7 Our Price: $7.47
10	008615804	SEE PN: 8615806 AND 1808102	1 req	Avail to order Our Price: $59.55
11	002409906	Propeller Shaft Journal Ring	1 req	Avail to order Our Price: $140.39
12	008613501	Lip Seal	2 req	Current Stock: 3 Our Price: $3.15
13	002408014	Differential Propeller Shaft	1 req	Avail to order Our Price: $1,143.66
14	008401422	Washer 28x14x2.3 Sh80 Vulk	2 req	Avail to order Our Price: $4.36
15	002419493	Reverse IntermediateMount Pin	1 req	Avail to order Our Price: $400.29
16	008501504	Bearing	2 req	Avail to order Our Price: $26.24
17	002419492	Reverse IntermediateGear	1 req	Avail to order Our Price: $761.97
18	002419501	Reverse Shaft Bushing	1 req	Avail to order Our Price: $326.67
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
