TAV: 62.02.00 - FUEL SYSTEM

2005 Lamborghini MURCIELAGO COUPE USA FUEL SYSTEM (62.02.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Murcielago Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	410937305	ELECTROVALVE SOLENOID VALVE	2 req	Avail to order 2 Used Available Our Price: $1,374.13
2	006227630	Union CONNECTOR	2 req	Avail to order Our Price: $14.94
3	008831528	Clamp CLAMP	4 req	Avail to order Our Price: $9.30
4	0062009920	FUEL SYSTEM PIPES WITH FILTER PIPE 1-6	1 req	Current Stock: 2 Our Price: $232.25
4	0062010456	RUBBER PIPE TO FUEL PUMP PIPE 7-12	1 req	Avail to order Our Price: $430.26
5	006229532	Fuel Pump Tank Clip PLATE	1 req	Avail to order Our Price: $53.90
6	006226900	Fuel Pump Rubber Band GASKET	2 req	Avail to order Our Price: $26.69
7	002024398	Fuel Pump FUEL PUMP	2 req	Current Stock: 6 Our Price: $762.25
8	001701495	Supplementary Reservoir Bracket RUBBER RING	1 req	Current Stock: 9 Our Price: $58.51
9	008300839	Stud M8x28 Uni 5911 8g Z STUD BOLT	1 req	Avail to order Our Price: $8.18
10	400251189B	CLAMP CLAMP	4 req	Current Stock: 27 Our Price: $11.61
11	410201212	Steering Oil Pipe Spring SPRING	2 req	Avail to order Our Price: $43.48
12	001701592	Radiator Shim SPACER	1 req	Current Stock: 8 Our Price: $20.77
13	006229533	Fuel Pump Tank Clip CLAMP	1 req	Current Stock: 1 Our Price: $71.04
14	0062010583	FUEL PUMP PROTECTION PROTECTION	1 req	Avail to order Our Price: $984.08
15	WHT001189	RUBBER WASHER MOUNT RUBBER RING	1 req	Current Stock: 6 Our Price: $6.78
16	WHT001942	WASHER WASHER	1 req	Current Stock: 13 Our Price: $3.51
17	008200804	Nut NUT	1 req	Current Stock: 7 Our Price: $2.00
18	0062009221	NLA (No Longer Available) PIPE 1-6	1 req	*See Description
18	0062009220	NLA (No Longer Available) PIPE 7-12	1 req	*See Description
19	0062003086	Filter FILTER	2 req	Current Stock: 7 Our Price: $2,350.79
20	008403201	Copper Washer 32.25x40x1.5 WASHER	2 req	Avail to order Our Price: $5.88
21	410201218	FUEL DELIVERY PIPE 1-6 PIPE 1-6	1 req	Current Stock: 1 Our Price: $506.18
21	410201217	FUEL DELIVERY PIPE 7-12 PIPE 7-12	1 req	Avail to order Our Price: $421.33
22	400201149B	NIPPLE CONNECTOR	2 req	Avail to order Our Price: $123.72
23	400201511A	Fuel Filter - Diablo - Gallardo - Murcielago FUEL FILTER	2 req	Current Stock: 10 Our Price: $293.29
24	410201196	Aerstop Fa Cn/20 GASKET	1 req	Current Stock: 4 Our Price: $5.36
25	410201450	METAL BAND PLATE	1 req	Avail to order Our Price: $14.82
26	410201349	Aerstop Fa Cn/20 GASKET	1 req	Avail to order Our Price: $35.22
27	N01152427	WASHER WASHER	2 req	Current Stock: 16 Our Price: $2.00
28	N01118312	HEX.HEAD CLAMPING NUT NUT	2 req	Avail to order Our Price: $2.17
29	410201449	Fuel Filter Seal Clamp CLAMP	1 req	Avail to order Our Price: $55.24
30	400422381	Stainless Steel Spring 9x11x10 SPRING	2 req	Avail to order Our Price: $2.90
31	0061015589	W.Harness WIRING HARNESS	1 req	Avail to order Our Price: $48.91
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
