TAV: 16.04.00 - INJECTION AND E-GEAR E.C.U.

2005 Lamborghini MURCIELAGO COUPE USA INJECTION AND E-GEAR E.C.U. (16.04.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Murcielago Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	N01100845	HEX.NUT NUT	3 req	Current Stock: 17 Our Price: $2.09
2	008410402	Washer D.4.3 Uni 1751 /Zd WASHER	3 req	Current Stock: 15 Our Price: $2.00
3	400972081	SECURING PART FLEXIBLE SUPPORT	6 req	Avail to order Our Price: $13.25
4	410907109	SPACER STUD	1 req	Avail to order Our Price: $36.40
4	410907109A	SPACER STUD	5 req	Avail to order Our Price: $34.32
5	0020015210	E.C.U. LIE Murcielago USA LIE CONTROL UNIT (E-GEAR)	2 req	Avail to order 3 Used Available Our Price: $5,448.86
5	0020014652	LIE CONTROL UNIT USA USA LIE CONTROL UNIT (MANUAL GEARBOX)	2 req	Avail to order Our Price: $3,640.03
9	410959252	POWER MOTOR CONTROL UNIT PMC - EFI LBA02 CONTROL UNIT	1 req	Current Stock: 1 Our Price: $16,986.76
10	410937539	BRACKET BRACKET	1 req	Avail to order Our Price: $276.91
11	400959645	SOUND ABSORBER INSULATING MATERIAL	1 req	Current Stock: 8 Our Price: $2.00
12	400907347	BRACKET, SELESPEED BRACKET	1 req	Avail to order Our Price: $16.24
13	086927156P	CONTROL UNIT FOR E GEAR E-GEAR CONTROL UNIT	1 req	Avail to order Our Price: $4,250.42
14	400907333	BRACKET, SELESPEED BRACKET	1 req	Avail to order Our Price: $53.45
15	N01118312	HEX.HEAD CLAMPING NUT NUT M6	1 req	Avail to order Our Price: $2.17
16	008400628	Washer WASHER	1 req	Avail to order Our Price: $2.00
17	WHT001190	SCREW SCREW M5	4 req	Current Stock: 14 Our Price: $2.00
18	WHT001187	Washer 10x5.3x1 Uni 6952 Cat-A WASHER	4 req	Current Stock: 8 Our Price: $2.00
19		FLEXIBLE SUPPORT (VALID FOR A DIFFERENT MARKET/MODEL YEAR)	0 req
20	410971336	bracket BRACKET	1 req	Avail to order Our Price: $175.68
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
