2021 Lamborghini HURACAN EVO SPYDER USA BRAKE AND ACCEL. LEVER MECH. (721.01.00)

Maintenance Parts:

Brakes

PN	Item	Diagram
4S0698151K	SET OF BRAKE PADS FOR CARBOCERAMIC DISC SET OF BRAKE PADS FOR DISC CARBOCERAMIC BRAKES OLD PN 4E0698151G		Current Stock: 1 Our Price: $948.35

Common repairs and upgrades

PN	Item	Diagram
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 2 Our Price: $22.58
4T0823359	GAS SPRING GAS SPRING		Current Stock: 2 Our Price: $82.49
4T0803615	TOWING EYE TOWING EYE OLD PN 400803615		Current Stock: 2 Our Price: $48.32
079115561J	SPIN-ON FILTER SPIN-ON FILTER		Avail to order Our Price: $83.92
079198405E	Oil Filter Gallardo/Huracan LP Series Oil Filter Gallardo LP Series		Current Stock: 7 Our Price: $89.92
1K0906283A	EGR VALVE ELECTR.CHANGEOVER EGR VALVE		Current Stock: 3 Our Price: $72.36

Fuel-Air

PN	Item	Diagram
4T0133843	FILTER ELEMENT FILTER ELEMENT FILTER ELEMENT		Avail to order Our Price: $477.90
06E906051K	FUEL PRESSURE SENSOR FUEL PRESSURE SENSOR		Current Stock: 1 Our Price: $123.28
4s0819439	Filter Element Filter Element		Current Stock: 6 Our Price: $104.52
07L127025S	FUEL PUMP FUEL PUMP		Avail to order Our Price: $695.26

Gaskets

PN	Item	Diagram
N0138493	WASHER WASHER		Current Stock: 47 Our Price: $4.18

Ignition

PN	Item	Diagram
0BZ911024D	STARTER STARTER		Current Stock: 1 Our Price: $1,307.14

Misc

PN	Item	Diagram
0R0000149	CLEANER FLUID 250ml CLEANER FLUID		Current Stock: 1 Our Price: $70.78

Sensors

PN	Item	Diagram
7PP907275F	WHEEL ELECTRONICS WHEEL ELECTRONICS		Avail to order Our Price: $169.72
4H0959126A	AC PRESSURE SENSOR A/C PRESSURE SENSOR,		Avail to order Our Price: $80.25
4S0906262F	LAMBDA PROBE BACK RIGHT O2 SENSOR LAMBDA PROBE LSU 4.9		Current Stock: 1 Our Price: $571.69
4S0906262G	LAMBDA PROBE BACK LEFT O2 SENSOR LAMBDA PROBE LSU 4.9		Current Stock: 1 Our Price: $343.91
4E0927803F	RH ABS SENSOR SPEED SENSOR		Avail to order Our Price: $145.31
4E0927804F	LH ABS SENSOR SPEED SENSOR		Current Stock: 1 Our Price: $145.31

Tools and Tookits

PN	Item	Diagram
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month		Avail to order Our Price: $373.98

Open All

Select Group and TAV

< Previous Next >

TAV: 721.01.00 - BRAKE AND ACCEL. LEVER MECH.

2021 Lamborghini HURACAN EVO SPYDER USA BRAKE AND ACCEL. LEVER MECH. (721.01.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Huracan Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	4S1723031D	PEDAL CLUSTER BRAKE PEDAL ( LHD)	1 req	Avail to order Our Price: $507.67
2	1K1723503AK	ACCELERATOR MODULE ACCELERATOR PEDAL WITH ELECTRONIC MODULE	1 req	Avail to order Our Price: $454.08
3	N10483102	HEXALOBULAR SOCKET HEX SOCKET HEAD BOLT (COMBI) (M6X50)	2 req	Avail to order Our Price: $2.00
4	N10752901	HEXALOBULAR SOCKETM5X18 FILLISTER HD. BOLT (M5X18)	5 req	Avail to order Our Price: $2.00
5	N10719301	12-POINT SOCKET SOCKET HEAD COLLARED BOLT WITH INNER MULTIPOINT HEAD (M8X28)	1 req	Avail to order Our Price: $3.43
6	4F0945459B	SENSOR BRAKE LIGHT SENSOR (4 PIN)	1 req	Current Stock: 3 Our Price: $42.43
7		BRAKE SERVO (SEE ILLUSTRATION : 612.02)	0 req
8	N10653301	HEXAGON FLANGE BOLT HEX COLLARED BOLT (M6X20)	6 req	Current Stock: 17 Our Price: $2.31
9	1K0721989	CAP CAP	1 req	Avail to order Our Price: $2.00
10	N01508210	HEXAGON FLANGE NUT HEXAGON COLLAR NUT (M6)	1 req	Current Stock: 17 Our Price: $2.09
11	N10752901	HEXALOBULAR SOCKETM5X18 FILLISTER HD. BOLT (M5X18)	4 req	Avail to order Our Price: $2.00
12	4S1721188D	BRACKET GPM LL UNTEN BRACKET ( LHD)	1 req	Avail to order Our Price: $20.85
13		BRACKET (FOR RHD CARS ONLY)	0 req
14		BRACKET (FOR RHD CARS ONLY)	0 req
15	4S0723131	PEDAL PAD BREMSPEDAL CAP FOR FOOT BRAKE PEDAL	4 req	Avail to order Our Price: $43.63
16	4T1864775E	BRACKET-FOOT BRACKET FOR FOOTREST ( LHD)	1 req	Avail to order Our Price: $135.04
17		COVERING (INCLUDED IN REF. 28- LHD RUBBER)	1 req
18		FOOT REST (INCLUDED IN REF.28- LHD STEEL)	1 req
19	WHT006119	FLAT HEAD BOLT M5X16 HEX SOCKET COUNTERSUNK BOLT (M5X15)	1 req	Avail to order Our Price: $2.00
20	N90106304	HEXAGON NUT W. M6 HEXAGON COLLAR NUT (M6)	1 req	Avail to order Our Price: $2.39
21		OVAL HEXAGON SOCKET HEAD BOLT (FOR RHD CARS ONLY)	0 req
22		COVER (FOR RHD CARS ONLY)	0 req
23		BLANKET (FOR RHD CARS ONLY)	0 req
24		HEX SOCKET OVAL HEAD COLLARED (FOR RHD CARS ONLY)	0 req
25		OVAL HEAD PANEL SCREW (FOR RHD CARS ONLY)	0 req
26		HEX COLLARED BOLT (FOR RHD CARS ONLY)	0 req
27		EDGE PROTECTION (FOR RHD CARS ONLY)	0 req
28	4T1864417A	FOOT REST FOOT REST	1 req	Avail to order Our Price: $270.96
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
