2020 Lamborghini HURACAN EVO SPYDER USA WING PROTECTOR (853.07.00)

Maintenance Parts:

Tools and Tookits

Tools and Tookits

PN	Item	Diagram
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month		Avail to order Our Price: $317.22

Open All

Select Group and TAV

< Previous Next >

TAV: 853.07.00 - WING PROTECTOR

2020 Lamborghini HURACAN EVO SPYDER USA WING PROTECTOR (853.07.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Huracan Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	4T7809601B	SIDE PANEL SIDE PART (CONTACT YOUR AREA MANAGER-LEFT)	1 req	Avail to order Our Price: $10,777.58
1	4T7809602C	SIDE PANEL SIDE PART (CONTACT YOUR AREA MANAGER-RIGHT)	1 req	Avail to order Our Price: $10,777.58
2	4T7853173A	TRIM, FENDER B PILLAR TRIM (LEFT)	1 req	Avail to order Our Price: $790.74
2	4T7853174A	TRIM, FENDER B PILLAR TRIM (RIGHT)	1 req	Avail to order Our Price: $581.22
3	4T7809075B	BRACKET SEITENTEIL BRACKET	2 req	Avail to order Our Price: $46.72
4	4T7809821B	EXTENSION ADDED ON RR FENDER SUPPORT (LEFT)	1 req	Avail to order Our Price: $147.82
4	4T7809822B	EXTENSION ADDED ON RR FENDER SUPPORT (RIGHT)	1 req	Avail to order Our Price: $147.82
5	4T7821129C	BRACKET,WHEEL BRACKET FOR WHEEL HOUSING (LEFT)	1 req	Avail to order Our Price: $63.29
5	4T7821130C	BRACKET,WHEEL BRACKET FOR WHEEL HOUSING (RIGHT)	1 req	Avail to order Our Price: $63.29
6	4T0809465B	ANGLE BRACKET RETAINING PLATE (LEFT)	1 req	Avail to order Our Price: $14.07
6	4T0809466B	ANGLE BRACKET RETAINING PLATE (RIGHT)	1 req	Avail to order Our Price: $14.07
7	N10009209	HEXAGON HEAD BOLT M6X20-S1-L HEXAGON HEAD BOLT (COMBI) (M6X20)	6 req	Avail to order Our Price: $2.00
7	N10009507	HEX. BOLT WITH WASHER HEXAGON HEAD BOLT (COMBI) (M6X18)	6 req	Current Stock: 6 Our Price: $2.00
8		HEXAGON HEAD BOLT (COMBI) (NOT AVAILABLE)	0 req
9	16	HEXAGON HEAD BOLT (COMBI) (M6X20)	0 req
10		HEXAGON HEAD BOLT (COMBI) (NOT AVAILABLE)	0 req
11	N01508210	HEXAGON FLANGE NUT HEXAGON COLLAR NUT (M6)	4 req	Current Stock: 17 Our Price: $1.94
12	N10442204	HEXALOBULAR SOCKET HEXAGON SOCKET OVAL HEAD BOLT (COMBI) (M6X40)	4 req	Current Stock: 8 Our Price: $1.94
13	8H0806221	ADJUSTMENT PART COMPENSATING PIECE	4 req	Avail to order Our Price: $8.55
14	4T0831713	SEALING PIECE SEAL	2 req	Avail to order Our Price: $10.55
15	8E0837033	STRIKER LH LOCK STRIKER	2 req	Current Stock: 2 Our Price: $19.81
16	4T0807239B	INTERMEDIATE LAYERSCHLIESSBUEGEL WASHER	2 req	Avail to order Our Price: $27.77
17	470853883A	ANGLE BRACKET REGOLAB.SIDE PAN. SECURING BRACKET (LEFT)	4 req	Avail to order Our Price: $63.29
18	N91017401	OVAL HEAD CSK SCR. COUNTERSUNK MULTI-POINT SOCKET HEAD BOLT (M8X22)	2 req	Avail to order Our Price: $2.00
19	N90821401	nut EXPANDING NUT (4,8X19,6)	8 req	Current Stock: 25 Our Price: $2.00
20	4T7898011	FASTENING CLIP FASTENING CLIP	2 req	Avail to order Our Price: $58.27
21	4T0807591A	BRACKET FIX GRIGLIA SX ARM (LEFT)	1 req	Avail to order Our Price: $37.24
21	4T0807592A	BRACKET FIX GRIGLIA DX ARM (RIGHT)	1 req	Avail to order Our Price: $37.24
22	N91042302	HEXALOBULAR SOCKETM6X16 OVAL HEXAGON SOCKET HEAD BOLT (M6X16)	4 req	Avail to order Our Price: $2.00
23	N90981701	SPEED NUT SPEED NUT (INCLUDED IN REF.32-M5X21.0X15.3)	2 req	Current Stock: 20 Our Price: $2.00
24	4T0807985B	SUPPORT PART BRACKET (LEFT)	1 req	Avail to order Our Price: $15.36
24	4T0807986B	SUPPORT PART BRACKET (RIGHT)	1 req	Avail to order Our Price: $8.40
25	N01166623	WASHER WASHER (6,4X18X1,6)	4 req	Avail to order Our Price: $2.00
26	N91206801	DUO HEXAGON FLANGEM6X22 HEXAGON FLANGE SCREW (M6X22)	4 req	Avail to order Our Price: $2.00
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
