2015 HURACAN LP 610-4 COUPE - ARABIA

Maintenance Parts:

Belts

PN	Item	Diagram
07L903137T	RIBBED V-BELT RIBBED V-BELT		Current Stock: 3 Our Price: $65.92

Brakes

PN	Item
4E0698151G	See PN 4S0698151K Front Brake pads Set carbon ceramic brakes	Avail to order Our Price: $693.71
4S0698451	Rear Brake Pad Set Rear Brake Pad Set 1 SET OF BRAKE PADS FOR DISK BRAKE	Avail to order Our Price: $633.05
4S0615437B	WIRING HARNESS SENSOR WIRING HARNESS SENSOR	Avail to order Our Price: $47.50
4T0698010	Ceramic Brake Pad Kit BIADHESIVEE PADS KIT	Avail to order Our Price: $89.76

Common repairs and upgrades

PN	Item
900000384D	HURACAN CAR COVER WHITE STITCHING INDOOR INT. 62X CAR COVER WHITE STITCHING INDOOR	Avail to order Our Price: $346.44
900000384A	HURACAN CAR COVER GREEN STITCHING INDOOR Huracan Indoor Cover - Green Stitching	Avail to order Our Price: $375.56
900000384B	HURACAN CAR COVER ORANGE STITCHING INDOOR INT. 62X CAR COVER ORANGE STIT. NOTE: The orange color Lamborghini uses for this cover is very light and is almost yellow. This is normal and their intended color for this cover	Avail to order Our Price: $346.44
900000384C	HURACAN CAR COVER YELLOW STITCHING INDOOR INT. 62X CAR COVER YELLOW STIT.	Avail to order Our Price: $346.44
900000384E	HURACAN CAR COVER GREY STITCHING INDOOR INT. 62X CAR COVER GREY STIT.	Avail to order Our Price: $346.44
900000384F	HURACAN CAR COVER RED STITCHING INDOOR INT. 62X CAR COVER RED STITCHING INDOOR	Avail to order Our Price: $346.44
900000384G	HURACAN CAR COVER BLUE STITCHING INDOOR INT. 62X CAR COVER BLUE STITCHING INDOOR	Avail to order Our Price: $346.44

Drivetrain

PN	Item
079198405E	Oil Filter Gallardo/Huracan LP Series Oil Filter Gallardo LP Series	Current Stock: 14 Our Price: $71.98
0BZ105266N	Dual Mass Flywheel Dual Mass Flywheel	Avail to order Our Price: $1,953.38
4T0898014	BLACK 62X CENTRAL LOCK CONVERSION KIT BLACK 62X CENTRAL LOCK CONVERSION KIT	Avail to order Our Price: $5,119.33
4T0898014A	RED 62X CENTRAL LOCK CONVERSION KIT RED 62X CENTRAL LOCK CONVERSION KIT	Avail to order Our Price: $5,119.33

Fuel-Air

PN	Item
420133844E	ENGINE AIR FILTER HURACAN AIR FILTER SEE PN 420133844EZ for K&N performance filter	Current Stock: 4 Our Price: $96.04
4s0201511	Fuel Filter Huracan Fuel Filter Huracan	Avail to order Our Price: $175.00
4s0819439	Filter Element Filter Element	Avail to order Our Price: $44.50
4s0919088a	Fuel Pump Fuel Pump	Avail to order Our Price: $759.00

Ignition

PN	Item
101905631G	Spark Plug - Gallardo/Huracan LP Series Spark Plug Champion	Current Stock: 48 Our Price: $27.93
0BZ911024C	STARTER STARTER	Avail to order Our Price: $847.08
7P0915105C	BATTERY 92AH/520A BATTERY 92AH/520A	Avail to order Our Price: $679.40
079905115	Ignition Coil Ignition Coil	Avail to order Our Price: $52.99
06H905601C	SPARK PLUG SPARK PLUG	Avail to order Our Price: $28.62

Misc

PN	Item
4H0805615	TOWING EYE FOR HURACAN TOWING EYE	Avail to order Our Price: $31.47
4T1864435E	HURACAN SET OF 2 FLOOR MATS PICK BORDER COLOR HURACAN SET OF 2 FLOOR MATS PICK BORDER COLOR customizable sticthing or border	Avail to order Our Price: $703.49
900000381	BATTERY CHARGER ROW BC - EURO Comes with Eyelet connects, Clamp connectors and Cigar Lighter Adapter.	Current Stock: 3 Our Price: $154.40
900000382	NLA use PN 400093050D for USA replacement	Avail to order Our Price: $154.40
N0300574	KEY - Spanner Murcielago-Aventador-Huracan Wrench Spanner Murcielago-Aventador-Huracan	Avail to order Our Price: $7.23
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month	Avail to order Our Price: $241.25
4T0853251A	TRIM - Huracan clear sidemarker rear TRIM	Current Stock: 1 Our Price: $79.25
4T0853252A	TRIM - Huracan clear sidemarker rear TRIM	Current Stock: 1 Our Price: $79.25
4T0898200	DOOR LIGHT WITH LAMBORGHINI LOGO KIT DOOR LIGHT WITH LAMBORGHINI LOGO KIT Replaces - 4E0947415A	Current Stock: 1 Our Price: $192.52
4T0898201	DOOR LIGHT WITH LAMBORGHINI WRITING KIT PAIR OF DOOR LIGHTS WITH LAMBORGHINI SCRIPT WRITING KIT LIGHTS THE GROUND WITH THE LAMBORGHINI SCRIPT ILLUMINATED FROM THE DOOR Replaces - 4E0947415A	Current Stock: 2 Our Price: $192.52
4T0945119B	Side Marker Light - Huracan clear sidemarker front Side Marker Light	Current Stock: 1 Our Price: $132.48
4T0945120B	Side Marker Light- Huracan clear sidemarker front Side Marker Light	Current Stock: 1 Our Price: $132.48

Sensors

PN	Item
4E0927803F	SPEED SENSOR SPEED SENSOR	Avail to order Our Price: $96.04
4E0927804F	SPEED SENSOR SPEED SENSOR	Current Stock: 1 Our Price: $96.04
4H0959126A	PRESSURE SENSOR, A/C PRESSURE SENSOR,	Avail to order Our Price: $57.84
4E0927803	ABS SENSOR LEFT ABS SENSOR LEFT	Current Stock: 5 Our Price: $34.77
4E0927804	ABS SENSOR RIGHT ABS SENSOR RIGHT	Avail to order Our Price: $34.77
8Z0820535A	Outer Sensor Outer Sensor	Current Stock: 1 Our Price: $23.99

Open All

Select Group and TAV

< Previous Next >

TAV: 863.09.00 - ENGINE BAY - FIXING

2015 Lamborghini HURACAN LP 610-4 COUPE ARABIA ENGINE BAY - FIXING (863.09.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Huracan Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	4T8863843A	BRACKET LH BRACKET (OPT)	1 req	Avail to order Our Price: $29.58
1	4T8863844A	BRACKET RH BRACKET (OPT)	1 req	Avail to order Our Price: $29.58
2	4T8863974B	BRACKET RH BRACKET (OPT)	1 req	Avail to order Our Price: $41.75
3	4T0813285	RETAINING PLATE LH BRACKET	1 req	Avail to order Our Price: $26.35
3	4T0813286	RETAINING PLATE RH BRACKET	1 req	Avail to order Our Price: $26.16
4	N01166623	WASHER WASHER	22 req	Avail to order Our Price: $2.00
5	4T8863974A	BRACKET RH BRACKET	1 req	Avail to order Our Price: $47.36
6	4T8864287C	BRACKET LH BRACKET	1 req	Avail to order Our Price: $33.84
6	4T8864288C	BRACKET RH BRACKET	1 req	Avail to order Our Price: $33.84
7	4T8864851B	BRACKET LH BRACKET	1 req	Avail to order Our Price: $33.84
7	4T8864852B	BRACKET RH BRACKET	1 req	Avail to order Our Price: $33.84
8	4T8864287C	BRACKET LH BRACKET (OPT)	1 req	Avail to order Our Price: $33.84
8	4T8864288C	BRACKET RH BRACKET (OPT)	1 req	Avail to order Our Price: $33.84
9	4T0864473	BRACKET FORGED ENGINEBAY LH BRACKET (OPT)	1 req	Avail to order Our Price: $12.45
9	4T0864474	BRACKET FORGED ENGINEBAY RH BRACKET (OPT)	1 req	Avail to order Our Price: $12.45
10	4T8863973B	BRACKET LH BRACKET (OPT)	1 req	Avail to order Our Price: $34.49
11	N01508210	HEXAGON FLANGE NUT NUT (M6)	1 req	Avail to order Our Price: $2.00
12	N91188301	HEXALOBULAR SOCKET SCREW (M6X20)	8 req	Current Stock: 1 Our Price: $2.00
13	470861147	CATCH CATCH	2 req	Avail to order Our Price: $8.05
14	N91042302	HEXALOBULAR SOCKETM6X16 SCREW (M6X16)	8 req	Current Stock: 4 Our Price: $2.00
15	N10734301	HEXALOBULAR SOCKET SCREW (M6X12)	8 req	Avail to order Our Price: $2.00
16	8D0805960	SPEED NUT CLIP	24 req	Avail to order Our Price: $2.75
17	4T8863973A	BRACKET LH BRACKET	1 req	Avail to order Our Price: $33.18
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
