TAV: 66.01.02 - Rear Coque Elements

1999 Lamborghini Diablo SV USA Rear Coque Elements (66.01.02)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Diablo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	WHT003574	Lock Screw 4.8x19din7983/B	4 req	Avail to order Our Price: $2.00
2	WHT000916A	SPEED NUT	4 req	Current Stock: 10 Our Price: $16.53
3	009430159	Net Under Rear Lamp Grille	1 req	Current Stock: 1 Our Price: $288.49
4	0066004330	Late Model Rear Grill	1 req	Current Stock: 1 Our Price: $2,831.42
5	0066003563	Lamborghini Badge Double Brack	4 req	Current Stock: 13 Our Price: $14.62
6	0094004128	SV decoration	1 req	Current Stock: 4 Our Price: $124.80
7	WHT000757	SCREW	3 req	Avail to order Our Price: $5.44
8	008400624	Firal Genuine WasherFr Ny-6-13	3 req	Current Stock: 4 Our Price: $4.76
9	N90327506	SPEED NUT	3 req	Current Stock: 43 Our Price: $2.00
10	N10718801	HEXAGON FLANGE BOLT	2 req	Current Stock: 4 Our Price: $2.00
11	008700444	Screw	2 req	Current Stock: 11 Our Price: $2.00
12	N91109201	WASHER	2 req	Current Stock: 103 Our Price: $2.00
13	0094004121	Lamborghini Script 8 Inch OEM	1 req	Avail to order Our Price: $183.38
14	0066004142	Bull Badge Bracket	1 req	Current Stock: 5 Our Price: $16.30
15	0094004122	Bull decoration	1 req	Avail to order Our Price: $149.84
16	N01508213	HEXAGON FLANGE NUT	4 req	Current Stock: 4 Our Price: $2.00
17	WHT000757	SCREW	2 req	Avail to order Our Price: $5.44
18	009410205	Shim Between Rear Bumper And T	2 req	Current Stock: 2 Our Price: $12.42
19	009430103	Rh Water Radiator Air Outlet Grill	1 req	Avail to order Our Price: $3,559.71
20	009430104	Lh Coolant Radiator Grill	1 req	Avail to order Our Price: $790.72
21	008100621	Screw M6x20 Uni 5739/5s/Z	8 req	Avail to order Our Price: $2.00
22	WHT002961	WASHER	8 req	Current Stock: 38 Our Price: $2.00
23	009430141	NLA (No Longer Available)	4 req	*See Description
24	009410206	Rear Bumper Shim	2 req	Avail to order Our Price: $49.87
25	008700449	Screw 1/56819/01 Rif. Fiat	4 req	Current Stock: 19 Our Price: $3.43
26	N91115501	washer	4 req	Current Stock: 1 Our Price: $2.00
27	008220502	Se N90834301	2 req	Avail to order Our Price: $2.00
28	009430145	Muffler Cover Grille	1 req	Current Stock: 1 Our Price: $1,887.62
29	N91049601	screw	4 req	Current Stock: 16 Our Price: $2.00
30	009430144	RIGHT MUFFLER COVER DETACHABLE	1 req	Avail to order Our Price: $49.50
31	008220402	Clip	4 req	Current Stock: 8 Our Price: $5.14
32	009410200	Rear Ext.Cover.Between Fend.	1 req	Avail to order Our Price: $2,251.27
33	WHT000757	SCREW	3 req	Avail to order Our Price: $5.44
34	009430146	Left Bmuff.Cover Detachable Gr	1 req	Avail to order Our Price: $49.57
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
