TAV: 43.03.00 - Steering

1999 Lamborghini Diablo SV USA Steering (43.03.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Diablo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	N0138481	WASHER	3 req	Current Stock: 20 Our Price: $2.00
2	003101941	Banjo Bolt Fitting	1 req	Avail to order Our Price: $4.68
3	413422247	Power Steering Box Oil Return	1 req	Avail to order Our Price: $60.60
4	008831320	Clamp	2 req	Avail to order Our Price: $3.73
5	004033464	Oil Delivery Power Steering Bo	1 req	Avail to order Our Price: $526.16
6	004033459	Oil Return From Power Steering	1 req	Avail to order Our Price: $31.24
7	008101076	Screw Te M10x110 8.8Uni5737 Z	4 req	Avail to order Our Price: $3.51
8	008401007	Washer 21.5x10.4x2 Uni 6592/5s	4 req	Avail to order Our Price: $2.00
9	004333518	Steering Box Upper Rh Bracket	1 req	Avail to order Our Price: $240.79
10	004331587	Steering Column Upper Seal	1 req	Current Stock: 1 Our Price: $2.31
11	004333655	Steering Box Lower Bracket	1 req	Avail to order Our Price: $381.98
12	410419831	CUP	1 req	Avail to order Our Price: $1,378.60
13	004333658	Steering Box Lower Mount Shim	req	Avail to order Our Price: $11.04
14	004333657	Steering Box Lower Mount Shim	req	Avail to order Our Price: $17.08
15	N0211963	HEX.HEAD CLAMPING	3 req	Avail to order Our Price: $2.00
16	400419811A	BALL JOINT	2 req	Current Stock: 1 Our Price: $1,476.85
17	WHT001187	Washer 10x5.3x1 Uni 6952 Cat-A	3 req	Current Stock: 8 Our Price: $2.00
18	0043002396	Lower Shaft Bushing	1 req	Avail to order Our Price: $110.14
19	008700843	Screw Din 7984 8x25 10k B	2 req	Avail to order Our Price: $4.54
20	002334682	BEVEL GEAR	2 req	Avail to order Our Price: $5,506.77
21	N0111849	HEX.HEAD CLAMPING NUT	2 req	Current Stock: 5 Our Price: $2.39
22	0043002198	Jointed Shaft	1 req	Avail to order Our Price: $661.41
23	410422479	Oil Delivery/Return Pipe Plate	2 req	Avail to order Our Price: $9.46
24	008700673	Screw 6.3x9.5 Iso14 Uni694 9-B	4 req	Avail to order Our Price: $11.37
25	004330272	Steering Column to Chassis Boot seal	1 req	Avail to order Our Price: $86.18
26	004038062	Pump Delivery/ReturnPipe	1 req	Avail to order Our Price: $475.60
27	004332458	CV Joint & Steering Box Connec	1 req	Current Stock: 1 Our Price: $408.52
28	008410820	Snap Ring D.8 Din 7980	1 req	Current Stock: 50 Our Price: $2.00
29	008100831	Screw M8x30 Uni 5737/8g/Z	1 req	Avail to order Our Price: $2.00
30	004333656	Steering Box Side Lower Bracke	1 req	Avail to order Our Price: $294.29
31	410419831	CUP	1 req	Avail to order Our Price: $1,378.60
32	410419063	STEERING GEAR	1 req	Avail to order Our Price: $4,830.50
33	008401408	Annealed Copper Washer 21x14x1	2 req	Current Stock: 41 Our Price: $2.00
34	004331582	U-Bolt	1 req	Avail to order Our Price: $341.11
35	410422293	Oil Return Power Steering Box	1 req	Avail to order Our Price: $69.76
36	005124347	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
