TAV: 66.03.02 - Coque Elements-Left Flank

1999 Lamborghini Diablo GT USA Coque Elements-Left Flank (66.03.02)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Diablo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	0066007287	REAR MUDG. FENDER (LEFT)	1 req	Avail to order Our Price: $15,483.04
2	009490113	RH / LH BONNET SEAL	1 req	Avail to order Our Price: $27.14
3	0074004726	LEFT AIR CONVEYOR RADIATOR	1 req	Avail to order Our Price: $2,258.69
3	0074005603	AIR CONVEYOR	1 req	Avail to order Our Price: $1,739.01
4	0066005379	NET	1 req	Avail to order Our Price: $172.46
4	0066007286	Net (Grill) Rd cooler LH	1 req	Avail to order Our Price: $145.37
5	0066005381	NET	1 req	Avail to order Our Price: $266.15
6	0066005383	NET	1 req	Avail to order Our Price: $521.73
7	0066004621	Lh Side Spoiler	1 req	Avail to order Our Price: $7,089.71
8	0066004665	LEFT PANEL	1 req	Avail to order Our Price: $11,919.78
9	WHT002961	WASHER	2 req	Current Stock: 38 Our Price: $2.00
10	008700680	Special Screw M6x1x20	8 req	Avail to order Our Price: $3.39
11	WHT000757	SCREW	3 req	Avail to order Our Price: $5.44
12	008400624	Firal Genuine WasherFr Ny-6-13	3 req	Current Stock: 4 Our Price: $4.75
13	N90327506	SPEED NUT	6 req	Current Stock: 43 Our Price: $2.00
14	009410306	Conditioned Air Valve Lid On R	1 req	Avail to order Our Price: $78.76
15	WHT003114	PAN HEAD SHEET	6 req	Current Stock: 20 Our Price: $5.92
16	WHT003424	Spring	6 req	Current Stock: 7 Our Price: $2.00
17	0078004671	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
18	008700334	Parker Screw 2.9 x 22	2 req	Current Stock: 4 Our Price: $2.00
19	009411511	Rh/Lh Rear W/House Grit Seal	1 req	Avail to order Our Price: $128.07
20	009411512	Lh Rear W/House GritSeal	1 req	Avail to order Our Price: $67.86
21	009911503	LH Rear Wheelhouse Apron	1 req	Avail to order Our Price: $887.29
22	009411513	Left And Right Rear Bulkhead S	1 req	Current Stock: 1 Our Price: $182.05
23	009911501	LH Rear Wheelhouse	1 req	Avail to order Our Price: $1,173.40
24	008700449	Screw 1/56819/01 Rif. Fiat	17 req	Current Stock: 19 Our Price: $3.40
25	N91109201	WASHER	17 req	Current Stock: 103 Our Price: $2.00
26	WHT000916A	SPEED NUT	17 req	Current Stock: 10 Our Price: $16.51
27	008400624	Firal Genuine WasherFr Ny-6-13	9 req	Current Stock: 4 Our Price: $4.75
28	WHT000757	SCREW	9 req	Avail to order Our Price: $5.44
29	0094004514	Diablo GT decoration	1 req	Avail to order Our Price: $188.65
30	0074005122	PANEL	1 req	Avail to order Our Price: $75.17
31	009490115	No Description - Please Check your book	1 req	Avail to order Our Price: $15.56
32	N91049601	screw	4 req	Current Stock: 16 Our Price: $2.00
33	008931416	PLUG	4 req	Avail to order Our Price: $2.00
34	0066005205	APPENDIX	1 req	Avail to order Our Price: $3,202.99
35	008100830	Screw M8x20 Uni 5739/8g/Z	2 req	Current Stock: 19 Our Price: $2.00
36	008400814	Washer 8.25x22x2 Aq35 Zg	2 req	Current Stock: 14 Our Price: $2.00
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
