TAV: 17.03.01 - Radiators And Electro-Fans

1999 Lamborghini Diablo GT USA Radiators And Electro-Fans (17.03.01)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Diablo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	001733004	Bracket Seal	4 req	Avail to order Our Price: $25.20
2	001735035	Lh Coolant Radiator	1 req	Avail to order 1 Used Available Our Price: $3,121.25
3	008400818	Copper Washer	4 req	Current Stock: 9 Our Price: $2.00
4	001733423	Breather Drilled Screw	2 req	Avail to order Our Price: $53.73
5	400121539	MANIFOLD GASKET	2 req	Current Stock: 8 Our Price: $57.32
6	410121333A	air duct LH	1 req	Avail to order Our Price: $1,645.09
7	N91130601	HOSE CLIP	2 req	Current Stock: 2 Our Price: $39.38
8	001735264	Nourice To Air Breather Pipe	1 req	Avail to order Our Price: $19.46
9	001738038	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
10	008100824	Screw M8x75 Uni 5737-65a/F	4 req	Current Stock: 9 Our Price: $2.00
11	WHT001942	WASHER	8 req	Current Stock: 13 Our Price: $3.51
12	001733266	Radiator Bracket Ring	4 req	Avail to order Our Price: $7.21
13	008831515	Clamp	1 req	Avail to order Our Price: $9.97
14	001735034	Rh Coolant Radiator	1 req	Avail to order 1 Used Available Our Price: $3,121.25
15	410121334A	air duct	1 req	Avail to order Our Price: $1,719.52
16	001731451	Coolant Radiator Bracket Seal	2 req	Avail to order Our Price: $17.15
17	WHT003040	WASHER	8 req	Current Stock: 2 Our Price: $8.12
18	008410502	Washer D.5.3 Uni 1751/Zd	8 req	Current Stock: 33 Our Price: $2.00
19	N10430103	HEXALOBULAR SOCKET	8 req	Current Stock: 21 Our Price: $2.00
20	0017017063	RADIATOR FAN	2 req	Avail to order Our Price: $416.86
21	WHT002961	WASHER	8 req	Current Stock: 38 Our Price: $2.00
22	008410612	Snap Ring D.6 Din 7980	8 req	Avail to order Our Price: $2.00
23	008700644	Screw M6x12 Uni 5931/8g/Zd	8 req	Current Stock: 3 Our Price: $2.00
24	410121299	Wing Plug On Radiator	2 req	Avail to order Our Price: $249.37
25	WHT003058	O RING	2 req	Current Stock: 213 Our Price: $1.94
26	001733267	Radiator Bracket Ring Shim	4 req	Avail to order Our Price: $12.49
27	WHT001189	RUBBER WASHER MOUNT	4 req	Current Stock: 6 Our Price: $6.78
28	N90179103	WASHER	4 req	Current Stock: 5 Our Price: $2.00
29	008200804	Nut	4 req	Current Stock: 7 Our Price: $2.00
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
