TAV: 60.02.02 - Tunnel Panel Instruments

1999 Lamborghini Diablo GT USA Tunnel Panel Instruments (60.02.02)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Diablo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	0051006156	SHOCK ABSORBER BUTTON STRIP	1 req	Current Stock: 1 Our Price: $511.39
2	006327459	Bulb	1 req	Avail to order Our Price: $6.49
3	006029692	CLIMATE CONTROL EARLY DIABLO	1 req	Avail to order Our Price: $13,026.65
4	006027080	Tunnel Console Switch	1 req	Current Stock: 29 Our Price: $43.54
5	006026633	Switch	1 req	Current Stock: 27 Our Price: $43.54
6	006029741	Front Air Delivery Switch	1 req	Current Stock: 23 Our Price: $274.22
7	006026632	Switch	1 req	Current Stock: 25 Our Price: $43.54
8	006026634	NLA (No Longer Available)	1 req	*See Description
9	006027085	Fan Switch	1 req	Current Stock: 7 Our Price: $43.54
10	006027084	Switch With PositiveSymbol	1 req	Current Stock: 17 Our Price: $43.54
11	006027083	Hot/Cold Switch on Tunnel Cons	1 req	Current Stock: 29 Our Price: $43.54
12	006027082	Switch With NegativeSymbol	1 req	Current Stock: 14 Our Price: $43.54
13	006027081	Tunnel Console Switch	1 req	Current Stock: 25 Our Price: $43.54
14	006035295	Switch Blank	1 req	Current Stock: 4 Our Price: $55.84
15	006029662	Side/Taillight Switch	1 req	Avail to order Our Price: $139.55
16	006029664	HAZARD SWITCH	1 req	Avail to order Our Price: $55.84
17	006031357	Light Dimmer Switch	1 req	Avail to order Our Price: $134.96
18	006029668	Door Unlock Switch	1 req	Avail to order Our Price: $33.77
19	006029667	Door Lock Switch	1 req	Current Stock: 10 Our Price: $117.57
20	006030484	Ceiling Light Switch	1 req	Avail to order Our Price: $31.61
21	006029665	Front Foglight Switch	1 req	Current Stock: 1 Our Price: $274.22
22	006029666	Rear Foglight Switch	1 req	Current Stock: 1 Our Price: $274.22
23	006038266	Pre-2000 Switch Panel	1 req	Current Stock: 1 Our Price: $1,455.10
24	006032439	Peg	2 req	Avail to order Our Price: $11.04
25	006029671	Power Window switch Pre-2000	2 req	Avail to order Our Price: $25.05
26	006035295	Switch Blank	2 req	Current Stock: 4 Our Price: $55.84
27	0069005077	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
27	0069004452	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
28	005933187	ASHTRAY ASSEMBLE PRE-2000 DIABLO	1 req	Avail to order Our Price: $290.33
29	008700347	Special Tapping Screw 3.5 6px1 Dash screw 6.0	6 req	Current Stock: 15 Our Price: $31.15
30	008220306	Clip for Special Atofil.D.3.5	6 req	Current Stock: 3 Our Price: $4.10
31	006037116	Diablo Mirror control	1 req	Current Stock: 12 Our Price: $57.70
32	0024004833	SELECTOR FRAME	1 req	Avail to order Our Price: $1,178.64
33	0024004877	SELECTOR GASKET	1 req	Avail to order Our Price: $13.76
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
