1999 Diablo GT - USA

Group :

Tav :

Maintenance Parts:

Belts

PN	Item	Diagram
001736516	COOLANT PUMP ALTERNATOR BELT COOLANT PUMP ALTERNATOR BELT		Avail to order Our Price: $199.17
004534071	COMPRESSOR BELT COMPRESSOR BELT		Avail to order Our Price: $142.24

Brakes

PN	Item	Diagram
410615115D	E-BRAKE PAD - LATE DIABLO - MURCIELAGO SOLD EACH E-BRAKE PAD MURCIELAGO AND LATE DIABLO SOLD EACH		Current Stock: 1 Our Price: $57.73
0032000561	BRAKE PAD KIT -FRONT - LATE DIABLO - MURCIELAGO -4 PADS - 2 PER ROTOR BRAKE PAD KIT 4 PADS PER KIT. FRONT SAME PART NUMBER. FOR FULL SET OF FRONT , NEED QTY 2.		Current Stock: 1 Our Price: $1,154.57

Common repairs and upgrades

PN	Item
0079004387	SHOCK ABSORBER SHOCK ABSORBER FOR ANTERIOR COWLING	Current Stock: 2 Our Price: $139.56
0092004388	SHOCK ABSORBER FOR ENGINE COWLING SHOCK ABSORBER FOR ENGINE COWLING	Current Stock: 4 Our Price: $252.93
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO	Current Stock: 2 Our Price: $22.44

Drivetrain

PN	Item
002137138	BALANCED ASSEMBLY (PRESSURE PLATE AND FLYWHEEL) - LATE MODEL DIABLO BALANCED CLUTCH 002137138 CLUTCH WHEEL SOLD SEPERATELY	Avail to order Our Price: $2,170.01
002135367	THROW OUT BEARING - LATE DIABLO THRUST BEARING VALEO952112LO	Avail to order Our Price: $515.75
0017001862	WATER PUMP COMPLETE 1995 2001 - READ DESCRIPTION WATER PUMP COMPLETE 1995 2001 - READ DESCRIPTION HOWEVER THERE ARE TWO PULLEY TYPES, YOU MUST DOUBLE CHECK HOW YOUR POWER STEERING IS CONNECTED. THE OTHER VERSION IS PN 0017002472	Avail to order Our Price: $4,079.91
0017002472	WATER PUMP 1995 2001 - READ DESCRIPTION COOLANT PUMP COMPLETE - THIS PUMP FITS DIABLOS FROM 1995 TO 2001 - HOWEVER THERE ARE TWO PULLEY TYPES, YOU MUST DOUBLE CHECK HOW YOUR POWER STEERING IS CONNECTED. THE OTHER VERSION IS PN 0017001862	Avail to order Our Price: $3,329.34
002134687a	1995 - 2001 DIABLO CLUTCH ROD THIS IS AN AFTERMARKET CLUTCH ROD UPGRADE FOR DIABLO'S MANUFACTURED AFTER 1994 (1995 - 2001) THESE RODS ARE VERY PRONE TO BREAKAGE. FOR FULL ARTICLE AND INSTALLATION VISIT: HTTP://LAMBOWEB.COM/REPAIRS_SECTION/DIABLO_REPAIRS_BROKEN_CLUTCH_ROD.HTM HTTP://WWW.LAMBOWEB.COM/REPAIRS_SECTION/REPAIRS_CLUTCH_CONNECTING_ROD.HTM	Avail to order Our Price: $631.15
002135365R	CLUTCH DIABLO 1995 AND UP - RECONDITIONED CLUTCH DIABLO 1995 AND UP - RECONDITIONED PRESSURE PLATE ONLY	Current Stock: 1 Our Price: $678.73
002136948	SLAVE CLUTCH CYLINDER DIABLO / COUNTACH SLAVE CLUTCH CYLINDER	Current Stock: 3 Our Price: $134.37
004219984	MASTER CLUTCH CYLINDER CLUTCH CYLINDER CONTROL ASSEMBLY	Avail to order Our Price: $350.78
07M115561B	SPIN-ON FILTER CARTUCCIS FIL.OLIO SPIN-ON FILTER CARTUCCIS FIL.OLIO	Current Stock: 9 Our Price: $223.18

Fuel-Air

PN	Item
400201511A	FUEL FILTER - DIABLO - GALLARDO - MURCIELAGO FUEL FILTER	Current Stock: 9 Our Price: $293.11
AMAIRD	HI-PERFORMANCE AFE AIR FILTER - DIABLO/MURCIELAGO - SPORT AIR FILTER MURCIELAGO - DIABLO AFTER MARKET AFE AIR FILTER 30-10133	Current Stock: 1 Our Price: $145.65
002024396	FUEL INJECTOR (SOLD EA) MANIFOLD UPPER COVERINJECTOR	Avail to order Our Price: $405.53
002024398	FUEL PUMP FUEL PUMP	Current Stock: 6 Our Price: $761.00
07M133843A	AIR FILTER - SPORT PERFORMANCE FILTER PERFORMANCE FILTER REPLACEMENT FOR 07M133843 AIR FILTER - MURCIELAGO SV LP 670-4	Avail to order Our Price: $782.61
07M133843KN	K&N AIR FILTER - LM002, COUNTACH, DIABLO, MURCIELAGO K&N'S REPLACEMENT AIR FILTERS ARE DESIGNED TO INCREASE HORSEPOWER AND ACCELERATION WHILE PROVIDING EXCELLENT FILTRATION. THESE FILTERS ARE WASHABLE AND REUSABLE AND ARE CUSTOM DESIGNED TO FIT INTO YOUR EXISTING FACTORY AIR BOX. THEIR DROP-IN DESIGN MEANS ADDING PERFORMANCE IS SIMPLE.	Avail to order Our Price: $70.48

Fuses-Bulbs-Relays

PN	Item
006617095	LICENSE PLATE LAMP REPLACEMENT BULB LICENSE PLATE LAMP REPLACEMENT BULB	Current Stock: 42 Our Price: $11.09
006617091	BULB 21W TAIL LIGHT 21W BULB	Current Stock: 4 Our Price: $13.55
006617094	LAMP BA 15S 21W BULB LAMP BA 15S 21W USED IN VARIOUS LAMPS (DEPENDING ON YOUR YEAR AND MODEL)	Current Stock: 76 Our Price: $9.90
N0177522	BULB HEADLIGHT LAMP 12V/3W	Current Stock: 10 Our Price: $2.17
006329696	FRONT TURN SIGNAL BULB FRONT TURN SIGNAL BULB	Current Stock: 6 Our Price: $3.35
006329695	BULB FOR FOGLIGHT BULB FOR FOGLIGHT	Current Stock: 1 Our Price: $19.39
006329694	HEADLIGHT BULB HEADLIGHT BULB	Avail to order Our Price: $63.82
006137479	250A MAXI FUSE 250A MAXI FUSE	Current Stock: 3 Our Price: $12.71
006138330	ITALAMEC 384 (70A) ITALAMEC 384 (70A)	Avail to order Our Price: $34.86
006138003	DRL RELAY DRL RELAY	Avail to order Our Price: $37.28
006311155	RELAY RELAY	Avail to order Our Price: $67.32
006311154	RELAY RELAY	Avail to order Our Price: $56.14
006030676	LIGHT RELAY LIGHT RELAY	Current Stock: 3 Our Price: $184.13
006038007	RELAY RELAY	Avail to order Our Price: $14.25
006038006	MICRO RELAY MICRO RELAY	Avail to order Our Price: $22.30
006036296	NLA (NO LONGER AVAILABLE) RELAY	Avail to order Our Price: $24.68
006036297	NLA (NO LONGER AVAILABLE) RELAY	Avail to order Our Price: $46.74
410947413	RED DOOR LIGHT RED DOOR LIGHT - NLA (NO LONGER AVAILABLE) TO ORDER FROM FACTORY PLEASE CONTACT US FOR OTHER OPTIONS.	Avail to order Our Price: $92.91

Gaskets

PN	Item
0011005351	ENGINE GASKET SET - DIABLO 1998-1999 UNTIL VIN 2219 ENGINE GASKET SET - DIABLO 1998-1999 UNTIL VIN 2219 SEE PN 15002553 FOR GROMMET AND OIL SEAL SET	Avail to order Our Price: $3,329.34
0011005352	ENGINE GASKET SET DIABLO 1998-1999 AFTER VIN 2219 ENGINE GASKET SET DIABLO 1998-1999 AFTER VIN 2219 SEE PN 15002553 FOR GROMMET AND OIL SEAL SET	Avail to order Our Price: $3,611.73
0015002553	GROMMET & OIL SEALS SET - DIABLO VT 1998 GROMMET & OIL SEALS SET - DIABLO VT 1998	Avail to order Our Price: $237.07
0R1320002	DIABLO REAR DIFFERENTIAL SEAL KIT DIF SEAL KIT	Current Stock: 1 Our Price: $48.53
600940141L	LATCH GASKET LEFT LATCH GASKET SET LEFT THIS IS THE RUBBER/PLASTIC GASKET THAT IS LOCATED ON THE LEFT SIDE BETWEEN THE OUTER DOOR LATCH AND THE DOOR FRAME	Current Stock: 4 Our Price: $24.28

Ignition

PN	Item
001630289	SPARK PLUG - DIABLO SPARK PLUG	Current Stock: 38 Our Price: $32.88
DiabloWireSet	SPARK PLUG WIRES 1991-1995 DIABLO - AFTERMARKET SPARK PLUG WIRES 1991 THROUGH 1995 ONLY FOR SYSTEMS USING A DISTRIBUTOR CAP	Avail to order Our Price: $820.50
0016003036	SPARK PLUG SPARK PLUG	Avail to order Our Price: $64.80
0016004528	IGNITION COIL IGNITION COIL	Current Stock: 18 Our Price: $61.50
DiabloWireSet2	SPARK PLUG WIRES 1996 AND UP DIABLO - AFTERMARKET SPARK PLUG WIRES FOR DIABLOS WITH COIL PACK	Avail to order Our Price: $1,650.70

Misc

PN	Item
0061005005	MED 2000 ALARM REMOTE CONTROL PROGRAMMED MED 2000 ALARM REMOTE CONTROL. YOU MUST SUPPLY THE CARS VIN ALONG WITH PROOF OF OWNERSHIP (REGISTRATION AND PHOTO IDENTIFICATION) SCANNED AND EMAILED OR A COPY SENT TO US.	Avail to order Our Price: $212.40
0071003278	WIPER BLADE WIPER BLADE	Avail to order Our Price: $40.55
008200605R	OE SPEC ALTERNATIVE FOR 008200605 M6 NCM 70 URAMA SIMMON NUT	Avail to order Our Price: $1.94
0R0000149	CLEANER FLUID 250ML CLEANER FLUID	Current Stock: 1 Our Price: $70.78
400093050D	CTEK US-CD BATTERY CHARGER INPUT 110-120VAC OUTPUT MAX 4.3A, 12V BACK DRAIN LESS THAN 1.5AM/MONTH	Avail to order Our Price: $373.98

Sensors

PN	Item
001327641	POTENTIOMETER TPS THROTTLE POSITION SENSOR DIABLO POTENTIOMETER TPS THROTTLE POSITION SENSOR DIABLO	Current Stock: 2 Our Price: $199.79
001536755	OIL TEMPERATURE THERMOSTAT OIL TEMPERATURE THERMOSTAT - ALSO USED ON DIABLO 91-93 2WD AND 94	Current Stock: 1 Our Price: $544.18
0017006576	THERMOSTAT FOR DIABLO WATER THERMOSTAT - -NLA (NO LONGER AVAILABLE) DIRECT FROM LAMBORGHINI CONTACT US TO VERIFY AVAILABILITY FROM OTHER SOURCES	Current Stock: 3 Our Price: $541.02
002408637	REVERSE SWITCH REVERSE SWITCH	Avail to order Our Price: $136.72
004526663	CABIN AIR TEMPERATURE SENSOR TEMPERATURE SENSOR	Avail to order Our Price: $1,961.93
0051001139	NLA (NO LONGER AVAILABLE) ABS SENSOR WHEEL SPEED SENSOR - DIABLO/MURCIELAGO	Avail to order Our Price: $294.46
07L919501A	WATER TEMPERATURE SENSOR WATER TEMPERATURE SENSOR	Current Stock: 3 Our Price: $375.18
07M905381	PHASE SENSOR PHASE SENSOR	Avail to order Our Price: $697.09
086927321	CRANK / FLYWHEEL / TIMING SENSOR ELECTROMAGNETIC PROBE	Avail to order Our Price: $130.42
0R1470226	LAMBDA (O2 OXYGEN) SENSOR - DIABLO - EARLY MURCIELAGO LAMBDA (O2 OXYGEN) SENSOR - DIABLO - EARLY MURCIELAGO	Current Stock: 9 Our Price: $393.20

Tools and Tookits

PN	Item	Diagram
004129973	DIABLO FRONT TOW HITCH ASSEMBLY DIABLO FRONT TOW HITCH ASSEMBLY		Avail to order Our Price: $1,528.18
wheeltool	WHEEL INSTALL TOOL SCREWS INTO HUB FOR EASY INSTALLATION.		Current Stock: 94 Our Price: $19.42

Open All

Select Group and TAV

< Previous Next >

TAV: 21.02.00 - Clutch Control Levers

1999 Lamborghini Diablo GT USA Clutch Control Levers (21.02.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Diablo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	004219984	MASTER CLUTCH CYLINDER	1 req	Avail to order Our Price: $350.78
2	N0152785	WASHER	2 req	Current Stock: 71 Our Price: $0.46
3	008100830	SCREW M8X20 UNI 5739/8G/Z	2 req	Current Stock: 19 Our Price: $0.50
4	008200811	M8 UNI 5589/8G/ZDNUT	1 req	Avail to order Our Price: $6.79
5	008200804	NUT	1 req	Current Stock: 7 Our Price: $1.19
6	N90179103	WASHER	1 req	Current Stock: 5 Our Price: $1.77
7	410721213	BRAKE CYLINDER CONTROL FORK	1 req	Current Stock: 1 Our Price: $67.75
8	002129460	CLUTCH CYLINDER FORKPIN	1 req	Current Stock: 1 Our Price: $37.80
9	002134952	CLUTCH PLATE LEVER SHAFT	1 req	Current Stock: 1 Our Price: $745.46
10	WHT003690	ELASTIC PIN 5X32 UNI6873	2 req	Current Stock: 19 Our Price: $0.53
11	008900804	ELASTIC PIN 8X32 UNI6873	2 req	Current Stock: 20 Our Price: $2.01
12	N01100845	HEX.NUT	11 req	Current Stock: 17 Our Price: $2.09
13	WHT000771	SPRING LOCK WASHER	11 req	Current Stock: 10 Our Price: $1.32
14	008300808	STUD M8X35 UNI 5911 8G Z	5 req	Avail to order Our Price: $6.02
15	WHT003028	TAP END STUD	1 req	Avail to order Our Price: $22.23
16	008522204	ROLLER BEARING	3 req	Current Stock: 1 Our Price: $23.42
17	N10155210	HEX.NUT	2 req	Current Stock: 38 Our Price: $2.17
18	002134687	CLUTCH CYLINER ROD	1 req	Avail to order Our Price: $900.71
19	008612804	GROMMET	1 req	Avail to order Our Price: $7.31
20	002137394	CLUTCH CYLINDER HOSE	1 req	Avail to order Our Price: $211.80
21	008583701	O-RING E 37 UNI 7435-75	1 req	Current Stock: 8 Our Price: $0.57
22	008201206	12X1.25X11.8/ NUT	1 req	Avail to order Our Price: $6.87
23	WHT003078	REFERENCE PIN 8H7X16C40	2 req	Avail to order Our Price: $46.98
24	002134956	CLUTCH CYLINER PUSH ROD	1 req	Avail to order Our Price: $2,771.97
25	002129128	CLUTCH CYLINDER SHIM	2 req	Avail to order Our Price: $61.01
26	N01100845	HEX.NUT	1 req	Current Stock: 17 Our Price: $2.09
27	N0152785	WASHER	1 req	Current Stock: 71 Our Price: $0.46
28	WHT002962	WASHER	1 req	Current Stock: 11 Our Price: $0.37
29	002134957	CLUTCH CYLINDER ROD FORK	1 req	Current Stock: 2 Our Price: $220.72
30	410721427	SERVO SPRING TIEROD	1 req	Avail to order Our Price: $96.32
31	WHT002952	HEXAGON HEAD BOLT	1 req	Current Stock: 2 Our Price: $5.36
32	002136948	SLAVE CLUTCH CYLINDER DIABLO / COUNTACH	1 req	Current Stock: 3 Our Price: $134.37
33	WHT003544	COPPER WASHER 12.25X18X1.5	2 req	Current Stock: 76 Our Price: $36.76
34	002134973	HOSE SCREW	1 req	Avail to order Our Price: $266.14
35	008400819	WASHER 8X12X1 BV.0005096.A	2 req	Current Stock: 1 Our Price: $0.60
36	002137085	CLUTCH PIPE FORM CYLINDER TO H	1 req	Avail to order Our Price: $196.06
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
