2021 AVENTADOR SVJ COUPE - EUROPE

Maintenance Parts:

Common repairs and upgrades

PN	Item
900000170	Tutela CS Speed Fluid -Oil Lifting System 1 liter Tutela CS Speed Fluid -Oil Lifting System 1 liter	Avail to order Our Price: $67.89
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO	Current Stock: 2 Our Price: $22.58
4T0803615	TOWING EYE TOWING EYE OLD PN 400803615	Current Stock: 2 Our Price: $48.32

Ignition

PN	Item	Diagram
470905619C	Spark Plug Spark Plug		Avail to order Our Price: $106.98

Misc

PN	Item	Diagram
0R0000149	CLEANER FLUID 250ml CLEANER FLUID		Current Stock: 1 Our Price: $70.78

Sensors

PN	Item
7PP907275F	WHEEL ELECTRONICS WHEEL ELECTRONICS	Avail to order Our Price: $169.72
4H0959126A	AC PRESSURE SENSOR A/C PRESSURE SENSOR,	Avail to order Our Price: $80.25
06A906262AT	OXYGEN SENSOR O2 SENSOR - LAMBDA PROBE OXYGEN SENSOR O2 SENSOR - LAMBDA PROBE	Current Stock: 24 Our Price: $154.84
4E0927804F	LH ABS SENSOR SPEED SENSOR	Current Stock: 1 Our Price: $145.31
4E0927803F	RH ABS SENSOR SPEED SENSOR	Avail to order Our Price: $145.31

Tools and Tookits

PN	Item	Diagram
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month		Avail to order Our Price: $373.98
69795000805	V12 VALVE SEALING FITTING TOOL V12 VALVE SEALING FITTING TOOL		Avail to order Our Price: $359.54

Open All

Select Group and TAV

< Previous Next >

TAV: 117.02.00 - OIL CONTAINER

2021 Lamborghini AVENTADOR SVJ COUPE EUROPE OIL CONTAINER (117.02.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Aventador Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	470115373G	OIL RESERVOIR OIL CONTAINER	1 req	Avail to order Our Price: $1,853.51
2	N10558102	HEXALOBULAR SOCKET SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD (M6X18)	6 req	Current Stock: 9 Our Price: $4.54
3	470115641B	BRACKET BRACKET FOR FLUID RESERVOIR	1 req	Avail to order Our Price: $36.63
4	400121268	PUFFER RUBBER BUSH	2 req	Avail to order Our Price: $12.44
5	470115575C	CARRIER SERB.OLIO INF 2 BRACKET FOR FLUID RESERVOIR	1 req	Avail to order Our Price: $26.73
6		BRACKET FOR FLUID RESERVOIR (SEE REF: 29)	0 req
7	4D0317867A	RUBBER MOUNTING RUBBER BUSH	1 req	Avail to order Our Price: $8.71
8	4E0903127	SPACER BUSH MOUNTING	2 req	Avail to order Our Price: $14.67
9	N10451408	HEXALOBULAR SOCKET OVAL HEXAGON SOCKET HEAD BOLT (M6X16)	7 req	Avail to order Our Price: $2.00
10	470103811	BRACKET BRACKET	1 req	Avail to order Our Price: $692.27
11	470115659A	OIL HOSE OIL HOSE	1 req	Avail to order Our Price: $759.27
12	07C103464F	OIL SEPERATOR,CPL. OIL SEPARATOR	1 req	Avail to order Our Price: $282.87
13	WHT002961	WASHER WASHER (6,5X18X1,5)	3 req	Current Stock: 38 Our Price: $2.00
14	470115319A	COVER OIL DIPSTICK	1 req	Avail to order Our Price: $186.10
15	N10533601	12-POINT SOCKET FLANGE BOLT SOCKET HEAD BOLT WITH HEXAGON SOCKET HEAD	1 req	Avail to order Our Price: $3.20
16	WHT002641	O-RING SEAL RING (20,22X3,53)	1 req	Avail to order Our Price: $5.07
17	059919523A	TEMPERATURE SENDER TEMPERATURE SENSOR	1 req	Current Stock: 6 Our Price: $70.57
18	N0138157	O-RING SEAL RING (1 WASHER FOR SERVICE INSPECTION-14X20)	1 req	Current Stock: 1 Our Price: $4.18
19	N90813202	SCREW PLUG SEAL BOLT WITH SEALING RING (M14X1,5X22)	1 req	Avail to order Our Price: $12.66
20	470115157	PIPE UNION CONNECTOR UNION	1 req	Avail to order Our Price: $168.24
21	WHT004895	O-Ring SEAL RING (29X2)	1 req	Avail to order Our Price: $5.36
22	WHT001942	WASHER WASHER	4 req	Current Stock: 13 Our Price: $3.51
23	WHT001189	RUBBER WASHER MOUNT PLASTIC WASHER	2 req	Current Stock: 6 Our Price: $6.78
24	400121277	SPACER DISTANCE PIECE	2 req	Avail to order Our Price: $11.17
25	470103235A	BREATHER PIPE VENT HOSE (FROM VIN CLA00325)	1 req	Avail to order Our Price: $759.27
26	470115268	BRACKET,FRONT BRACKET	1 req	Avail to order Our Price: $54.12
27	059903261B	BUSH	1 req
28	059903265B	GROMMET	1 req
29	470115261F	BRACKET BRACKET FOR FLUID RESERVOIR	1 req	Avail to order Our Price: $30.23
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
