2021 Lamborghini AVENTADOR S AUSTRALIA INSTRUMENT PANEL (857.02.00)

Maintenance Parts:

Common repairs and upgrades

PN	Item
900000170	Tutela CS Speed Fluid -Oil Lifting System 1 liter Tutela CS Speed Fluid -Oil Lifting System 1 liter	Avail to order Our Price: $67.89
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO	Current Stock: 2 Our Price: $22.58
4T0803615	TOWING EYE TOWING EYE OLD PN 400803615	Current Stock: 2 Our Price: $48.32

Drivetrain

PN	Item	Diagram
07M115561B	SPIN-ON FILTER CARTUCCIS FIL.OLIO SPIN-ON FILTER CARTUCCIS FIL.OLIO		Avail to order Our Price: $104.15

Fuel-Air

PN	Item	Diagram
470133843A	FILTER ELEMENT FILTER ELEMENT		Current Stock: 1 Our Price: $174.19

Ignition

PN	Item	Diagram
470905619A	SPARK PLUG SPARK PLUG		Avail to order Our Price: $110.70
470905619C	Spark Plug Spark Plug		Avail to order Our Price: $106.98

Misc

PN	Item
6Q0819653B	CABIN FILTER AVENTADOR CABIN FILTER	Current Stock: 2 Our Price: $65.74
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month	Avail to order Our Price: $373.98
0R0000149	CLEANER FLUID 250ml CLEANER FLUID	Current Stock: 1 Our Price: $70.78

Sensors

PN	Item
7PP907275F	WHEEL ELECTRONICS WHEEL ELECTRONICS	Avail to order Our Price: $169.72
4H0959126A	AC PRESSURE SENSOR A/C PRESSURE SENSOR,	Avail to order Our Price: $80.25
06A906262AT	OXYGEN SENSOR O2 SENSOR - LAMBDA PROBE OXYGEN SENSOR O2 SENSOR - LAMBDA PROBE	Current Stock: 24 Our Price: $154.84
4E0927804F	LH ABS SENSOR SPEED SENSOR	Current Stock: 1 Our Price: $145.31
4E0927803F	RH ABS SENSOR SPEED SENSOR	Avail to order Our Price: $145.31

Tools and Tookits

PN	Item	Diagram
470012257	DEMOUNTING HOOK DEMOUNTING HOOK		Current Stock: 1 Our Price: $253.70
69795000805	V12 VALVE SEALING FITTING TOOL V12 VALVE SEALING FITTING TOOL		Avail to order Our Price: $359.54

Open All

Select Group and TAV

< Previous Next >

TAV: 857.02.00 - INSTRUMENT PANEL

2021 Lamborghini AVENTADOR S AUSTRALIA INSTRUMENT PANEL (857.02.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Aventador Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	472857921H	TRAY CASS.PORTAOGG.PASS STOWAGE COMPARTMENT (LEATHER, SIGNAL VIN, NO LOGO - STD- RHD)	1 req	Avail to order Our Price: $3,558.14
1	472857921J	LOWER DASHBOARD, LEATHER RHD STOWAGE COMPARTMENT (LEATHER, SIGNAL VIN, WITH LOGO - BRANDING VERSION- RHD)	1 req	Avail to order Our Price: $3,558.14
2	472857226B	MOLDING,DASHBOARD PLANCIA SUP.RH RHD TRIM STRIP FOR DASH PANEL, FOIL SEALED ( RHD)	1 req	Avail to order Our Price: $85.76
3	5K0919234A	WARNING LIGHT CONTROL LAMP FOR DEACT- IVATION OF FRONT PASSENGER AIRBAG	1 req	Avail to order Our Price: $40.80
4	400853886	Dashbord Emblem LAMBORGHINI EMBLEM	1 req	Avail to order Our Price: $489.02
5	472857222A	MOLDING,DASHBOARD TRIM STRIP FOR DASH PANEL, FOIL SEALED ( RHD)	1 req	Avail to order Our Price: $85.76
6	470819903	AIR INTAKE DEFROSTER NOZZLE FOR WIND- SCREEN	1 req	Avail to order Our Price: $424.30
7	8K0909131D	DRIVER IDENTIFICATION IGNITION/STARTER SWITCH	1 req	Avail to order Our Price: $126.25
8	8R2905219	TRIM TRIM ( RHD)	1 req	Avail to order Our Price: $21.74
9	472857087A	CLIP ANGLE KEY FRAME. SECURING BRACKET ( RHD)	1 req	Avail to order Our Price: $56.80
10	N90777702	SNAP NUT CLAMP SPEED NUT (M5X13.6X11.5)	2 req	Current Stock: 3 Our Price: $2.00
11	N10406602	SCREW OVAL HEXAGON SOCKET HEAD BOLT (M5X8)	2 req	Avail to order Our Price: $2.00
12	12	CLIP	0 req
13	N10586401	HEXALOBULAR SOCKET OVAL HEXAGON SOCKET HEAD BOLT (M5X10)	2 req	Current Stock: 13 Our Price: $2.00
14	N90981701	SPEED NUT SPEED NUT (M5X21.0X15.3)	3 req	Current Stock: 20 Our Price: $2.00
15	N10738101	HEXALOBULAR SOCKET HEX SOCKET HEAD BOLT (COMBI) (M5X16)	3 req	Current Stock: 6 Our Price: $2.00
16		CONTROL PANEL WITH PUSHBUTTONS (FOR ROADSTER MODEL)	1 req
17	N90475903	SNAP NUT CLAMP M5X13.6X11.5 SPEED NUT (M5X13,6X11,5)	1 req	Avail to order Our Price: $2.00
18	N01166623	WASHER WASHER (6,4X18X1,6)	8 req	Current Stock: 8 Our Price: $2.00
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
