2016 AVENTADOR SV LP750-4 ROADSTER - ENGLAND

Maintenance Parts:

Drivetrain

PN	Item	Diagram
07M115561B	SPIN-ON FILTER CARTUCCIS FIL.OLIO SPIN-ON FILTER CARTUCCIS FIL.OLIO		Current Stock: 2 Our Price: $48.56

Fuel-Air

PN	Item	Diagram
470133843A	FILTER ELEMENT FILTER ELEMENT		Current Stock: 1 Our Price: $163.31

Ignition

PN	Item	Diagram
470905619	SEE PN 470905619C SPARK PLUG		Avail to order Our Price: $101.44
470905619A	SPARK PLUG SPARK PLUG		Avail to order Our Price: $104.03

Misc

PN	Item
N0300574	KEY - Spanner Murcielago-Aventador-Huracan Wrench Spanner Murcielago-Aventador-Huracan	Avail to order Our Price: $9.19
6Q0819653B	ODOR FILTER ODOR FILTER	Avail to order Our Price: $63.53
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month	Avail to order Our Price: $317.22

Tools and Tookits

PN	Item	Diagram
470012257	DEMOUNTING HOOK DEMOUNTING HOOK		Current Stock: 1 Our Price: $253.70

Open All

Select Group and TAV

< Previous Next >

TAV: 863.03.00 - TUNNEL

2016 Lamborghini AVENTADOR SV LP750-4 ROADSTER ENGLAND TUNNEL (863.03.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Aventador Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	475863242E	CENTER CONSOLE RHD LEADER SMOKER CENTRE CONSOLE, LOWER PART (WITH ASHTRAY - LEATHER INTERIOR - SUPPLY VIN- RHD)	1 req	Avail to order Our Price: $3,487.29
1	475863242G	CENTRE CONSOLE (WITHOUT ASHTRAY - LEATHER INTERIOR - SUPPLY VIN ) CENTRE CONSOLE, LOWER PART (WITHOUT ASHTRAY - LEATHER INTERIOR - SUPPLY VIN- RHD)	1 req	Avail to order Our Price: $3,171.57
2	470863667C	LINING SIDE PANEL TRIM FOR CENTRE CONSOLE (ALCANTARA UPHOLSTERY - SUPPLY VIN)	1 req	Avail to order Our Price: $1,743.65
2	470863667D	LINING FIANCH.SX TUNNEL SIDE PANEL TRIM FOR CENTRE CONSOLE (CUP HOLDER - LEATHER INTERIOR - SUPPLY VIN- RHD)	1 req	Avail to order Our Price: $1,657.54
2	470863667F	LINING FIANCH.SX TUNNEL SIDE PANEL TRIM FOR CENTRE CONSOLE (LEATHER SEMIANILINA INTERIOR - Q-CITURA - SUPPLY VIN)	1 req	Avail to order Our Price: $1,657.54
3	470863668B	LINING FIANCH.DX TUNNEL SIDE PANEL TRIM FOR CENTRE CONSOLE (LEATHER INTERIOR - SUPPLY VIN)	1 req	Avail to order Our Price: $1,657.54
3	470863668C	LINING FIANCH.DX TUNNEL SIDE PANEL TRIM FOR CENTRE CONSOLE (ALCANTARA UPHOLSTERY - SUPPLY VIN)	1 req	Avail to order Our Price: $1,743.65
4	470863315A	EXTENSION,CENTER C LINING FOR CONSOLE (LEATHER INTERIOR - SUPPLY VIN)	1 req	Avail to order Our Price: $1,407.84
4	470863315B	EXTENSION,CENTER LINING FOR CONSOLE	1 req	Avail to order Our Price: $1,407.84
5	472863849	BRACKET CORNER TRIM	1 req	Avail to order Our Price: $138.06
6	4G8857406A6PS	ASHTRAY ASHTRAY (SOUL (BLACK))	1 req	Avail to order Our Price: $65.74
8	470863253	BRACKET ATTACHMENT BARS (CENTER)	1 req	Avail to order Our Price: $28.78
9	8E0806193	RETAINING PART COMPENSATING PIECE ( 3,4MM)	2 req	Avail to order Our Price: $15.93
10	470863583	BRACKET ATTACHMENT BARS (LEFT FRONT)	1 req	Avail to order Our Price: $15.93
11	470863584	BRACKET ATTACHMENT BARS (RIGHT FRONT)	1 req	Avail to order Our Price: $15.93
12	470863346	BRACKET BRACKET	2 req	Avail to order Our Price: $28.92
13	N90986803	FLANGE TAPPING HEXAGON SOCKET HEAD PANEL BOLT (4,2X13)	4 req	Avail to order Our Price: $2.00
14	N10653801	HEXALOBULAR SOCKETM5X8 HEXAGON SOCKET HEAD BOLT (M5X8.0)	16 req	Avail to order Our Price: $3.38
15	N91092001	Please Check Manual for description STOP BUFFER (4,5X2,2X8,6)	2 req	Avail to order Our Price: $2.00
16	N90657502	CLAMPING WASHER CLAMPING WASHER (5X11,75)	1 req	Avail to order Our Price: $2.00
17	N01508210	HEXAGON FLANGE NUT HEXAGON COLLAR NUT (M6)	3 req	Current Stock: 17 Our Price: $1.94
18	N10653201	HEXAGON FLANGE HEX COLLARED BOLT (M6X16)	2 req	Current Stock: 12 Our Price: $2.01
19	N0154487	SPEED NUT SPEED NUT (4,2X16,3X11)	4 req	Current Stock: 6 Our Price: $2.00
20	4D0857949A	GROMMET GROMMET	2 req	Avail to order Our Price: $8.40
21	470863285	SPRING SPRING (LEFT)	1 req	Avail to order Our Price: $40.19
22	470863286	SPRING SPRING (RIGHT)	1 req	Avail to order Our Price: $40.19
23	470863761	COVER COVER FOR DRAWER (LEATHER INTERIOR - SUPPLY VIN-LEATHER (STANDARD))	1 req	Avail to order Our Price: $476.46
23	470863761A	COVER COVER FOR DRAWER (ALCANTARA UPHOLSTERY - SUPPLY VIN-ALCANTARA)	1 req	Avail to order Our Price: $795.05
23	470863761B	COVER TUNNEL COVER RIV. COVER FOR DRAWER (SUPPLY VIN-CARBON EFFECT)	1 req	Avail to order Our Price: $795.05
23	470863761C	COVER COVER FOR DRAWER	1 req	Avail to order Our Price: $795.05
24	470863273A	COVER,CENTER TRIM (INNER)	1 req	Avail to order Our Price: $243.97
26	470863300	TRAY GLOVE COMPARTMENT	1 req	Avail to order Our Price: $177.24
27	470863348	PIVOT PIN	1 req	Avail to order Our Price: $34.09
28	418880324	FRICTIONING MECHANISM BRAKE ELEMENT	2 req	Avail to order Our Price: $16.30
29	8J0919303	CIGAR LIGHTER CIGARETTE LIGHTER (LIGHTER)	1 req	Avail to order Our Price: $23.54
29	8J0919303A	CIGAR LIGHTER SOCKET (OUTLET 12V)	1 req	Avail to order Our Price: $19.59
30	8T0853107	CLAMP CLIP	6 req	Avail to order Our Price: $2.00
31	N10602101	SCREW HEXAGON SOCKET FLAT HEAD BOLT	10 req	Current Stock: 17 Our Price: $2.00
32	N10721401	SCREW OVAL HD. SELF-TAPP FITT. SCREW	3 req	Avail to order Our Price: $2.00
33	N10405604	HEXALOBULAR SOCKET OVAL HEXAGON SOCKET HEAD BOLT	4 req	Avail to order Our Price: $2.00
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
