2016 AVENTADOR SV LP750-4 ROADSTER - AUSTRALIA

Group :

Tav :

Maintenance Parts:

Common repairs and upgrades

PN	Item
900000170	TUTELA CS SPEED FLUID -OIL LIFTING SYSTEM 1 LITER TUTELA CS SPEED FLUID -OIL LIFTING SYSTEM 1 LITER	Current Stock: 8 Our Price: $61.26
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO	Current Stock: 7 Our Price: $27.66
4T0803615	TOWING EYE TOWING EYE OLD PN 400803615	Current Stock: 4 Our Price: $58.32
G052529A2	TRANSMISSION FLUID TRANSMISSION FLUID	Current Stock: 14 Our Price: $71.47

Drivetrain

PN	Item	Diagram
07M115561B	SPIN-ON FILTER CARTUCCIS FIL.OLIO SPIN-ON FILTER CARTUCCIS FIL.OLIO		Current Stock: 9 Our Price: $201.60

Fuel-Air

PN	Item	Diagram
470133843A	FILTER ELEMENT FILTER ELEMENT		Current Stock: 2 Our Price: $157.26

Ignition

PN	Item	Diagram
470905619A	SPARK PLUG SPARK PLUG		Avail to order Our Price: $99.97
470905619C	SPARK PLUG SPARK PLUG		Avail to order Our Price: $100.13

Misc

PN	Item
6Q0819653B	CABIN FILTER AVENTADOR CABIN FILTER	Current Stock: 2 Our Price: $61.49
400093050D	CTEK US-CD BATTERY CHARGER INPUT 110-120VAC OUTPUT MAX 4.3A, 12V BACK DRAIN LESS THAN 1.5AM/MONTH	Avail to order Our Price: $417.39
0R0000149	CLEANER FLUID 250ML CLEANER FLUID	Current Stock: 1 Our Price: $82.84

Sensors

PN	Item
7PP907275F	WHEEL ELECTRONICS WHEEL ELECTRONICS	Avail to order Our Price: $185.62
4H0959126A	AC PRESSURE SENSOR A/C PRESSURE SENSOR,	Avail to order Our Price: $79.44
06A906262AT	OXYGEN SENSOR O2 SENSOR - LAMBDA PROBE OXYGEN SENSOR O2 SENSOR - LAMBDA PROBE	Current Stock: 22 Our Price: $153.21
4E0927803F	RH ABS SENSOR SPEED SENSOR	Avail to order Our Price: $143.73
4E0927804F	LH ABS SENSOR SPEED SENSOR	Current Stock: 1 Our Price: $143.73

Tools and Tookits

PN	Item
470012257	DEMOUNTING HOOK DEMOUNTING HOOK	Avail to order Our Price: $611.31
69795000805	V12 VALVE SEALING FITTING TOOL V12 VALVE SEALING FITTING TOOL	Avail to order Our Price: $434.20
69195290	TOOL KIT FOR REMOVING THE GRILLE TOOL KIT FOR REMOVING THE GRILLE BUMPER NET TOOL	Avail to order Our Price: $474.62
61195080	TOOL FOR TOP DEAD CENTER LP700 TOP DEAD CENTER GAUGE. TOOL FOR TOP DEAD CENTER LP700	Avail to order Our Price: $314.66
wheeltool	WHEEL INSTALL TOOL SCREWS INTO HUB FOR EASY INSTALLATION.	Current Stock: 91 Our Price: $15.26

Open All

Select Group and TAV

< Previous Next >

TAV: 857.03.00 - INSTRUMENT PANEL

2016 Lamborghini AVENTADOR SV LP750-4 ROADSTER AUSTRALIA INSTRUMENT PANEL (857.03.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Aventador Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	472858794C	LINING SOTTOPLANCIA LP DASH PANEL TRIM (LEATHER UPHOLSTERY, SUPPLY VIN- RHD)	1 req	Avail to order Our Price: $1,462.66
1	472858794E	DASH PANEL TRIM (ALCANTARA UPHOLSTERY, SUPPLY VIN- RHD)	1 req
2	472941788A	TRIM TRIM ( RHD)	1 req	Avail to order Our Price: $21.96
3	472857221A	MOLDING,DASHBOARD TRIM STRIP FOR DASH PANEL, FOIL SEALED (STANDARD- RHD)	1 req	Avail to order Our Price: $84.84
3	472857221B	TRIM STRIP FOR DASH PANEL, FOIL SEALED (CARBON INTERIOR- RHD)	1 req
4	470819705	VENT,SIDE AIR VENT FOR DOOR WINDOW (LEFT)	1 req	Avail to order Our Price: $253.37
4	470819706	VENT,SIDE AIR VENT FOR DOOR WINDOW (RIGHT)	1 req	Avail to order Our Price: $253.37
5	N91136801	HEXAGON SOCKET HEAD PANEL BOLT HEXAGON SOCKET HEAD PANEL BOLT (4,2X11)	4 req	Current Stock: 11 Our Price: $0.42
6	N10588402	CLAMPING WASHER SPEED NUT	1 req	Avail to order Our Price: $0.32
7	N10586401	HEXALOBULAR SOCKET OVAL HEXAGON SOCKET HEAD BOLT (M5X10)	2 req	Current Stock: 13 Our Price: $1.17
8	N90981701	SPEED NUT SPEED NUT (M5X21.0X15.3)	6 req	Current Stock: 20 Our Price: $1.04
9	N10738101	HEXALOBULAR SOCKET HEX SOCKET HEAD BOLT (COMBI) (M5X16)	6 req	Current Stock: 6 Our Price: $0.99
10	470857565	COVER COVER (LEATHER UPHOLSTERY, SUPPLY VIN-LEFT)	1 req	Avail to order Our Price: $335.11
10	470857566	COVER COVER (LEATHER UPHOLSTERY, SUPPLY VIN-RIGHT)	1 req	Avail to order Our Price: $335.11
11	1J0858137B	CLAMP CLIP	6 req	Avail to order Our Price: $1.18
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
