2014 AVENTADOR LP720-4 COUPE 50th - ARABIA

Group :

Tav :

Maintenance Parts:

Common repairs and upgrades

PN	Item
900000170	TUTELA CS SPEED FLUID -OIL LIFTING SYSTEM 1 LITER TUTELA CS SPEED FLUID -OIL LIFTING SYSTEM 1 LITER	Current Stock: 8 Our Price: $61.26
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO	Current Stock: 7 Our Price: $27.66
4T0803615	TOWING EYE TOWING EYE OLD PN 400803615	Current Stock: 4 Our Price: $58.32
G052529A2	TRANSMISSION FLUID TRANSMISSION FLUID	Current Stock: 14 Our Price: $71.47

Drivetrain

PN	Item	Diagram
07M115561B	SPIN-ON FILTER CARTUCCIS FIL.OLIO SPIN-ON FILTER CARTUCCIS FIL.OLIO		Current Stock: 9 Our Price: $201.60

Fuel-Air

PN	Item	Diagram
4D0906321C	FUEL FILTER FILTER		Avail to order Our Price: $42.69
470133843A	FILTER ELEMENT FILTER ELEMENT		Current Stock: 2 Our Price: $157.26

Ignition

PN	Item	Diagram
470905619A	SPARK PLUG SPARK PLUG		Avail to order Our Price: $99.97
470905619C	SPARK PLUG SPARK PLUG		Avail to order Our Price: $100.13

Misc

PN	Item
6Q0819653B	CABIN FILTER AVENTADOR CABIN FILTER	Current Stock: 2 Our Price: $61.49
400093050D	CTEK US-CD BATTERY CHARGER INPUT 110-120VAC OUTPUT MAX 4.3A, 12V BACK DRAIN LESS THAN 1.5AM/MONTH	Avail to order Our Price: $417.39
0R0000149	CLEANER FLUID 250ML CLEANER FLUID	Current Stock: 1 Our Price: $82.84

Sensors

PN	Item
4E0927803	ABS SENSOR LEFT ABS SENSOR LEFT	Current Stock: 2 Our Price: $47.65
7PP907275F	WHEEL ELECTRONICS WHEEL ELECTRONICS	Avail to order Our Price: $185.62
06A906262AT	OXYGEN SENSOR O2 SENSOR - LAMBDA PROBE OXYGEN SENSOR O2 SENSOR - LAMBDA PROBE	Current Stock: 22 Our Price: $153.21
4E0927803F	RH ABS SENSOR SPEED SENSOR	Avail to order Our Price: $143.73
4E0927804F	LH ABS SENSOR SPEED SENSOR	Current Stock: 1 Our Price: $143.73
4H0959126A	AC PRESSURE SENSOR A/C PRESSURE SENSOR,	Avail to order Our Price: $79.44

Tools and Tookits

PN	Item
470012257	DEMOUNTING HOOK DEMOUNTING HOOK	Avail to order Our Price: $611.31
69795000805	V12 VALVE SEALING FITTING TOOL V12 VALVE SEALING FITTING TOOL	Avail to order Our Price: $434.20
69195290	TOOL KIT FOR REMOVING THE GRILLE TOOL KIT FOR REMOVING THE GRILLE BUMPER NET TOOL	Avail to order Our Price: $474.62
61195080	TOOL FOR TOP DEAD CENTER LP700 TOP DEAD CENTER GAUGE. TOOL FOR TOP DEAD CENTER LP700	Avail to order Our Price: $314.66
wheeltool	WHEEL INSTALL TOOL SCREWS INTO HUB FOR EASY INSTALLATION.	Current Stock: 91 Our Price: $15.26

Open All

Select Group and TAV

< Previous Next >

TAV: 103.02.00 - OIL SUMP

2014 Lamborghini AVENTADOR LP720-4 COUPE 50th ARABIA OIL SUMP (103.02.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Aventador Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	N10709401	HEXAGON FLANGE SCREW BM8X120X80	1 req	Avail to order Our Price: $6.55
2	N10689302	12-POINT SOCKET FLANGE BOLT SCREW M8X25	24 req	Avail to order Our Price: $3.36
3	07M103121C	GASKET SEAL	1 req	Avail to order Our Price: $17.71
4	N91084501	O RING FOR OIL SUMP SEAL RING	1 req	Current Stock: 6 Our Price: $8.05
5	07M103627	OIL DRAIN PLUG PLUG	1 req	Current Stock: 3 Our Price: $44.90
6	022103139B	SLEEVE BUSHING	6 req	Avail to order Our Price: $8.59
7		95 DIAMETER CYLINDER LINER (NOT AVAILABLE)	0 req
8		SEAL RING (NOT AVAILABLE)	0 req
9	07M103937A	CAP PLUG	1 req	Avail to order Our Price: $285.78
10	07M115540	SPRAY JET VALVE VALVE	1 req	Avail to order Our Price: $271.79
11	WHT000406	WASHER WASHER	1 req	Avail to order Our Price: $3.89
12	N91014801	O RING SEAL RING	14 req	Current Stock: 8 Our Price: $1.83
13	N90111301	O RING SEAL RING	14 req	Current Stock: 4 Our Price: $0.35
14	N90443601	O-RING SEAL RING	2 req	Avail to order Our Price: $9.38
15	050121113B	THERMOSTAT WATER THERMOSTAT	2 req	Avail to order Our Price: $75.10
16	07M103649	SEAL SEAL	2 req	Avail to order Our Price: $26.92
17	N91084801	HEXALOBULAR SOCKET SCREW M6X18	8 req	Current Stock: 18 Our Price: $1.01
18	07M121121E	COVER COVER	2 req	Avail to order Our Price: $814.58
19	07L919561B	OIL PRESSURE GAUGE SENDER ENGINE OIL PRESSURE SENSOR	1 req	Avail to order Our Price: $919.17
20	06H906433C	PULSE GENERATOR CRANKSHAFT POSITION SENSOR	1 req	Avail to order Our Price: $97.68
21	N91096702	HEXALOBULAR SOCKET SCREW M6X16	1 req	Avail to order Our Price: $1.63
22		SUPPORT (VALID UP TO MODEL YEAR 12 )	0 req
23		SCREW M6X16 (VALID UP TO MODEL YEAR 12 )	0 req
24	079907601	PULSE GENERATOR TRANSMISSION RANGE SENSOR	1 req	Avail to order Our Price: $192.97
25	N91096702	HEXALOBULAR SOCKET SCREW M6X16	1 req	Avail to order Our Price: $1.63
26	07M103158E	NOZZLE NOZZLE FOR PISTONS COOLING	7 req	Avail to order Our Price: $1,554.05
27	N10456103	PAN HEAD BOLT M4X10.0 SCREW M4X10	1 req	Avail to order Our Price: $0.60
28	059919523A	TEMPERATURE SENDER TEMPERATURE SENSOR	2 req	Current Stock: 6 Our Price: $69.79
29	470971729	PROTECTIVE HOSE CONNETT.PRESS.OLIO HEATING PROTECTION SHEATH	1 req	Avail to order Our Price: $45.79
30	N10562301	CLAMP CLAMP	1 req	Avail to order Our Price: $1.57
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
