2014 AVENTADOR LP700-4 ROADSTER - ARABIA

Group :

Tav :

Maintenance Parts:

Common repairs and upgrades

PN	Item
900000170	TUTELA CS SPEED FLUID -OIL LIFTING SYSTEM 1 LITER TUTELA CS SPEED FLUID -OIL LIFTING SYSTEM 1 LITER	Current Stock: 6 Our Price: $61.26
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO	Current Stock: 7 Our Price: $27.66
4T0803615	TOWING EYE TOWING EYE OLD PN 400803615	Current Stock: 5 Our Price: $58.32
G052529A2	TRANSMISSION FLUID TRANSMISSION FLUID	Current Stock: 14 Our Price: $71.47

Drivetrain

PN	Item	Diagram
07M115561B	SPIN-ON FILTER CARTUCCIS FIL.OLIO SPIN-ON FILTER CARTUCCIS FIL.OLIO		Current Stock: 13 Our Price: $201.60

Fuel-Air

PN	Item	Diagram
4D0906321C	FUEL FILTER FILTER		Avail to order Our Price: $42.69
470133843A	FILTER ELEMENT FILTER ELEMENT		Current Stock: 2 Our Price: $157.26

Ignition

PN	Item	Diagram
470905619A	SPARK PLUG SPARK PLUG		Avail to order Our Price: $99.97
470905619C	SPARK PLUG SPARK PLUG		Avail to order Our Price: $100.13

Misc

PN	Item
6Q0819653B	CABIN FILTER AVENTADOR CABIN FILTER	Current Stock: 2 Our Price: $61.49
400093050D	CTEK US-CD BATTERY CHARGER INPUT 110-120VAC OUTPUT MAX 4.3A, 12V BACK DRAIN LESS THAN 1.5AM/MONTH	Avail to order Our Price: $417.39
0R0000149	CLEANER FLUID 250ML CLEANER FLUID	Current Stock: 1 Our Price: $82.84

Sensors

PN	Item
4E0927803	ABS SENSOR LEFT ABS SENSOR LEFT	Current Stock: 2 Our Price: $47.65
470998161	COLD JOINT KIT SET OF TWO 470919197C	Avail to order Our Price: $935.21
06A906262AT	OXYGEN SENSOR O2 SENSOR - LAMBDA PROBE OXYGEN SENSOR O2 SENSOR - LAMBDA PROBE	Current Stock: 24 Our Price: $153.21
4E0927803F	RH ABS SENSOR SPEED SENSOR	Avail to order Our Price: $143.73
4E0927804F	LH ABS SENSOR SPEED SENSOR	Current Stock: 1 Our Price: $143.73
4H0959126A	AC PRESSURE SENSOR A/C PRESSURE SENSOR,	Avail to order Our Price: $79.44
7PP907275F	WHEEL ELECTRONICS WHEEL ELECTRONICS	Avail to order Our Price: $185.62

Tools and Tookits

PN	Item
470012257	DEMOUNTING HOOK DEMOUNTING HOOK	Current Stock: 1 Our Price: $611.31
69795000805	V12 VALVE SEALING FITTING TOOL V12 VALVE SEALING FITTING TOOL	Avail to order Our Price: $434.20
69195290	TOOL KIT FOR REMOVING THE GRILLE TOOL KIT FOR REMOVING THE GRILLE BUMPER NET TOOL	Avail to order Our Price: $474.62
61195080	TOOL FOR TOP DEAD CENTER LP700 TOP DEAD CENTER GAUGE. TOOL FOR TOP DEAD CENTER LP700	Avail to order Our Price: $314.66
wheeltool	WHEEL INSTALL TOOL SCREWS INTO HUB FOR EASY INSTALLATION.	Current Stock: 92 Our Price: $15.26

Open All

Select Group and TAV

< Previous Next >

TAV: 409.03.00 - FRONT DIFFERENTIAL ASSEMBLY

2014 Lamborghini AVENTADOR LP700-4 ROADSTER ARABIA FRONT DIFFERENTIAL ASSEMBLY (409.03.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Aventador Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	01S409021K	DIFFERENTIAL VA FRONT DIFFERENTIAL	1 req	Avail to order Our Price: $10,214.00
2	420599285	CROSS MEMBER SUPPORT	1 req	Avail to order Our Price: $195.19
3	01S599288A	CROSSMEMBER SUPPORT	1 req	Avail to order Our Price: $390.37
4	N10431201	SUPPORT CLAMP	1 req	Avail to order Our Price: $1.77
5	N10687201	12-POINT SOCKET SCREW M10X45	3 req	Avail to order Our Price: $3.28
6	N10736901	HEXAGON FLANGE BOLT SCREW M12X1,5X95	2 req	Avail to order Our Price: $83.07
7	N10198301	LUG-TYPE HOSE CLAMP	2 req	Current Stock: 1 Our Price: $3.10
8	N10689301	12-POINT SOCKET SCREW M8X25	4 req	Current Stock: 4 Our Price: $3.36
9	N10640301	HEXAGON FLANGE SCREW M12X1,5X100X90	2 req	Avail to order Our Price: $7.53
10	01S409341A	VENTILATION VENT PIPE	1 req	Avail to order Our Price: $975.14
11	01S409831B	VENTILATION VENT PIPE	1 req	Avail to order Our Price: $47.29
12	0B9525151	GEARBOX OIL DRAIN PLUG MAGNETIC PLUG M18X1,5 (2 MAGNETIC PLUGS M18X1,5 WITH WASHER PER SERVICE INSPECTION)	2 req	Avail to order Our Price: $25.06
13	0B9525820	GEAR BOX PLUG WITH WASHER FOR SERVICE INSPECTION PLUG M18X1,5 (2 PLUGS M18X1,5 WITH WASHER PER SERVICE INSPECTION)	2 req	Avail to order Our Price: $15.50
14	7H0525337	BEARING BONDED RUBBER BUSH	2 req	Avail to order Our Price: $55.26
15	01S409085	RADIAL SHAFT SEAL OIL SEAL 40-52-7/11	1 req	Avail to order Our Price: $134.08
16	087409360	SCREW SCREW M8X68,4	2 req	Avail to order Our Price: $7.17
17	01S409086	RADIAL SHAFT SEAL OIL SEAL 40-54-7/11	1 req	Avail to order Our Price: $72.18
18	02D525118B	ANGLED PIPE CONNECTOR	2 req	Avail to order Our Price: $16.47
19	8E0599257K	BEARING BONDED RUBBER BUSH	2 req	Avail to order Our Price: $26.48
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
