2014 AVENTADOR LP700-4 ROADSTER - ARABIA

Maintenance Parts:

Drivetrain

PN	Item	Diagram
07M115561B	SPIN-ON FILTER CARTUCCIS FIL.OLIO SPIN-ON FILTER CARTUCCIS FIL.OLIO		Current Stock: 2 Our Price: $48.56

Fuel-Air

PN	Item	Diagram
4D0906321C	FUEL FILTER FILTER		Avail to order Our Price: $40.12
470133843A	FILTER ELEMENT FILTER ELEMENT		Current Stock: 1 Our Price: $163.31

Ignition

PN	Item	Diagram
470905619	SEE PN 470905619C SPARK PLUG		Avail to order Our Price: $101.44
470905619A	SPARK PLUG SPARK PLUG		Avail to order Our Price: $104.03

Misc

PN	Item
900000382	NLA use PN 400093050D for USA replacement	Avail to order Our Price: $190.57
900000381	NLA (No Longer Available) Comes with Eyelet connects, Clamp connectors and Cigar Lighter Adapter.	Avail to order Our Price: $190.57
N0300574	KEY - Spanner Murcielago-Aventador-Huracan Wrench Spanner Murcielago-Aventador-Huracan	Avail to order Our Price: $9.19
6Q0819653B	ODOR FILTER ODOR FILTER	Avail to order Our Price: $63.53
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month	Avail to order Our Price: $317.22

Sensors

PN	Item
4E0927804	SEE PN 4E0927804F ABS SENSOR RIGHT	Avail to order Our Price: $45.07
4E0927803	ABS SENSOR LEFT ABS SENSOR LEFT	Current Stock: 2 Our Price: $45.07
470998161	COLD JOINT KIT Set of two 470919197C	Avail to order Our Price: $924.67

Tools and Tookits

PN	Item	Diagram
470012257	DEMOUNTING HOOK DEMOUNTING HOOK		Current Stock: 1 Our Price: $253.70

Open All

Select Group and TAV

< Previous Next >

TAV: 407.01.00 - FRONT ARMS

2014 Lamborghini AVENTADOR LP700-4 ROADSTER ARABIA FRONT ARMS (407.01.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Aventador Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1		FRONT HUB CARRIER (SEE TABLE 407.02.00)	0 req
2	WHT005396	TAP END STUD STUD BOLT M10X1,25XM10X45	8 req	Avail to order Our Price: $29.92
3	N10272302	HEX.NUT W/ FLANGE NUT M10	16 req	Avail to order Our Price: $2.37
4	WHT004898	HEXAGON FLANGE NUT W.WASHER NUT M14X1,5	4 req	Current Stock: 14 Our Price: $6.24
5	N10736901	HEXAGON FLANGE BOLT SCREW M12X1,5X95	2 req	Avail to order Our Price: $78.50
6	N10106402	HEX.NUT W/FLANGE LOCKING ELEM. NUT M12X1,5	4 req	Avail to order Our Price: $2.52
7	470407505G	CONTROL ARM,FRONT ANT.SUP.SX CRASH PART LH UPPER ARM (THIS ITEM MAY HAVE RESTRICTIONS - CONTACT LAMBOSTUFF/BULLSTUFF)	1 req	Avail to order Our Price: $1,119.38
7	470407506G	CONTROL ARM,FRONT ANT. SUP.DX RH UPPER ARM (THIS ITEM MAY HAVE RESTRICTIONS - CONTACT LAMBOSTUFF/BULLSTUFF)	1 req	Avail to order Our Price: $1,119.38
8	N91055501	HEXALOBULAR SOCKET SCREW M5POWX12	4 req	Avail to order Our Price: $2.00
9	N10714801	HEXALOBULAR SOCKET SCREW M6X18	6 req	Avail to order Our Price: $2.00
10	N10434301	PAN HEAD BOLT SCREW M5X10	4 req	Avail to order Our Price: $2.00
11	N01118312	HEX.HEAD CLAMPING NUT NUT M6	2 req	Current Stock: 4 Our Price: $2.01
12	N10640301	HEXAGON FLANGE SCREW BM12X1,5X100X90	2 req	Avail to order Our Price: $7.39
13	470407151H	TRACK CONTROL ARM CRASH PART LH LOWER ARM (THIS ITEM MAY HAVE RESTRICTIONS - CONTACT LAMBOSTUFF/BULLSTUFF)	1 req	Avail to order Our Price: $1,578.61
13	470407152H	TRACK CONTROL ARM RH LOWER ARM (THIS ITEM MAY HAVE RESTRICTIONS - CONTACT LAMBOSTUFF/BULLSTUFF)	1 req	Avail to order Our Price: $1,578.61
14	WHT005397	TAP END STUD STUD BOLT M10X1,25XM10X39	8 req	Avail to order Our Price: $40.33
15	470407203	BACKING PLATE 1 MM SHIM	4 req	Avail to order Our Price: $95.58
15	470407203A	BACKING PLATE 5.0 MM SHIM	4 req	Avail to order Our Price: $95.58
15	470407203B	BACKING PLATE 3 MM SHIM	4 req	Avail to order Our Price: $85.68
16	470413383B	PUSH ROD STRUT,BUMPER	2 req	Avail to order Our Price: $288.46
17	470971003	CABLE HOLDER LH BRACKET	1 req	Avail to order Our Price: $49.16
17	470971004	CABLE HOLDER RH BRACKET	1 req	Avail to order Our Price: $49.16
18	470611845	BRACKET,BRAKE HOSE BRACKET	2 req	Avail to order Our Price: $24.05
19	470611851A	BRACKET,BRAKE LINE LH BRACKET	1 req	Avail to order Our Price: $32.80
19	470611852A	BRACKET,BRAKE LINE RH BRACKET	1 req	Avail to order Our Price: $32.80
20	470941273	SENSOR,HEADLIGHT- LH SENSOR	1 req	Avail to order Our Price: $400.39
20	470941274	SENSOR,HEADLIGHT- RH SENSOR	1 req	Avail to order Our Price: $419.06
21	470941287	RETAINING PART LH BRACKET	1 req	Avail to order Our Price: $17.94
21	470941288	RETAINING PART RH BRACKET	1 req	Avail to order Our Price: $17.94
22		SHOCK ABSORBER (SEE TABLE 411.01.00)	0 req
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
