Maintenance Parts:

Drivetrain

PN Item Diagram
07M115561B SPIN-ON FILTER CARTUCCIS FIL.OLIO
SPIN-ON FILTER CARTUCCIS FIL.OLIO
Avail to order
Our Price: $50.22
SPIN-ON FILTER    CARTUCCIS FIL.OLIO

Fuel-Air

PN Item Diagram
470133843A FILTER ELEMENT
FILTER ELEMENT
Current Stock: 1
Our Price: $168.88
FILTER ELEMENT
4D0906321C FUEL FILTER
FILTER
Avail to order
Our Price: $41.62
FUEL FILTER

Ignition

PN Item Diagram
470905619 SEE PN 470905619C
SPARK PLUG
Avail to order
Our Price: $104.90
SEE PN 470905619C
470905619A SPARK PLUG
SPARK PLUG
Avail to order
Our Price: $107.58

Misc

PN Item Diagram
400093050D CTEK US-CD BATTERY CHARGER
Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month
Avail to order
Our Price: $317.22
CTEK US-CD BATTERY CHARGER
6Q0819653B ODOR FILTER
ODOR FILTER
Avail to order
Our Price: $65.70
ODOR FILTER
900000381 NLA (No Longer Available)
Comes with Eyelet connects, Clamp connectors and Cigar Lighter Adapter.
Avail to order
Our Price: $190.57
NLA (No Longer Available)
900000382 NLA
use PN 400093050D for USA replacement
Avail to order
Our Price: $190.57
NLA

Sensors

PN Item Diagram
470998161 COLD JOINT KIT
Set of two 470919197C
Avail to order
Our Price: $969.58
4E0927803 ABS SENSOR LEFT
ABS SENSOR LEFT
Current Stock: 2
Our Price: $46.75
ABS SENSOR LEFT
4E0927804 SEE PN 4E0927804F
ABS SENSOR RIGHT
Avail to order
Our Price: $46.75
SEE PN 4E0927804F

Tools and Tookits

PN Item Diagram
470012257 DEMOUNTING HOOK
DEMOUNTING HOOK
Current Stock: 1
Our Price: $253.70
DEMOUNTING HOOK
Open All

Select Group and TAV

TAV: 103.01.00 - CRANKCASE

2013 Lamborghini AVENTADOR LP700-4 ROADSTER CANADA CRANKCASE (103.01.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Aventador Parts Manual. Sorry, but there are NO exceptions.

Item # PN Item Qty Req *
1 STUD BOLT MJ11X100,15 (NOT AVAILABLE) 0 req
2 STUD BOLT MJ11X150,6 (NOT AVAILABLE) 0 req
3 BUSHING (NOT AVAILABLE) 0 req
4 STUD BOLT M8-4H6HX165 (NOT AVAILABLE) 0 req
5 STUD BOLT MJ12-4H6HX182,50 (NOT AVAILABLE) 0 req
6 WASHER (NOT AVAILABLE) 0 req
7 NUT M8 (NOT AVAILABLE) 0 req
8 WASHER (NOT AVAILABLE) 0 req
9 NUT M12 (NOT AVAILABLE) 0 req
10 N0138485 SEALING RING
WASHER (4 WASHERS PER SERVICE INSPECTION)
12 req Current Stock: 1
Our Price: $2.00
SEALING RING
11 07M103519 PLUG
PLUG M16 (4 PLUGS M16 PER SERVICE INSPECTION)
12 req Avail to order
Our Price: $72.66
PLUG
12 07M103485A OIL FILLER CAP
PLUG
1 req Avail to order
Our Price: $150.37
13 WHT002159 o ring
SEAL RING
1 req Avail to order
Our Price: $9.23
o ring
14 N10712702 SCREW PLUG
PLUG M30
1 req Avail to order
Our Price: $39.91
15 N91069701 O-RING
SEAL RING
1 req Current Stock: 5
Our Price: $4.99
O-RING
16 WHT005250 HEXAGON HEAD BOLT
PLUG M16
3 req Avail to order
Our Price: $26.58
17 WHT003049 Copper Washer 26.25x32x1.5
WASHER
3 req Avail to order
Our Price: $6.03
Copper Washer 26.25x32x1.5
18 07M103035A PLUG
PLUG M26X1,5
3 req Avail to order
Our Price: $20.18
19 ENGINE BLOCK (NOT AVAILABLE) 0 req

* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
