2012 AVENTADOR LP700-4 COUPE - EUROPE

Maintenance Parts:

Belts

PN	Item	Diagram
07M903137C	RIBBED V-BELT RIBBED V-BELT		Avail to order Our Price: $41.07

Brakes

PN	Item	Diagram
470698151	FRONT BRAKE PAD SET FRONT BRAKE PAD SET		Current Stock: 2 Our Price: $1,666.39
470698451	REAR BRAKE PAD SET REAR BRAKE PAD SET		Current Stock: 2 Our Price: $1,376.26

Drivetrain

PN	Item
07M105269C	SEE PN 07M105269D BALANCED CLUTCH MECHANISM	Avail to order Our Price: $8,288.36
07M115561	see PN 07M115561B Oil Filter Cartridge	Avail to order Our Price: $50.22
0CE141671A	CONCENTRIC SLAVE CYLINDER LP700 CONCENTRIC SLAVE CYLINDER	Avail to order Our Price: $1,451.55
0CE311675A	CLUTCH SENSOR - MASTER CYLINDER CLUTCH SENSOR - MASTER CYLINDER	Current Stock: 1 Our Price: $1,107.64
079905381	TRANSDUCER POS. TRANSDUCER POS.	Avail to order Our Price: $448.13
07M115561B	SPIN-ON FILTER CARTUCCIS FIL.OLIO SPIN-ON FILTER CARTUCCIS FIL.OLIO	Current Stock: 1 Our Price: $50.22

Fuel-Air

PN	Item	Diagram
4D0906321C	FUEL FILTER FILTER		Avail to order Our Price: $41.62
470133843A	FILTER ELEMENT FILTER ELEMENT		Current Stock: 1 Our Price: $168.88

Fuses-Bulbs-Relays

PN	Item	Diagram
N01713118	FUSE Please Check your Part Manual for a Description		Current Stock: 18 Our Price: $2.00
N0177532	LAMP BULB LAMP BULB		Avail to order Our Price: $2.00

Ignition

PN	Item
7P0915105	BATTERY BATTERY	Avail to order Our Price: $587.70
470905619	SEE PN 470905619C SPARK PLUG	Avail to order Our Price: $104.90
470905619A	SPARK PLUG SPARK PLUG	Avail to order Our Price: $107.58

Misc

PN	Item
900000382	NLA use PN 400093050D for USA replacement	Avail to order Our Price: $190.57
900000381	NLA (No Longer Available) Comes with Eyelet connects, Clamp connectors and Cigar Lighter Adapter.	Avail to order Our Price: $190.57
0R8340113	AVENTADOR CENTRAL LOCK CONVERSION KIT AVENTADOR CENTRAL LOCK CONVERSION KIT	Avail to order Our Price: $9,143.69
470898013	BLACK 73X CENTRAL LOCK CONVERSION KIT BLACK 73X CENTRAL LOCK CONVERSION KIT	Avail to order Our Price: $9,143.69
6Q0819653B	ODOR FILTER ODOR FILTER	Avail to order Our Price: $65.70
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month	Avail to order Our Price: $317.22

Sensors

PN	Item
07L905163A	SEE PN 07L905163C PHASE SENSOR	Avail to order Our Price: $37.90
4F0907275D	See PN 7PP907275F WHEEL ELECTRONICS	Avail to order Our Price: $203.22
059919523A	TEMPERATURE SENDER TEMPERATURE SENDER	Current Stock: 6 Our Price: $68.48
07L919561B	OIL PRESSURE GAUGE SENDER OIL PRESSURE GAUGE SENDER	Avail to order Our Price: $890.28
06A906262AT	O2 SENSOR-LAMBDA PROBE LAMBDA PROBE	Avail to order Our Price: $149.62
4E0927804	SEE PN 4E0927804F ABS SENSOR RIGHT	Avail to order Our Price: $46.75
4E0927803	ABS SENSOR LEFT ABS SENSOR LEFT	Current Stock: 2 Our Price: $46.75
470998161	COLD JOINT KIT Set of two 470919197C	Avail to order Our Price: $969.58

Tools and Tookits

PN	Item	Diagram
470012257	DEMOUNTING HOOK DEMOUNTING HOOK		Current Stock: 1 Our Price: $253.70

Open All

Select Group and TAV

< Previous Next >

TAV: 906.01.00 - SECONDARY AIR SYSTEM

2012 Lamborghini AVENTADOR LP700-4 COUPE EUROPE SECONDARY AIR SYSTEM (906.01.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Aventador Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
0	0R8340017	KIT PROTECTION HEAT SHIELD + PUMP (ORDERABLE FOR CAMPAING NR L834-A.06.12)	1 req	Avail to order Our Price: $434.91
1	400998075	Secondary air pump HEAT SHIELD + PUMP	2 req	Avail to order Our Price: $625.29
1	400998075	Secondary air pump HEAT SHIELD/PUMP KIT	2 req	Avail to order Our Price: $625.29
2	N10451408	HEXALOBULAR SOCKET SCREW M6X16	8 req	Avail to order Our Price: $2.00
2	N10451408	HEXALOBULAR SOCKET SCREW M6X16	8 req	Avail to order Our Price: $2.00
3	400127217	SECURING CLIP CLAMP	6 req	Avail to order Our Price: $2.00
3	400127217	SECURING CLIP CLAMP	6 req	Avail to order Our Price: $2.00
4	N02214812	HEX.HEAD CLAMPING NUT M6	6 req	Avail to order Our Price: $2.09
4	N02214812	HEX.HEAD CLAMPING NUT M6	6 req	Avail to order Our Price: $2.09
5	WHT002961	WASHER WASHER	10 req	Current Stock: 39 Our Price: $2.00
5	WHT002961	WASHER WASHER	10 req	Current Stock: 39 Our Price: $2.00
6	N91054001	HEXALOBULAR SOCKET SCREW M6X22	9 req	Avail to order Our Price: $2.00
6	N91054001	HEXALOBULAR SOCKET SCREW M6X22	9 req	Avail to order Our Price: $2.00
7	N10451408	HEXALOBULAR SOCKET SCREW M6X16	4 req	Avail to order Our Price: $2.00
7	N10451408	HEXALOBULAR SOCKET SCREW M6X16	4 req	Avail to order Our Price: $2.00
8	470131611B	HOSE PIPE	1 req	Avail to order Our Price: $736.94
8	470131611B	HOSE PIPE	1 req	Avail to order Our Price: $736.94
9	470131611C	HOSE PIPE	1 req	Avail to order Our Price: $736.94
9	470131611C	HOSE PIPE	1 req	Avail to order Our Price: $736.94
10	N0206253	HOLDING CLIP CLAMP	5 req	Current Stock: 2 Our Price: $2.01
10	N0206253	HOLDING CLIP CLAMP	5 req	Current Stock: 2 Our Price: $2.01
11	06A131120D	GASKET SEAL	4 req	Current Stock: 2 Our Price: $8.04
11	06A131120D	GASKET SEAL	4 req	Current Stock: 2 Our Price: $8.04
12	470906613A	BRACKET,SAP SUPPORT	1 req	Avail to order Our Price: $43.70
12	470906613A	BRACKET,SAP SUPPORT	1 req	Avail to order Our Price: $43.70
13	470906617A	BRACKET SUPPORT	1 req	Avail to order Our Price: $25.39
13	470906617A	BRACKET SUPPORT	1 req	Avail to order Our Price: $25.39
14	07L131119	ADAPTER CONNECTOR	2 req	Avail to order Our Price: $17.50
14	07L131119	ADAPTER CONNECTOR	2 req	Avail to order Our Price: $17.50
15	07L131101F	COMBINATION VALVE SECONDARY AIR VALVE	2 req	Avail to order Our Price: $179.40
15	07L131101F	COMBINATION VALVE SECONDARY AIR VALVE	2 req	Avail to order Our Price: $179.40
16	470133898A	TUBE,SECONDARY AIR PIPE	1 req	Avail to order Our Price: $201.74
16	470133898A	TUBE,SECONDARY AIR PIPE	1 req	Avail to order Our Price: $201.74
17	470133897B	TUBE,SECONDARY AIR PIPE	1 req	Avail to order Our Price: $208.43
17	470133897B	TUBE,SECONDARY AIR PIPE	1 req	Avail to order Our Price: $208.43
18	07L133579	BRANCH TUBE CONNECTOR	1 req	Current Stock: 8 Our Price: $2.23
18	07L133579	BRANCH TUBE CONNECTOR	1 req	Current Stock: 8 Our Price: $2.23
19	470131845	HOSE PIPE	1 req	Avail to order Our Price: $102.29
19	470131845	HOSE PIPE	1 req	Avail to order Our Price: $102.29
20	470131846	HOSE PIPE	1 req	Avail to order Our Price: $47.87
20	470131846	HOSE PIPE	1 req	Avail to order Our Price: $47.87
21	470131853	HOSE PIPE	1 req	Avail to order Our Price: $20.85
21	470131853	HOSE PIPE	1 req	Avail to order Our Price: $20.85
22	06K906052	PRESSURE SENSOR SENSOR	2 req	Avail to order Our Price: $270.22
22	06K906052	PRESSURE SENSOR SENSOR	2 req	Avail to order Our Price: $270.22
23	07M133106A	HEAT SHIELD HEAT SHIELD	2 req	Avail to order Our Price: $108.54
23	07M133106A	HEAT SHIELD HEAT SHIELD	2 req	Avail to order Our Price: $108.54
24		HEAT SHIELD (CANNOT BE SOLD SEPARATELY - SEE REF. 1)	2 req
24		HEAT SHIELD (CANNOT BE SOLD SEPARATELY - SEE REF. 1)	2 req
25	470906325A	RETAINING PART LEFT HEAT SHIELD	1 req	Avail to order Our Price: $47.12
26	470906294A	RETAINING PART RIGHT HEAT SHIELD	1 req	Avail to order Our Price: $108.38
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
