2012 AVENTADOR LP700-4 COUPE - EUROPE

Maintenance Parts:

Belts

PN	Item	Diagram
07M903137C	RIBBED V-BELT RIBBED V-BELT		Avail to order Our Price: $42.26

Brakes

PN	Item	Diagram
470698151	FRONT BRAKE PAD SET FRONT BRAKE PAD SET		Current Stock: 2 Our Price: $1,718.46
470698451	REAR BRAKE PAD SET REAR BRAKE PAD SET		Current Stock: 2 Our Price: $1,416.43

Common repairs and upgrades

PN	Item
900000170	Tutela CS Speed Fluid -Oil Lifting System 1 liter Tutela CS Speed Fluid -Oil Lifting System 1 liter	Avail to order Our Price: $67.85
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO	Current Stock: 2 Our Price: $22.44
4T0803615	Towing Eye TOWING EYE previous part number 400803615	Avail to order Our Price: $47.87

Drivetrain

PN	Item
07M105269C	SEE PN 07M105269D BALANCED CLUTCH MECHANISM	Avail to order Our Price: $8,541.56
07M115561	see PN 07M115561B Oil Filter Cartridge	Avail to order Our Price: $51.78
0CE311675A	CLUTCH SENSOR - MASTER CYLINDER CLUTCH SENSOR - MASTER CYLINDER	Current Stock: 1 Our Price: $1,140.39
07M115561B	SPIN-ON FILTER CARTUCCIS FIL.OLIO SPIN-ON FILTER CARTUCCIS FIL.OLIO	Current Stock: 1 Our Price: $104.15
0CE141671A	CONCENTRIC SLAVE CYLINDER LP700 CONCENTRIC SLAVE CYLINDER	Avail to order Our Price: $1,496.20
079905381	TRANSDUCER POS. TRANSDUCER POS.	Avail to order Our Price: $463.01

Fuel-Air

PN	Item	Diagram
4D0906321C	FUEL FILTER FILTER		Avail to order Our Price: $41.62
470133843A	FILTER ELEMENT FILTER ELEMENT		Current Stock: 1 Our Price: $174.08

Fuses-Bulbs-Relays

PN	Item	Diagram
N01713118	FUSE FUSE		Current Stock: 18 Our Price: $2.00
N0177532	LAMP BULB LAMP BULB		Avail to order Our Price: $2.00

Ignition

PN	Item
7P0915105	BATTERY BATTERY	Avail to order Our Price: $604.06
470905619A	SPARK PLUG SPARK PLUG	Avail to order Our Price: $110.70
470905619C	Spark Plug Spark Plug	Avail to order Our Price: $106.98

Misc

PN	Item
6Q0819653B	CABIN FILTER CABIN FILTER	Avail to order Our Price: $65.70
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month	Avail to order Our Price: $317.22
0R8340113	AVENTADOR CENTRAL LOCK CONVERSION KIT AVENTADOR CENTRAL LOCK CONVERSION KIT	Avail to order Our Price: $9,238.38
470898013	BLACK 73X CENTRAL LOCK CONVERSION KIT BLACK 73X CENTRAL LOCK CONVERSION KIT	Avail to order Our Price: $9,238.38

Sensors

PN	Item
07L905163A	SEE PN 07L905163C PHASE SENSOR	Avail to order Our Price: $39.01
4F0907275D	See PN 7PP907275F WHEEL ELECTRONICS	Avail to order Our Price: $209.92
059919523A	TEMPERATURE SENDER TEMPERATURE SENDER	Current Stock: 6 Our Price: $70.57
07L919561B	OIL PRESSURE GAUGE SENDER OIL PRESSURE GAUGE SENDER	Avail to order Our Price: $917.08
06A906262AT	OXYGEN SENSOR O2 SENSOR - LAMBDA PROBE OXYGEN SENSOR O2 SENSOR - LAMBDA PROBE	Avail to order Our Price: $154.84
4E0927804	SEE PN 4E0927804F ABS SENSOR RIGHT	Avail to order Our Price: $48.16
4E0927803	ABS SENSOR LEFT ABS SENSOR LEFT	Current Stock: 2 Our Price: $48.16
7PP907275F	WHEEL ELECTRONICS WHEEL ELECTRONICS	Avail to order Our Price: $169.72
4H0959126A	AC PRESSURE SENSOR A/C PRESSURE SENSOR,	Avail to order Our Price: $80.25
470998161	COLD JOINT KIT Set of two 470919197C	Avail to order Our Price: $999.38

Tools and Tookits

PN	Item
470012257	DEMOUNTING HOOK DEMOUNTING HOOK	Current Stock: 1 Our Price: $253.70
69795000805	V12 VALVE SEALING FITTING TOOL V12 VALVE SEALING FITTING TOOL	Avail to order Our Price: $356.21
69195290	Tool kit for removing the grille Tool kit for removing the grille LP700 Bumper Net Tool	Avail to order Our Price: $389.40
61195080	TOOL FOR TOP DEAD CENTER LP700 SUPER DEAD CENTER GAUGE. TOOL FOR TOP DEAD CENTER LP700	Avail to order Our Price: $258.12

Open All

Select Group and TAV

< Previous Next >

TAV: 819.02.00 - DASHBOARD AIR PIPE

2012 Lamborghini AVENTADOR LP700-4 COUPE EUROPE DASHBOARD AIR PIPE (819.02.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Aventador Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	470819203	AIR OUTLET VENT DEFROSTER AIR CONVEYOR ASSEMBLY	1 req	Avail to order Our Price: $375.18
1	470819203	AIR OUTLET VENT DEFROSTER AIR CONVEYOR ASSEMBLY	1 req	Avail to order Our Price: $375.18
2	N91176801	SCREW SCREW TP5X10-R	12 req	Avail to order Our Price: $2.00
2	N91176801	SCREW SCREW TP5X10-R	12 req	Avail to order Our Price: $2.00
3	470819382	VENT CHANNEL AIR GUIDE	1 req	Avail to order Our Price: $43.55
3	470819382	VENT CHANNEL AIR GUIDE	1 req	Avail to order Our Price: $43.55
4	N10595002	HEXALOBULAR SOCKET SCREW M5X18	2 req	Avail to order Our Price: $2.00
4	N10595002	HEXALOBULAR SOCKET SCREW M5X18	2 req	Avail to order Our Price: $2.00
5	N91085101	HEXALOBULAR SOCKET SCREW M5X16	4 req	Current Stock: 16 Our Price: $2.00
5	N91085101	HEXALOBULAR SOCKET SCREW M5X16	4 req	Current Stock: 16 Our Price: $2.00
6	470819869	AIR DUCT LEFT AIR GUIDE	1 req	Avail to order Our Price: $174.94
6	470819869	AIR DUCT LEFT AIR GUIDE	1 req	Avail to order Our Price: $174.94
7	470819870	AIR DUCT RIGHT AIR GUIDE	1 req	Avail to order Our Price: $174.94
7	470819870	AIR DUCT RIGHT AIR GUIDE	1 req	Avail to order Our Price: $174.94
8	N10586401	HEXALOBULAR SOCKET SCREW M5X10	4 req	Current Stock: 13 Our Price: $2.00
8	N10586401	HEXALOBULAR SOCKET SCREW M5X10	4 req	Current Stock: 13 Our Price: $2.00
9	N10604701	FILLISTER HEAD SCREW ST4.8X9.5	2 req	Avail to order Our Price: $2.00
9	N10604701	FILLISTER HEAD SCREW ST4.8X9.5	2 req	Avail to order Our Price: $2.00
10	N90981701	SPEED NUT CLIP	9 req	Current Stock: 20 Our Price: $2.00
10	N90981701	SPEED NUT CLIP	9 req	Current Stock: 20 Our Price: $2.00
11	N10738101	HEXALOBULAR SOCKET SCREW M5X16	9 req	Current Stock: 6 Our Price: $2.00
11	N10738101	HEXALOBULAR SOCKET SCREW M5X16	9 req	Current Stock: 6 Our Price: $2.00
12	N10595002	HEXALOBULAR SOCKET SCREW M5X18	4 req	Avail to order Our Price: $2.00
12	N10595002	HEXALOBULAR SOCKET SCREW M5X18	4 req	Avail to order Our Price: $2.00
13	470819383	AIR OUTLET VENT AIR GUIDE	1 req	Avail to order Our Price: $115.98
13	470819383	AIR OUTLET VENT AIR GUIDE	1 req	Avail to order Our Price: $115.98
14	470819384	AIR OUTLET VENT AIR GUIDE	1 req	Avail to order Our Price: $166.00
14	470819384	AIR OUTLET VENT AIR GUIDE	1 req	Avail to order Our Price: $166.00
15	471864255	AIR DUCT AIR GUIDE	1 req	Avail to order Our Price: $160.05
15	471864255	AIR DUCT AIR GUIDE	1 req	Avail to order Our Price: $160.05
16	471864256	AIR DUCT AIR GUIDE	1 req	Avail to order Our Price: $160.05
16	471864256	AIR DUCT AIR GUIDE	1 req	Avail to order Our Price: $160.05
17	470819793	DEFROSTER JET AIR VENT	1 req	Avail to order Our Price: $191.31
17		FRESH AIR VENT (SEE TABLE. 857.03 rif. 4)	0 req
18		FRESH AIR VENT (SEE TABLE. 857.02 rif. 6)	0 req
18	470819635A	DEFROSTER JET AIR VENT	1 req	Avail to order Our Price: $190.57
19	470819794	DEFROSTER JET AIR VENT	1 req	Avail to order Our Price: $198.75
19		FRESH AIR VENT (SEE TABLE. 857.03 rif. 4)	0 req
20		HVAC UNIT (SEE TABLE 820.01.00)	0 req
20	8K0907539	SUNLOAD SENSOR SUN SENSOR	1 req	Avail to order Our Price: $57.84
21	470819705	VENT,SIDE FRESH AIR VENT	1 req	Avail to order Our Price: $256.07
21	470805259B	BRACKET CENTR.PLANCIA CENT DASHBOARD CENTER BRACKET	2 req	Avail to order Our Price: $81.88
22	N10335202	SCREW M6X12 SCREW M6x13	4 req	Current Stock: 5 Our Price: $2.00
22	470819903	AIR INTAKE FRESH AIR VENT	1 req	Avail to order Our Price: $424.30
23	470819706	VENT,SIDE FRESH AIR VENT	1 req	Avail to order Our Price: $256.07
24		HVAC UNIT (SEE TABLE 820.01.00)	0 req
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
