2016 HURACAN ZHONG 600-4 COUPE - AUSTRALIA

Group :

Tav :

Maintenance Parts:

Brakes

PN	Item	Diagram
4T0698010	CERAMIC BRAKE PAD KIT BIADHESIVEE PADS KIT		Avail to order Our Price: $142.27
4S0698151K	SET OF BRAKE PADS FOR CARBOCERAMIC DISC SET OF BRAKE PADS FOR DISC CARBOCERAMIC BRAKES OLD PN 4E0698151G		Current Stock: 1 Our Price: $1,084.07

Common repairs and upgrades

PN	Item
900000384B	HURACAN CAR COVER ORANGE STITCHING INDOOR INT. 62X CAR COVER ORANGE STIT. NOTE: THE ORANGE COLOR LAMBORGHINI USES FOR THIS COVER IS VERY LIGHT AND IS ALMOST YELLOW. THIS IS NORMAL AND THEIR INTENDED COLOR FOR THIS COVER	Avail to order Our Price: $454.30
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO	Current Stock: 2 Our Price: $25.24
4T0823359	GAS SPRING GAS SPRING	Current Stock: 2 Our Price: $93.20
4T0803615	TOWING EYE TOWING EYE OLD PN 400803615	Current Stock: 2 Our Price: $55.87
079115561J	SPIN-ON FILTER SPIN-ON FILTER	Avail to order Our Price: $94.88
1K0906283A	EGR VALVE ELECTR.CHANGEOVER EGR VALVE	Current Stock: 3 Our Price: $95.98
G052529A2	TRANSMISSION FLUID TRANSMISSION FLUID	Current Stock: 14 Our Price: $82.54

Drivetrain

PN	Item	Diagram
079198405E	OIL FILTER GALLARDO/HURACAN LP SERIES OIL FILTER GALLARDO LP SERIES		Current Stock: 6 Our Price: $102.79

Fuel-Air

PN	Item
420133844E	ENGINE AIR FILTER HURACAN AIR FILTER SEE PN 420133844EZ FOR K&N PERFORMANCE FILTER	Avail to order Our Price: $176.14
4T0133843	FILTER ELEMENT FILTER ELEMENT FILTER ELEMENT	Avail to order Our Price: $539.96
06E906051K	FUEL PRESSURE SENSOR FUEL PRESSURE SENSOR	Current Stock: 1 Our Price: $153.68
4s0819439	FILTER ELEMENT FILTER ELEMENT	Current Stock: 6 Our Price: $118.09
07L127025S	FUEL PUMP FUEL PUMP	Avail to order Our Price: $796.46

Gaskets

PN	Item	Diagram
N0138493	WASHER WASHER		Current Stock: 47 Our Price: $4.77

Ignition

PN	Item	Diagram
06H905601C	SPARK PLUG SPARK PLUG		Avail to order Our Price: $41.61
0BZ911024D	STARTER STARTER		Current Stock: 1 Our Price: $1,494.22

Misc

PN	Item
4T1864435E	HURACAN SET OF 2 FLOOR MATS PICK BORDER COLOR HURACAN SET OF 2 FLOOR MATS PICK BORDER COLOR CUSTOMIZABLE STICTHING OR BORDER	Avail to order Our Price: $865.25
4H0805615	TOWING EYE FOR HURACAN TOWING EYE	Avail to order Our Price: $52.84
4T0898201	SEE PN 4T0998200A PAIR OF DOOR LIGHTS WITH LAMBORGHINI SCRIPT WRITING KIT LIGHTS THE GROUND WITH THE LAMBORGHINI SCRIPT ILLUMINATED FROM THE DOOR REPLACES - 4E0947415A	Avail to order Our Price: $252.46
4T0898200	SEE PN 4T0998200 DOOR LIGHT WITH LAMBORGHINI LOGO KIT REPLACES - 4E0947415A	Avail to order Our Price: $252.46
400093050D	CTEK US-CD BATTERY CHARGER INPUT 110-120VAC OUTPUT MAX 4.3A, 12V BACK DRAIN LESS THAN 1.5AM/MONTH	Avail to order Our Price: $373.98
4T0864537	TRIM COVER PLATE TRIM COVER PLATE	Avail to order Our Price: $89.31
0R0000149	CLEANER FLUID 250ML CLEANER FLUID	Current Stock: 1 Our Price: $70.78

Sensors

PN	Item
7PP907275F	WHEEL ELECTRONICS WHEEL ELECTRONICS	Avail to order Our Price: $214.44
4H0959126A	AC PRESSURE SENSOR A/C PRESSURE SENSOR,	Avail to order Our Price: $91.73
4E0927803F	RH ABS SENSOR SPEED SENSOR	Avail to order Our Price: $166.10
4E0927804F	LH ABS SENSOR SPEED SENSOR	Current Stock: 1 Our Price: $166.10

Tools and Tookits

PN	Item	Diagram
470012257	DEMOUNTING HOOK DEMOUNTING HOOK		Current Stock: 1 Our Price: $585.43
wheeltool	WHEEL INSTALL TOOL SCREWS INTO HUB FOR EASY INSTALLATION.		Current Stock: 93 Our Price: $19.42

Open All

Select Group and TAV

< Previous Next >

TAV: 863.09.00 - SECURING PARTS FOR ENGINE

2016 Lamborghini HURACAN ZHONG 600-4 COUPE AUSTRALIA SECURING PARTS FOR ENGINE (863.09.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Huracan Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	4T8863843A	BRACKET ARM (LEFT)	1 req	Avail to order Our Price: $46.80
1	4T8863844A	BRACKET ARM (RIGHT)	1 req	Avail to order Our Price: $46.80
2	4T8863974B	BRACKET ARM (OPT-RIGHT)	1 req	Avail to order Our Price: $66.12
3	4T0813285	RETAINING PLATE ARM (LEFT)	1 req	Avail to order Our Price: $41.69
3	4T0813286	RETAINING PLATE ARM (RIGHT)	1 req	Avail to order Our Price: $227.19
4	N01166623	WASHER WASHER (6,4X18X1,6)	22 req	Current Stock: 8 Our Price: $1.49
5	4T8863974A	BRACKET ARM (RIGHT)	1 req	Avail to order Our Price: $74.96
6	4T8864287C	BRACKET ARM (LEFT)	1 req	Avail to order Our Price: $53.52
6	4T8864288C	BRACKET ARM (RIGHT)	1 req	Avail to order Our Price: $53.52
7	4T8864851B	BRACKET ARM (LEFT)	1 req	Avail to order Our Price: $53.52
7	4T8864852B	BRACKET ARM (RIGHT)	1 req	Avail to order Our Price: $53.52
8	4T0864287	BRACKET FORGED ENGINEBAY ARM (OPT-LEFT)	1 req	Avail to order Our Price: $37.78
8	4T0864288	BRACKET FORGED ENGINEBAY ARM (OPT-RIGHT)	1 req	Avail to order Our Price: $37.78
9	4T0864473	BRACKET FORGED ENGINEBAY ARM (OPT-LEFT)	1 req	Avail to order Our Price: $19.58
9	4T0864474	BRACKET FORGED ENGINEBAY ARM (OPT-RIGHT)	1 req	Avail to order Our Price: $19.58
10	4T8863973B	BRACKET ARM (OPT-LEFT)	1 req	Avail to order Our Price: $54.54
11	N01508210	HEXAGON FLANGE NUT HEXAGON COLLAR NUT (M6-M6)	1 req	Current Stock: 17 Our Price: $2.38
12	N91188301	HEXALOBULAR SOCKET HEXAGON SOCKET HEAD BOLT (M6X20-M6X20)	8 req	Current Stock: 1 Our Price: $1.69
13	470861147	CATCH STOP BUFFER (4,5X2,2X8,6)	2 req	Avail to order Our Price: $52.84
14	N91042302	OVAL HEXAGON SOCKET HEAD BOLT OVAL HEXAGON SOCKET HEAD BOLT (M6X16-M6X16)	8 req	Avail to order Our Price: $1.96
15	N10734301	HEXALOBULAR SOCKET HEXAGON SOCKET HEAD BOLT (M6X12-M6X12)	8 req	Avail to order Our Price: $3.31
15	WHT003841	HEXALOBULAR SOCKETM6GFX14 FLAT ROUND HEAD BOLT (M6GFX14-M6GFX14)	4 req	Avail to order Our Price: $2.13
16	8D0805960	SPEED NUT SPEED NUT (6,0MM)	24 req	Current Stock: 18 Our Price: $4.08
17	4T8863973A	BRACKET ARM (LEFT)	1 req	Avail to order Our Price: $52.49
18	8D0805121B	PIVOT GRIP PIN (BLACK)	8 req	Current Stock: 11 Our Price: $47.73
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
