TAV: 76.01.00 - Head Lamp Lifting System

1998 Lamborghini Diablo 2WD-4WD USA Head Lamp Lifting System (76.01.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Diablo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	009444136	Rh/Lh Headlight Motor Shim	req	Avail to order Our Price: $26.61
2	009444137	Rh/Lh Headlight Motor Shim	req	Avail to order Our Price: $39.54
3	009444148	Left Headlight Support Interna	req	Avail to order Our Price: $51.81
3	009444147	Right Headlight Support Intern	1 req	Avail to order Our Price: $51.81
4	N01118312	HEX.HEAD CLAMPING NUT	1 req	Avail to order Our Price: $2.17
5	009444208	Adjustment Rod & Handle	2 req	Current Stock: 2 Our Price: $304.90
6	009444139	Rh Headlight Male Sticker-Rh	2 req	Avail to order Our Price: $16.18
6	009444141	Lh Headlight Sticker	1 req	Avail to order Our Price: $16.18
7	009444124	Rh Headlight Box Frame	1 req	Current Stock: 1 Our Price: $223.64
7	009444125	Lh Headlight Box Frame	1 req	Avail to order Our Price: $149.84
8	009444140	NLA (No Longer Available)	1 req	*See Description
8	009444142	Lh Headlight Sticker LH	1 req	Avail to order Our Price: $16.18
9	008700335	Parker Screw 2.9 x 16	4 req	Avail to order Our Price: $2.00
9	WHT003065	Parker Screw 2.9 x 16	4 req	Current Stock: 6 Our Price: $2.00
10	008830410	Spring	2 req	Avail to order Our Price: $2.00
11	N10718801	HEXAGON FLANGE BOLT	6 req	Current Stock: 4 Our Price: $2.00
12	008700668	Screw 6x1x20	8 req	Avail to order Our Price: $2.00
13	N01152427	WASHER	4 req	Current Stock: 16 Our Price: $2.00
14	009444137	Rh/Lh Headlight Motor Shim	req	Avail to order Our Price: $39.54
15	009444136	Rh/Lh Headlight Motor Shim	req	Avail to order Our Price: $26.61
16	009444144	Lh Headlight Motor Bracket	1 req	Avail to order Our Price: $108.84
16	009444143	Rh Headlight Motor Bracket	1 req	Current Stock: 1 Our Price: $109.29
17	005937318	RH HEADLIGHT ADJUSTMENT MOTOR	1 req	Avail to order Our Price: $1,144.86
17	005937319	LH HEADLIGHT ADJUSTMENT MOTOR	1 req	Avail to order Our Price: $394.53
18	410805717A	Headlight Wire Terminal	2 req	Avail to order Our Price: $11.84
19	008410603	Washer D.6.4 Uni 1751/Zd	2 req	Avail to order Our Price: $2.00
20	008400626	Washer 6.5x22x2.5 Uni 4721/Z	8 req	Avail to order Our Price: $44.89
21	009444134	Rh/Lh Headlight Box Brac. Shim	req	Avail to order Our Price: $21.18
22	009444135	Rh/Lh Headlight Box Brac. Shim	req	Avail to order Our Price: $11.48
23	009444204	Headlight Bowden Wire	2 req	Avail to order Our Price: $67.02
24	410827421	Bonnet Lock Wire Adjustment	2 req	Avail to order Our Price: $6.55
25	N01100632	HEX.NUT	2 req	Avail to order Our Price: $4.99
26	009444205	Headlight Rubber Pin	2 req	Avail to order Our Price: $28.71
27	009444127	Left Headlight Support Right B	1 req	Avail to order Our Price: $47.86
27	009444129	Right Headlight Support Left B	1 req	Avail to order Our Price: $47.86
28	008801004	Bushing 7x14x18 mm	4 req	Current Stock: 4 Our Price: $72.02
29	009444138	Headlight Pin Bush	4 req	Avail to order Our Price: $2.00
30	008100857	Lid Fixing Special Screw	4 req	Current Stock: 2 Our Price: $31.76
31	009444001	LH Headlight Box Assembly	1 req	Avail to order 1 Used Available Our Price: $1,414.87
31	009444000	RH Headlight Box Assembly	1 req	Avail to order 1 Used Available Our Price: $1,414.87
32	N01118312	HEX.HEAD CLAMPING NUT	4 req	Avail to order Our Price: $2.17
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
