TAV: 66.04.01 - Coque Elements-Left Flank

1998 Lamborghini Diablo 2WD-4WD USA Coque Elements-Left Flank (66.04.01)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Diablo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	009430125	NET ON REAR LEFT FENDER FOR AI	1 req	Avail to order Our Price: $404.28
2	009453137	Air Filter Duct Bracket	1 req	Avail to order Our Price: $10.74
3	009453136	Air Filter Duct Adjustment Sup	1 req	Avail to order Our Price: $13.80
4	N10718801	HEXAGON FLANGE BOLT	4 req	Current Stock: 4 Our Price: $2.00
5	009430127	Net (Grill) Small side LH	1 req	Avail to order Our Price: $291.48
6	009453138	Left Air Filter Air Duct	1 req	Avail to order Our Price: $539.71
7	009453147	Lh Water Radiator Air Duct	1 req	Avail to order Our Price: $1,003.38
8	009490113	RH / LH BONNET SEAL	1 req	Avail to order Our Price: $27.18
9	009410009	Left Rear Fender	1 req	Avail to order Our Price: $11,256.35
10	009411506	Left Rear Wheelhouse	1 req	Avail to order Our Price: $566.55
11	WHT000757	SCREW	11 req	Avail to order Our Price: $5.44
12	008400624	Firal Genuine WasherFr Ny-6-13	11 req	Current Stock: 4 Our Price: $4.76
13	N90327506	SPEED NUT	2 req	Current Stock: 43 Our Price: $2.00
14	009490200	Oil Radiator Air Output Manifo	1 req	Avail to order Our Price: $159.53
15	009453142	Oil Radiator Air Outlet Duct	1 req	Avail to order Our Price: $126.59
16	009453126	GASKETS FOR AIR CONV. RAD. OIL	1 req	Avail to order Our Price: $4.69
17	009411512	Lh Rear W/House GritSeal	1 req	Avail to order Our Price: $67.86
18	009453155	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
19	009453125	Seal/Fa Cn/20	2 req	Avail to order Our Price: $6.19
20	009430140	Lh Skirt Lower PanelNet	1 req	Avail to order Our Price: $161.77
21	009430006	Lh Skirt Grille Assembly	1 req	Avail to order Our Price: $481.57
22	009430143	Skirt Air Exhaust Grille	1 req	Avail to order Our Price: $90.65
23	009410305	Lh Skirt External Cover.	1 req	Avail to order Our Price: $5,277.82
24	008400624	Firal Genuine WasherFr Ny-6-13	3 req	Current Stock: 4 Our Price: $4.76
25	N90327506	SPEED NUT	6 req	Current Stock: 43 Our Price: $2.00
26	WHT000757	SCREW	3 req	Avail to order Our Price: $5.44
27	009458308	Lh Doorsill Moulding	1 req	Avail to order Our Price: $3,760.36
28	008700449	Screw 1/56819/01 Rif. Fiat	22 req	Current Stock: 19 Our Price: $3.43
29	N91109201	WASHER	22 req	Current Stock: 103 Our Price: $2.00
30	009411511	Rh/Lh Rear W/House Grit Seal	1 req	Avail to order Our Price: $128.07
31	WHT000916A	SPEED NUT	22 req	Current Stock: 10 Our Price: $16.53
32	009411526	Lh Rear Fedner Liner / Battery cover	1 req	Avail to order Our Price: $576.70
33	009411512	Lh Rear W/House GritSeal	1 req	Avail to order Our Price: $67.86
34	009411513	Left And Right Rear Bulkhead S	1 req	Current Stock: 1 Our Price: $182.07
35	009411505	Left Rear Wheelhouse	1 req	Avail to order Our Price: $500.89
36	WHT002961	WASHER	3 req	Current Stock: 38 Our Price: $2.00
37	N10718801	HEXAGON FLANGE BOLT	8 req	Current Stock: 4 Our Price: $2.00
38	N91049601	screw	8 req	Current Stock: 16 Our Price: $2.00
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
