TAV: 42.01.00 - Pedals

1998 Lamborghini Diablo 2WD-4WD USA Pedals (42.01.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Diablo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	008401006	Washer 22x10.5x2.5 Uni 1734/5s	6 req	Current Stock: 1 Our Price: $2.00
2	004232621	Brake Booster & Pedal Board Pi	2 req	Avail to order Our Price: $43.91
3	004225060	Brake Booster Lever	1 req	Avail to order Our Price: $87.82
4	008801209	Bushing 12x14x20 mm	1 req	Avail to order Our Price: $11.11
5	004225061	Brake Booster Lever Rod	1 req	Avail to order Our Price: $79.62
6	001321270	Throttle Lever Return Spring	2 req	Current Stock: 3 Our Price: $9.77
7	008802501	Bushing 25x28x15 mm	2 req	Avail to order Our Price: $25.50
8	004210834	Brake/Clutch Pedal Adjustment	2 req	Avail to order Our Price: $5.22
9	N01100637	HEX.NUT	2 req	Current Stock: 18 Our Price: $2.00
10	008900603	Pin S6x28	2 req	Avail to order Our Price: $6.87
11	413721325	Brake/Clutch Pedal Pin	1 req	Avail to order Our Price: $3,714.46
12	008400819	Washer 8x12x1 Bv.0005096.A	2 req	Current Stock: 1 Our Price: $2.00
13	N01100845	HEX.NUT	1 req	Current Stock: 17 Our Price: $2.09
14	008100854	SCREW	1 req	Avail to order Our Price: $2.00
15	008200504	M5 Lh. Special Nut	2 req	Avail to order Our Price: $18.56
16	004238042	Accelerator Wire Lever	1 req	Avail to order Our Price: $39.74
17	004230089	Accelerator Pedal Wire Assembl	1 req	Avail to order Our Price: $1,337.35
18	008200804	Nut	1 req	Current Stock: 7 Our Price: $2.00
19	N0152785	WASHER	1 req	Current Stock: 71 Our Price: $2.00
20	N90179103	WASHER	1 req	Current Stock: 5 Our Price: $2.00
21	008401220	Washer 12.4x22x1/Aq45	2 req	Avail to order Our Price: $6.93
22	008521205	BEARING	2 req	Current Stock: 2 Our Price: $12.81
23	004231811	Accelerator Pedal Bracket	1 req	Avail to order Our Price: $292.96
24	008581101	O-Ring E 12 Uni 7435-75	1 req	Avail to order Our Price: $6.79
25	004230143	Accelerator Pedal Assembly	1 req	Avail to order Our Price: $638.11
26	0042005210	Pedal Cover (Clutch or Brake)	1 req	Avail to order Our Price: $80.51
27	0042001105	Brake Pedal	1 req	Avail to order Our Price: $454.73
28	0042005210	Pedal Cover (Clutch or Brake)	1 req	Avail to order Our Price: $80.51
29	004235355	Clutch Pedal	1 req	Avail to order 1 Used Available Our Price: $454.73
30	004232622	Pin On Brake Pedal For Cap	1 req	Avail to order Our Price: $30.94
31	008581004	Clip	3 req	Avail to order Our Price: $10.89
32	N10155210	HEX.NUT	1 req	Current Stock: 38 Our Price: $2.17
33	004225062	Brake Booster Lever Rod	1 req	Avail to order Our Price: $76.34
34	008900305	Door handle cable Pin	2 req	Current Stock: 10 Our Price: $2.00
35	410721965	Brake Booster Control Lever Pi	1 req	Avail to order Our Price: $32.01
36	004236013	Accelerator Pedal Wire Assembl	1 req	Avail to order Our Price: $181.15
38	004236013	Accelerator Pedal Wire Assembl	1 req	Avail to order Our Price: $181.15
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
