TAV: 63.01.00 - Lights

1996 Lamborghini Diablo Roadster USA Lights (63.01.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Diablo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	006331753	DOUBLE HEADLIGHT WITHOUT RING	2 req	Avail to order 1 Used Available Our Price: $205.45
1	006331753	HEADLIGHT	2 req	Current Stock: 2 1 Used Available Our Price: $256.82
2	006331631	HEADLIGHT RING	2 req	Current Stock: 3 Our Price: $115.08
3	006329694	Bulb Headlight	2 req	Avail to order Our Price: $63.82
4	006337294	Rear Consol light Pre-2000	1 req	Avail to order 2 Used Available Our Price: $83.34
5	006329698	Bulb	1 req	Avail to order Our Price: $9.02
6	006338122	Bulb	1 req	Avail to order Our Price: $3.95
7	006337066	DIABLO TRUNK LIGHT	1 req	Avail to order Our Price: $19.80
8	N0177522	bulb	1 req	Current Stock: 10 Our Price: $2.17
9	WHT001187	Washer 10x5.3x1 Uni 6952 Cat-A	4 req	Current Stock: 8 Our Price: $2.00
10	008700502	Screw M5x18 Uni 59318g/F	4 req	Avail to order Our Price: $2.00
11	0063001281	BACKUP LIGHT	1 req	Avail to order Our Price: $86.95
11	0063001282	Rear Fog Light - RED	1 req	Avail to order Our Price: $98.85
12	006617094	LAMP BA 15S 21W	4 req	Current Stock: 76 Our Price: $9.90
13	006617095	Bulb for license plate lamp	2 req	Current Stock: 42 Our Price: $11.09
14	WHT003424	Spring	4 req	Current Stock: 7 Our Price: $2.00
15	008700445	Lock Screw 3.5x16din7981/Zg	4 req	Current Stock: 16 Our Price: $2.00
16	006328344	Number Plate Light	2 req	Avail to order Our Price: $53.01
17	009911301	LH Rear Headlight Cover Panel	1 req	Avail to order Our Price: $1,173.35
17	009911300	RH Rear Headlight Cover Panel	1 req	Avail to order Our Price: $1,173.35
18	009444005	Rh Rear Light Frame	1 req	Avail to order Our Price: $276.45
18	009444006	Lh Rear Light Frame - clear	1 req	Current Stock: 1 Our Price: $277.31
19	006329828	Rear Stop lamp (Red) 91-99	2 req	Current Stock: 11 Our Price: $101.24
20	006329829	Rear Turn lamp (Amber) 91-99	2 req	Current Stock: 62 Our Price: $89.76
21	006617091	Bulb 21w tail light	2 req	Current Stock: 4 Our Price: $13.56
22	WHT002961	WASHER	8 req	Current Stock: 38 Our Price: $2.00
23	WHT002963	SPRING LOCK WASHER	8 req	Current Stock: 26 Our Price: $2.00
24	N01100632	HEX.NUT	8 req	Avail to order Our Price: $4.99
25	006319022	Red Reflector	2 req	Current Stock: 4 Our Price: $166.75
26	410947413	RED DOOR LIGHT	2 req	Avail to order Our Price: $92.91
27	410947413	RED DOOR LIGHT	2 req	Avail to order Our Price: $92.91
28	006329897	4w Bulb for front side indicator	2 req	Current Stock: 3 Our Price: $2.91
29	0R1050004	Direction Indicators Kit includes 2	2 req	Current Stock: 2 Our Price: $203.51
30	N0211963	HEX.HEAD CLAMPING	6 req	Avail to order Our Price: $2.00
31	006338269	Foglight also needed 006338270	8 req	Avail to order Our Price: $220.66
32	006338269	Foglight also needed 006338270	2 req	Avail to order Our Price: $220.66
33	006329695	BULB FOR FOGLIGHT	4 req	Current Stock: 1 Our Price: $19.36
34	002403369	Reverse Lever Lock Spring	4 req	Avail to order Our Price: $38.55
35	006337296	Foglight/Flash Bolt	6 req	Avail to order Our Price: $19.01
36	WHT003364	SERRATED LOCK	6 req	Avail to order Our Price: $2.39
37	006336821	RH HEADLIGHT DIABLO ROADSTER	1 req	Avail to order Our Price: $426.57
37	006336822	LH HEADLIGHT - DIABLO ROADSTER	1 req	Avail to order Our Price: $426.57
38	006337297	Foglight/Flash Adjustment Bolt	6 req	Avail to order Our Price: $19.01
39	006617094	LAMP BA 15S 21W	2 req	Current Stock: 76 Our Price: $9.90
40	006329696	Bulb 5w Front Turn Signal	2 req	Current Stock: 6 Our Price: $3.35
41	REPPRE2000TURN	Pre2000 Front Turn Signals SET (Left and Right) NLA	1 req	*See Description
42	008700304	Lock Screw 3.5x9.5din7981/N	8 req	Avail to order Our Price: $2.00
43	410945249A	Rear Backup light strip	1 req	Current Stock: 1 Our Price: $199.50
44	006132280	Supplementary Brake Light Conn	1 req	Avail to order Our Price: $11.93
45	009944100	Brake Light/Roll-BarContact	1 req	Avail to order Our Price: $1,478.98
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
