2021 AVENTADOR SVJ ROADSTER - AUSTRALIA

Maintenance Parts:

Tools and Tookits

Tools and Tookits

PN	Item	Diagram
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month		Avail to order Our Price: $317.22

Open All

Select Group and TAV

< Previous Next >

TAV: 815.02.00 - AIR INTAKE TRIM PLATE

2021 Lamborghini AVENTADOR SVJ ROADSTER AUSTRALIA AIR INTAKE TRIM PLATE (815.02.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Aventador Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	470119363E	AIR DUCT ELEMENT EFFUSORE OLIO MOT. AIR GUIDE (LEFT)	1 req	Avail to order Our Price: $316.65
1	470119364E	AIR DUCT ELEMENT EFFUSORE OLIO MOT. AIR GUIDE (RIGHT)	1 req	Avail to order Our Price: $364.55
2		AIR GUIDE GRILLE (FROM VIN ELA02260 SEE REF 14)	0 req
3		LINING FOR FENDER (SEE ILLUSTRATION :-REAR 821-020)	0 req
4	N0154487	SPEED NUT SPEED NUT (4,2X16,3X11)	6 req	Current Stock: 6 Our Price: $2.00
5	N90986803	FLANGE TAPPING HEXAGON SOCKET HEAD PANEL BOLT (4,2X13)	6 req	Avail to order Our Price: $2.00
6	N10661002	HEXALOBULAR SOCKET HEX SOCKET OVAL HEAD COLLARED (M6X20)	8 req	Current Stock: 18 Our Price: $2.00
7	N90780903	SOCKET SCREW OVAL HEXAGON SOCKET HEAD BOLT (M6X16)	6 req	Current Stock: 1 Our Price: $2.00
8	470117331D	AIR DUCT ELEMENT AIR GUIDE (LEFT)	1 req	Avail to order Our Price: $365.98
8	470117332D	AIR DUCT ELEMENT AIR GUIDE (RIGHT)	1 req	Avail to order Our Price: $317.37
9	470122193E	AIR DUCT CARBON FIBER LH AIR DUCT CARDBOARD (MATT CARBON LOOK-LEFT)	1 req	Avail to order Our Price: $5,511.02
9	470122193F	AIR DUCT, CARBON FIBER LH AIR DUCT CARDBOARD (CFK SHINY CARBON LOOK-LEFT)	1 req	Avail to order Our Price: $5,511.02
9	470122194F	AIR DUCT, CARBON FIBER RH AIR DUCT CARDBOARD (CFK SHINY CARBON LOOK-RIGHT)	1 req	Avail to order Our Price: $5,511.02
9	470122194H	FRAME CODICE LIBERO AIR DUCT CARDBOARD (CFK MATT-RIGHT)	1 req	Avail to order Our Price: $5,532.30
9	470122194J	FRAME AIR DUCT CARDBOARD (CFK SHINY)	1 req	Avail to order Our Price: $5,532.30
10	470117085B	BRACKET RAD.OLIO MOT. ARM (LEFT)	1 req	Avail to order Our Price: $10.98
10	470117086B	BRACKET RAD.OLIO MOT. ARM (RIGHT)	1 req	Avail to order Our Price: $10.98
11	N91083301	BLIND RIVET POP RIVET (A3.2X14)	4 req	Avail to order Our Price: $2.00
12	N90688703	SNAP NUT CLAMP SPEED NUT (M6X24X16)	4 req	Current Stock: 2 Our Price: $2.00
13	N01166623	WASHER WASHER (6,4X18X1,6)	4 req	Avail to order Our Price: $2.00
14	470827281B	LOUVER CONVOG.RAD.OLIO AIR GUIDE GRILLE (LEFT)	1 req	Avail to order Our Price: $42.25
14	470827282B	LOUVER CONVOG.RAD.OLIO AIR GUIDE GRILLE (RIGHT)	1 req	Avail to order Our Price: $42.25
15	N90986803	FLANGE TAPPING HEXAGON SOCKET HEAD PANEL BOLT (4,2X13)	6 req	Avail to order Our Price: $2.00
16	N10714801	HEXALOBULAR SOCKET OVAL HEXAGON SOCKET HEAD BOLT (M6X18)	2 req	Avail to order Our Price: $2.00
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
