2014 AVENTADOR LP700-4 COUPE - ARABIA

Maintenance Parts:

Belts

PN	Item	Diagram
07M903137C	RIBBED V-BELT RIBBED V-BELT		Avail to order Our Price: $41.07

Brakes

PN	Item	Diagram
470698151	FRONT BRAKE PAD SET FRONT BRAKE PAD SET		Current Stock: 2 Our Price: $1,666.39
470698451	REAR BRAKE PAD SET REAR BRAKE PAD SET		Current Stock: 2 Our Price: $1,376.26

Drivetrain

PN	Item
079905381	TRANSDUCER POS. TRANSDUCER POS.	Avail to order Our Price: $448.13
07M105269C	SEE PN 07M105269D BALANCED CLUTCH MECHANISM	Avail to order Our Price: $8,288.36
07M115561	see PN 07M115561B Oil Filter Cartridge	Avail to order Our Price: $50.22
07M115561B	SPIN-ON FILTER CARTUCCIS FIL.OLIO SPIN-ON FILTER CARTUCCIS FIL.OLIO	Avail to order Our Price: $50.22
0CE141671A	CONCENTRIC SLAVE CYLINDER LP700 CONCENTRIC SLAVE CYLINDER	Avail to order Our Price: $1,451.55
0CE311675A	CLUTCH SENSOR - MASTER CYLINDER CLUTCH SENSOR - MASTER CYLINDER	Current Stock: 1 Our Price: $1,107.64

Fuel-Air

PN	Item	Diagram
470133843A	FILTER ELEMENT FILTER ELEMENT		Current Stock: 1 Our Price: $168.88
4D0906321C	FUEL FILTER FILTER		Avail to order Our Price: $41.62

Fuses-Bulbs-Relays

PN	Item	Diagram
N01713118	FUSE Please Check your Part Manual for a Description		Current Stock: 18 Our Price: $2.00
N0177532	LAMP BULB LAMP BULB		Avail to order Our Price: $2.00

Ignition

PN	Item
470905619	SEE PN 470905619C SPARK PLUG	Avail to order Our Price: $104.90
470905619A	SPARK PLUG SPARK PLUG	Avail to order Our Price: $107.58
7P0915105	BATTERY BATTERY	Avail to order Our Price: $587.70

Misc

PN	Item
0R8340113	AVENTADOR CENTRAL LOCK CONVERSION KIT AVENTADOR CENTRAL LOCK CONVERSION KIT	Avail to order Our Price: $9,143.69
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month	Avail to order Our Price: $317.22
470898013	BLACK 73X CENTRAL LOCK CONVERSION KIT BLACK 73X CENTRAL LOCK CONVERSION KIT	Avail to order Our Price: $9,143.69
6Q0819653B	ODOR FILTER ODOR FILTER	Avail to order Our Price: $65.70
900000381	NLA (No Longer Available) Comes with Eyelet connects, Clamp connectors and Cigar Lighter Adapter.	Avail to order Our Price: $190.57
900000382	NLA use PN 400093050D for USA replacement	Avail to order Our Price: $190.57

Sensors

PN	Item
059919523A	TEMPERATURE SENDER TEMPERATURE SENDER	Current Stock: 6 Our Price: $68.48
06A906262AT	O2 SENSOR-LAMBDA PROBE LAMBDA PROBE	Avail to order Our Price: $149.62
07L905163A	SEE PN 07L905163C PHASE SENSOR	Avail to order Our Price: $37.90
07L919561B	OIL PRESSURE GAUGE SENDER OIL PRESSURE GAUGE SENDER	Avail to order Our Price: $890.28
470998161	COLD JOINT KIT Set of two 470919197C	Avail to order Our Price: $969.58
4E0927803	ABS SENSOR LEFT ABS SENSOR LEFT	Current Stock: 2 Our Price: $46.75
4E0927804	SEE PN 4E0927804F ABS SENSOR RIGHT	Avail to order Our Price: $46.75
4F0907275D	See PN 7PP907275F WHEEL ELECTRONICS	Avail to order Our Price: $203.22

Tools and Tookits

PN	Item	Diagram
470012257	DEMOUNTING HOOK DEMOUNTING HOOK		Current Stock: 1 Our Price: $253.70

Open All

Select Group and TAV

< Previous Next >

TAV: 251.03.00 - EXHAUST SYSTEM

2014 Lamborghini AVENTADOR LP700-4 COUPE ARABIA EXHAUST SYSTEM (251.03.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Aventador Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	N10433701	SPEED NUT CLIP	12 req	Current Stock: 14 Our Price: $2.00
2	470825709B	HEAT SHIELD,REAR HEAT SHIELD	1 req	Avail to order Our Price: $4,094.10
3	N10680201	DUO HEXAGON FLANGE BOLT SCREW M10X75	2 req	Avail to order Our Price: $3.80
4	N10005207	HEX. BOLT WITH SCREW M8X18	4 req	Avail to order Our Price: $8.04
5	470251303C	SUSPENSION SUPPORT	2 req	Avail to order Our Price: $110.92
6	7L0253144B	SUSPENSION SUPPORT	2 req	Avail to order Our Price: $58.51
7	N0195307	HEXAGON FLANGE SCREW M8X25	4 req	Avail to order Our Price: $3.13
8	470251051G	MUFFLER SILENCER WITH CATALYST	1 req	Avail to order Our Price: $24,720.86
9	N91032702	HEXALOBULAR SOCKET FLANGE BOLT SCREW M6X20	4 req	Current Stock: 6 Our Price: $2.00
10	470253697C	TRIM,TAIL PIPE EXHAUST TERMINALS COVER	1 req	Avail to order Our Price: $699.72
11	N90780903	SOCKET SCREW SCREW M6X16	2 req	Current Stock: 1 Our Price: $2.00
12	420251143	CLAMP CLIP	2 req	Avail to order Our Price: $94.69
13	470131850	HOSE PIPE	2 req	Avail to order Our Price: $120.74
14	470971796	BRACKET LH BRACKET	1 req	Avail to order Our Price: $28.81
14	470971806A	BRACKET RH BRACKET	1 req	Avail to order Our Price: $66.11
15	470131849	HOSE PIPE	2 req	Avail to order Our Price: $120.30
16	059906051A	PRESSURE SENSOR SENSOR	2 req	Current Stock: 4 Our Price: $137.72
17	3C0131483A	CLIP CLAMP	4 req	Avail to order Our Price: $3.51
18	N10569501	HEXALOBULAR SOCKET SCREW M5X16	2 req	Avail to order Our Price: $2.31
19	3C0131483	CLIP CLAMP	4 req	Avail to order Our Price: $3.51
20	N10637302	HEXALOBULAR SOCKETFLANGE BOLT SCREW M5X20	2 req	Current Stock: 8 Our Price: $2.00
21	470825613B	HEAT SHIELD HEAT SHIELD	1 req	Avail to order Our Price: $2,895.65
22	N90775001	FLANGE TAPPING SCREW ST4,8X16	12 req	Current Stock: 9 Our Price: $2.09
23		CROSS MEMBER (SEE TABLE 701.03.00)	0 req
24		REAR BUMPER (SEE TABLE 701.04.00)	0 req
25	470825497	DIFFUSER HEAT SHIELD	1 req	Avail to order Our Price: $259.79
26	470825981	SPACER SPACER	2 req	Avail to order Our Price: $22.71
27	WHT001942	WASHER WASHER	4 req	Current Stock: 13 Our Price: $3.43
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
