Maintenance Parts:

Drivetrain

PN Item Diagram
07M115561B SPIN-ON FILTER CARTUCCIS FIL.OLIO
SPIN-ON FILTER CARTUCCIS FIL.OLIO
Avail to order
Our Price: $50.22
SPIN-ON FILTER    CARTUCCIS FIL.OLIO

Fuel-Air

PN Item Diagram
470133843A FILTER ELEMENT
FILTER ELEMENT
Current Stock: 1
Our Price: $168.88
FILTER ELEMENT
4D0906321C FUEL FILTER
FILTER
Avail to order
Our Price: $41.62
FUEL FILTER

Ignition

PN Item Diagram
470905619 SEE PN 470905619C
SPARK PLUG
Avail to order
Our Price: $104.90
SEE PN 470905619C
470905619A SPARK PLUG
SPARK PLUG
Avail to order
Our Price: $107.58

Misc

PN Item Diagram
400093050D CTEK US-CD BATTERY CHARGER
Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month
Avail to order
Our Price: $317.22
CTEK US-CD BATTERY CHARGER
6Q0819653B ODOR FILTER
ODOR FILTER
Avail to order
Our Price: $65.70
ODOR FILTER
900000381 NLA (No Longer Available)
Comes with Eyelet connects, Clamp connectors and Cigar Lighter Adapter.
Avail to order
Our Price: $190.57
NLA (No Longer Available)
900000382 NLA
use PN 400093050D for USA replacement
Avail to order
Our Price: $190.57
NLA

Sensors

PN Item Diagram
470998161 COLD JOINT KIT
Set of two 470919197C
Avail to order
Our Price: $969.58
4E0927803 ABS SENSOR LEFT
ABS SENSOR LEFT
Current Stock: 2
Our Price: $46.75
ABS SENSOR LEFT
4E0927804 SEE PN 4E0927804F
ABS SENSOR RIGHT
Avail to order
Our Price: $46.75
SEE PN 4E0927804F

Tools and Tookits

PN Item Diagram
470012257 DEMOUNTING HOOK
DEMOUNTING HOOK
Current Stock: 1
Our Price: $253.70
DEMOUNTING HOOK
Open All

Select Group and TAV

TAV: 807.02.00 - FRONT BUMPERS

2013 Lamborghini AVENTADOR LP700-4 ROADSTER JAPAN FRONT BUMPERS (807.02.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Aventador Parts Manual. Sorry, but there are NO exceptions.

Item # PN Item Qty Req *
1 FRONT BUMPERS (SEE TABLE 8070100) 1 req
2 470807325F REINFORCEMENT
LH REINFORCEMENT (UNTIL THE VIN ZHWUR1ZD2ELA02464 REPLACE ALSO RH P/N AND THE RIF.2 TAV. 701.01.00)
1 req Avail to order
Our Price: $158.55
2 470807326E REINFORCEMENT
RH REINFORCEMENT (UNTIL THE VIN ZHWUR1ZD2ELA02464 REPLACE ALSO LH P/N AND THE RIF.2 TAV. 701.01.00)
1 req Avail to order
Our Price: $103.02
3 470807481C ANGLE BRACKET
BRACKET
2 req Avail to order
Our Price: $29.63
ANGLE BRACKET
4 470807129A BRACKET
BRACKET
2 req Avail to order
Our Price: $51.59
BRACKET
5 4T0853745A TYPE SIGN LOGO ANT.
LAMBORGHINI ORNAMENT
1 req Avail to order
Our Price: $459.21
TYPE SIGN         LOGO ANT.
6 470807193C BRACKET,SIDE PER PARAFANGO
LH BRACKET
1 req Avail to order
Our Price: $44.52
6 470807194C See PN 470807194E
RH BRACKET
1 req *See Description
7 470807639A GRILLE
GRID
1 req Avail to order
Our Price: $172.95
GRILLE
8 470807681 GRILLE
LEFT FRONT GRID
1 req Avail to order
Our Price: $347.39
GRILLE
8 470807682 GRILLE
RIGHT FRONT GRID
1 req Avail to order
Our Price: $363.78
GRILLE
9 470807819 TRIM
LH FRAME
1 req Avail to order
Our Price: $2,109.64
TRIM
9 470807819A TRIM MOSTR.GRIGLIA SX
LH FRAME (EXTERNAL CARBON )
1 req Avail to order
Our Price: $5,754.91
9 470807820 TRIM
RH FRAME
1 req Avail to order
Our Price: $2,109.64
TRIM
9 470807820A TRIM MOSTR.GRIGLIA DX
RH FRAME (EXTERNAL CARBON )
1 req Avail to order
Our Price: $5,754.91
10 N90698605 SCREW
SCREW 4.2X16
8 req Current Stock: 3
Our Price: $2.00
SCREW
11 N10558102 HEXALOBULAR SOCKET
SCREW M6X18
4 req Current Stock: 9
Our Price: $4.40
HEXALOBULAR SOCKET
12 N10661002 HEXALOBULAR SOCKET
SCREW M6X20
6 req Current Stock: 18
Our Price: $2.00
HEXALOBULAR SOCKET
13 N01167026 WASHER
WASHER
6 req Avail to order
Our Price: $2.00
14 N10558102 HEXALOBULAR SOCKET
SCREW M6X18
4 req Current Stock: 9
Our Price: $4.40
HEXALOBULAR SOCKET
15 N0154487 SPEED NUT
CLIP
8 req Current Stock: 6
Our Price: $2.00
SPEED NUT
16 N90688703 SNAP NUT CLAMP
CLIP
2 req Current Stock: 8
Our Price: $2.00
SNAP NUT CLAMP
17 N90780903 SOCKET SCREW
SCREW M6X16
2 req Current Stock: 1
Our Price: $2.00
SOCKET SCREW
18 N0110027 HEX.NUT
NUT M3
1 req Current Stock: 1
Our Price: $2.00
HEX.NUT
19 N10558102 HEXALOBULAR SOCKET
SCREW M6X18
10 req Current Stock: 9
Our Price: $4.40
HEXALOBULAR SOCKET
20 470807287D LICENSE PLATE ANT.TARGA
LICENSE PLATE HOLDER
1 req Avail to order
Our Price: $157.07
21 470807287C LICENSE PLATE BRAC
LICENSE PLATE HOLDER (VALID FOR A MARKET CHINESE)
1 req Avail to order
Our Price: $531.50
22 N10451404 screw
SCREW M6X16
3 req Current Stock: 17
Our Price: $2.00
screw
23 N01166623 WASHER
WASHER
3 req Current Stock: 8
Our Price: $2.00
WASHER
24 400807995 GROMMET
RUBBER BUSHING
5 req Avail to order
Our Price: $3.65
GROMMET
25 N10637302 HEXALOBULAR SOCKETFLANGE BOLT
SCREW M5X20 (VALID FOR A MARKET CHINESE)
2 req Current Stock: 8
Our Price: $2.00
HEXALOBULAR SOCKETFLANGE BOLT

* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
