2010 MURCIELAGO REVENTON ROADSTER - EUROPE

Group :

Tav :

Maintenance Parts:

Belts

PN	Item	Diagram
07M903137A	RIBBED V-BELT RIBBED V-BELT		Avail to order Our Price: $99.97

Brakes

PN	Item
400698451	BRAKE PAD KIT REAR - MURCIELAGO - GALLARDO - SOLD AS 2 PAIR REAR BRAKE PAD KIT SET OF 2 PAIR FOR BOTH REAR ROTORS	Avail to order Our Price: $662.57
410615115D	E-BRAKE PAD - LATE DIABLO - MURCIELAGO SOLD EACH E-BRAKE PAD MURCIELAGO AND LATE DIABLO SOLD EACH	Current Stock: 1 Our Price: $52.15
410798041A	BRAKE PAD SET REAR CARBOCERAMIC - MURCIELAGO BRAKE PAD SET REAR CARBOCERAMIC - MURCIELAGO SOLD AS 2 PAIR FOR BOTH REAR ROTORS.	Avail to order Our Price: $1,208.14
4S0698151K	SET OF BRAKE PADS FOR CARBOCERAMIC DISC SET OF BRAKE PADS FOR DISC CARBOCERAMIC BRAKES OLD PN 4E0698151G	Current Stock: 1 Our Price: $938.30

Common repairs and upgrades

PN	Item
410837987	SHOCK ABSORBER SHOCK ABSORBER	Current Stock: 1 Our Price: $131.31
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO	Current Stock: 7 Our Price: $27.66
900000170	TUTELA CS SPEED FLUID -OIL LIFTING SYSTEM 1 LITER TUTELA CS SPEED FLUID -OIL LIFTING SYSTEM 1 LITER	Current Stock: 8 Our Price: $61.26

Drivetrain

PN	Item
07M105269	MURCIELAGO LP640/670 CLUTCH (MANUAL AND EGEAR) BALANCED MECHANISM CLUTCH MURCIELAGO LP640 CLUTCH (MANUAL AND EGEAR)	Avail to order Our Price: $9,029.42
086141671L	THROW OUT BEARING - EGEAR CONCENTRIC SLAVE CYLINDER FOR A LOWER COST ALTERNATIVE SEE OE SPEC BUT NON-OEM PN 086141671L-ALT IF REPLACING ORIGINAL 04-08 GALLARDO EQUIPMENT ALSO SEE PN: N10124306 X3	Avail to order Our Price: $2,091.61
07M115561B	SPIN-ON FILTER CARTUCCIS FIL.OLIO SPIN-ON FILTER CARTUCCIS FIL.OLIO	Current Stock: 9 Our Price: $201.60
N0138495	O-RING / WASHER O-RING	Current Stock: 47 Our Price: $3.45

Fuel-Air

PN	Item
07M133843	AIR FILTER - LM002, COUNTACH, DIABLO, MURCIELAGO PLEASE CHECK YOUR PART MANUAL FOR A DESCRIPTION FOR PERFORMANCE FILTERS SEE PN: 07M133843A	Current Stock: 12 Our Price: $28.63
400201511A	FUEL FILTER - DIABLO - GALLARDO - MURCIELAGO FUEL FILTER	Current Stock: 9 Our Price: $264.73
07M906031A	FUEL INJECTOR MURCIELAGO FUEL INJECTOR MURCIELAGO	Avail to order Our Price: $241.59
07M133843A	AIR FILTER - SPORT PERFORMANCE FILTER PERFORMANCE FILTER REPLACEMENT FOR 07M133843 AIR FILTER - MURCIELAGO SV LP 670-4	Avail to order Our Price: $706.90
07M133843KN	K&N AIR FILTER - LM002, COUNTACH, DIABLO, MURCIELAGO K&N'S REPLACEMENT AIR FILTERS ARE DESIGNED TO INCREASE HORSEPOWER AND ACCELERATION WHILE PROVIDING EXCELLENT FILTRATION. THESE FILTERS ARE WASHABLE AND REUSABLE AND ARE CUSTOM DESIGNED TO FIT INTO YOUR EXISTING FACTORY AIR BOX. THEIR DROP-IN DESIGN MEANS ADDING PERFORMANCE IS SIMPLE.	Avail to order Our Price: $55.37
410805396	FILTER BOX A.C. LEFT FILTER BOX A.C. LEFT	Current Stock: 1 Our Price: $150.29
410820367A	PARTICULATE FILTER PARTICULATE FILTER	Current Stock: 2 Our Price: $64.67
N10445602	BULB BULB	Avail to order Our Price: $17.45

Fuses-Bulbs-Relays

PN	Item
006617095	LICENSE PLATE LAMP REPLACEMENT BULB LICENSE PLATE LAMP REPLACEMENT BULB	Current Stock: 42 Our Price: $10.00
N10445703	HEADLIGHT BULB HEADLIGHT BULB	Current Stock: 8 Our Price: $181.42
N01713118	FUSE FUSE	Current Stock: 18 Our Price: $1.38
N0177522	BULB HEADLIGHT LAMP 12V/3W	Current Stock: 10 Our Price: $2.12
N0177532	LAMP BULB LAMP BULB	Avail to order Our Price: $1.52
N10525502	FUSE STRIP FUSE STRIP	Avail to order Our Price: $6.29

Gaskets

PN	Item	Diagram
0R1470106	GEAR BOX SUPPORT-GASKET SET GEAR BOX SUPPORT		Avail to order Our Price: $4,264.35
600940141L	LATCH GASKET LEFT LATCH GASKET SET LEFT THIS IS THE RUBBER/PLASTIC GASKET THAT IS LOCATED ON THE LEFT SIDE BETWEEN THE OUTER DOOR LATCH AND THE DOOR FRAME		Current Stock: 4 Our Price: $19.07

Ignition

PN	Item
7P0915105	BATTERY BATTERY	Avail to order Our Price: $545.66
07M905115B	IGNITION COIL IGNITION COIL	Avail to order Our Price: $244.51
410905619	SPARK PLUG SPARK PLUG - MURCIELAGO, MURCIELAGO LP640 - LP 670-4 - REVENTON SOLD EACH	Current Stock: 2 Our Price: $49.21

Misc

PN	Item
401955425C	WIPER BLADE (GALLARDO / MURCIELAGO) WIPER BLADE	Current Stock: 1 Our Price: $106.01
0R0000149	CLEANER FLUID 250ML CLEANER FLUID	Current Stock: 1 Our Price: $82.84
400093050D	CTEK US-CD BATTERY CHARGER INPUT 110-120VAC OUTPUT MAX 4.3A, 12V BACK DRAIN LESS THAN 1.5AM/MONTH	Avail to order Our Price: $417.39

Sensors

PN	Item
07L905163A	SEE PN 07L905163C PHASE SENSOR PLEASE CHECK CURRENT PRICING AS PRICE IS NOT UPDATED WHEN PART IS SUPERCEDED	Avail to order Our Price: $38.61
086141297	CLUTCH SENSOR CLUTCH SENSOR	Current Stock: 1 Our Price: $512.59
07L919561B	OIL PRESSURE GAUGE SENDER OIL PRESSURE GAUGE SENDER	Avail to order Our Price: $919.17
086927321	CRANK / FLYWHEEL / TIMING SENSOR ELECTROMAGNETIC PROBE	Avail to order Our Price: $129.03
036906262J	FRONT OXYGEN SENSOR FRONT OXYGEN SENSOR	Current Stock: 2 Our Price: $465.47
06A906262AT	OXYGEN SENSOR O2 SENSOR - LAMBDA PROBE OXYGEN SENSOR O2 SENSOR - LAMBDA PROBE	Current Stock: 22 Our Price: $153.21
07L919501A	WATER TEMPERATURE SENSOR WATER TEMPERATURE SENSOR	Current Stock: 3 Our Price: $371.24
07M905381	PHASE SENSOR PHASE SENSOR	Avail to order Our Price: $751.44
1K2945511	BRAKE PEDAL SWITCH NLA SWITCH BRAKE PEDAL NLA (NO LONGER AVAILABLE) FROM FACTORY. PLEASE CONTACT US FOR CURRENT PRICE AND AVAILABILITY.	Avail to order Our Price: $29.05
400698137	WORN PADS SENSOR WORN PADS SENSOR	Current Stock: 2 Our Price: $125.76
400907475A	PEDAL VALUE (POTENTIOMETER) PEDAL VALUE	Avail to order Our Price: $1,966.48
410919529	TEMPERATURE SENSOR TEMPERATURE SENSOR	Current Stock: 2 Our Price: $405.07
410919529A	TEMPERATURE SENSOR - MURCIELAGO TEMPERATURE SENSOR	Avail to order Our Price: $390.37
7PP907275F	WHEEL ELECTRONICS WHEEL ELECTRONICS	Avail to order Our Price: $185.62

Tools and Tookits

PN	Item
61195072	CAMSHAFT MECHANICAL PHASE TOOL CAMSHAFT MECHANICAL PHASE TOOL	Avail to order Our Price: $2,382.22
69795000805	V12 VALVE SEALING FITTING TOOL V12 VALVE SEALING FITTING TOOL	Avail to order Our Price: $434.20
wheeltool	WHEEL INSTALL TOOL SCREWS INTO HUB FOR EASY INSTALLATION.	Current Stock: 91 Our Price: $15.26

Open All

Select Group and TAV

< Previous Next >

TAV: 409.03.00 - FRONT DIFFERENTIAL CASE

2010 Lamborghini MURCIELAGO REVENTON ROADSTER EUROPE FRONT DIFFERENTIAL CASE (409.03.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Murcielago Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	N10545402	HEX. BOLT WITH WASHER SCREW M8X25.00-S1-N	8 req	Avail to order Our Price: $4.43
2	WHT001514	SPRING WASHER WASHER	8 req	Current Stock: 9 Our Price: $26.48
3	01S409410B	COVER COVER	1 req	Current Stock: 1 Our Price: $1,318.31
4	410805153	DIFFERENTIAL SUPPORT SUPPORT	1 req	Avail to order Our Price: $56.50
6	WHT001942	WASHER WASHER	3 req	Current Stock: 13 Our Price: $3.45
7	N0111849	HEX.HEAD CLAMPING NUT NUT M8	3 req	Current Stock: 5 Our Price: $2.39
8	410801499	SPACER SPACER	2 req	Avail to order Our Price: $75.54
9	WHT002639	HEXAGON HEAD BOLT SCREW M12X1.25X70X30	2 req	Current Stock: 1 Our Price: $7.26
10	410805991	ELASTIC SUPPORT SUPPORT	2 req	Current Stock: 2 2 Used Available Our Price: $196.69
11	WHT002158	RING 85 MM OR SEAL RING	2 req	Avail to order Our Price: $22.14
12	01S409448B	DIFFERENTIAL BOX FLANGE SHIM 0 2.0 MM ADJUSTMENT SHIM	2 req	Current Stock: 2 Our Price: $80.59
12	01S409448C	SPACER RING 0.075 MM ADJUSTMENT SHIM	3 req	Avail to order Our Price: $37.20
12	01S409448D	SPACER RING 0.050 MM ADJUSTMENT SHIM	3 req	Current Stock: 2 Our Price: $24.44
12	01S409448G	SPACER RING 1.0 MM ADJUSTMENT SHIM	1 req	Avail to order Our Price: $51.19
12	01S409448H	SPACER RING 2.0 MM ADJUSTMENT SHIM	2 req	Avail to order Our Price: $59.78
13	01S409828A	BEARING PLATE FLANGE	2 req	Avail to order Our Price: $929.44
14	01S409770	STRAIGHT ROLLER BEARING RACE BEARING	1 req	Avail to order Our Price: $357.16
15	01S409129A	FLANGE FLANGE	1 req	Avail to order Our Price: $1,259.41
16	01S409761	RING PIECE RING NUT	1 req	Avail to order Our Price: $246.73
17	01S409887	OIL SEAL SEAL RING	1 req	Current Stock: 7 Our Price: $75.54
18	N10545402	HEX. BOLT WITH WASHER SCREW M8X25.00-S1-N	6 req	Avail to order Our Price: $4.43
19	WHT001514	SPRING WASHER WASHER	6 req	Current Stock: 9 Our Price: $26.48
20	01S409561	BEARING BEARING	1 req	Avail to order Our Price: $60.04
21	N0123501	RETAINER RING RETAINING RING	2 req	Current Stock: 7 Our Price: $7.97
22	01S409435B	VISCOUS JOINT VISCOUS COUPLING	1 req	Avail to order Our Price: $6,378.02
23	01S409297	RETAINING RING SEAL RING	1 req	Avail to order Our Price: $20.01
24	01S409965	PLUG MAGNETIC PLUG	1 req	Current Stock: 5 Our Price: $186.33
25	01S409149A	FRONT DIFFERENTIAL HOUSING ONLY FRONT DIFFERENTIAL CASE	1 req	Avail to order Our Price: $12,719.28
26	086301141	MAGNETIC PLUG PLUG	1 req	Current Stock: 4 Our Price: $29.49
27	N0138492	SEALING WASHER WASHER	1 req	Current Stock: 26 Our Price: $3.45
28	01S919529	TEMP SENSOR SENSOR	1 req	Current Stock: 10 Our Price: $300.48
29	WHT003164	TAP END STUD STUD BOLT M8X35	12 req	Avail to order Our Price: $23.29
30	WHT001514	SPRING WASHER WASHER	12 req	Current Stock: 9 Our Price: $26.48
31	N01100845	HEX.NUT NUT M8X1,25X6,5	12 req	Current Stock: 17 Our Price: $2.04
32	WHT003164	TAP END STUD STUD BOLT M8X35	3 req	Avail to order Our Price: $23.29
33	410407295B	SPACER RING WASHER	2 req	Current Stock: 10 Our Price: $7.08
34	WHT003355	CLAMPING NUT NUT M12X1.25	2 req	Current Stock: 13 Our Price: $23.29
35	01S409267F	SPACER SLEEVE 1.0 MM SHIM	4 req	Avail to order Our Price: $44.90
36		OIL BREATHER PIPE (VALID UP TO MODEL YEAR 09)	0 req
37	400133338	GASKET GASKET	2 req	Avail to order Our Price: $72.00
38	01S409194	PROTECTIVE COVER BULKHEAD	1 req	Avail to order Our Price: $270.99
39	N90305304	HEXAGON FLANGE BOLT SCREW M6X10.0	2 req	Current Stock: 2 Our Price: $2.04
40	N90929202	FILLISTER HEAD SCREW M10X20.0	8 req	Avail to order Our Price: $3.98
41	02D525118B	ANGLED PIPE OIL BREATHER PIPE 90°	1 req	Avail to order Our Price: $16.47
42	01S409847	BREATHER TUBE OIL BREATHER PIPE	1 req	Avail to order Our Price: $116.10
43	N90686701	SPRING CLAMP CLAMP	1 req	Avail to order Our Price: $2.04
44	N0206027	HOLDING CLIP CLAMP	1 req	Avail to order Our Price: $4.16
45	N10338903	HEXAGON FLANGE SCREW M6X16	1 req	Avail to order Our Price: $57.83
46	01S409190	BUSH BUSHING	1 req	Avail to order Our Price: $25.59
47	WHT003078	REFERENCE PIN 8H7X16C40 DOWEL	2 req	Avail to order Our Price: $46.49
48	01S409149	DIFFERENTIAL GEARBOX HOUSING ONLY DIFFERENTIAL GEARBOX HOUSING ONLY	1 req	Current Stock: 1 Our Price: $2,430.45
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
