2009 MURCIELAGO LP 640 COUPE - CANADA

Group :

Tav :

Maintenance Parts:

Belts

PN	Item	Diagram
07M903137A	RIBBED V-BELT RIBBED V-BELT		Avail to order Our Price: $98.42

Brakes

PN	Item
410615301	BRAKE DISK PLEASE CHECK YOUR PART MANUAL FOR A DESCRIPTION	Avail to order Our Price: $2,146.16
0031016774	BRAKE PAD KIT FRONT - MURCIELAGO BRAKE PAD KIT	Avail to order Our Price: $1,264.31
410615301A	BRAKE CARBON ROTOR PLEASE CHECK YOUR PART MANUAL FOR A DESCRIPTION	Avail to order Our Price: $8,176.93
410615115D	E-BRAKE PAD - LATE DIABLO - MURCIELAGO SOLD EACH E-BRAKE PAD MURCIELAGO AND LATE DIABLO SOLD EACH	Current Stock: 1 Our Price: $51.35
410615601	BRAKE DISC BRAKE DISC	Current Stock: 7 Our Price: $2,039.20
410798041A	BRAKE PAD SET REAR CARBOCERAMIC - MURCIELAGO BRAKE PAD SET REAR CARBOCERAMIC - MURCIELAGO SOLD AS 2 PAIR FOR BOTH REAR ROTORS.	Avail to order Our Price: $1,188.90
400698451	BRAKE PAD KIT REAR - MURCIELAGO - GALLARDO - SOLD AS 2 PAIR REAR BRAKE PAD KIT SET OF 2 PAIR FOR BOTH REAR ROTORS	Avail to order Our Price: $652.01
4S0698151K	SET OF BRAKE PADS FOR CARBOCERAMIC DISC SET OF BRAKE PADS FOR DISC CARBOCERAMIC BRAKES OLD PN 4E0698151G	Current Stock: 1 Our Price: $851.83

Common repairs and upgrades

PN	Item
410837987	SHOCK ABSORBER SHOCK ABSORBER	Current Stock: 1 Our Price: $129.24
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO	Current Stock: 2 Our Price: $28.32
900000170	TUTELA CS SPEED FLUID -OIL LIFTING SYSTEM 1 LITER TUTELA CS SPEED FLUID -OIL LIFTING SYSTEM 1 LITER	Current Stock: 6 Our Price: $60.27

Drivetrain

PN	Item
086141671C	SEE PN 410141671 MURCI THROWOUT BEARING E-GEAR	Avail to order Our Price: $5,319.08
086141671B	MURCIELAGO CLUTCH ASSEMBLY MANUAL MURCIELAGO CLUTCH ASSEMBLY MANUAL NLA FROM FACTORY PLEASE CONTACT US FOR CURRENT PRICING AND AVAILABIILITY	Avail to order Our Price: $5,069.28
410721401	SEE PN 410721401A PLEASE CHECK YOUR PART MANUAL FOR A DESCRIPTION	Avail to order Our Price: $223.31
07M105269	MURCIELAGO LP640/670 CLUTCH (MANUAL AND EGEAR) BALANCED MECHANISM CLUTCH MURCIELAGO LP640 CLUTCH (MANUAL AND EGEAR)	Avail to order Our Price: $8,196.99
086141671K	SEE PN 086141671M CONCENTRIC SLAVE C WHEN A PART IS SUPERCEDED THE PRICE IS NO LONGER UPDATED FOR THE OLD PART NUMBER	Avail to order Our Price: $779.58
410721401A	MASTER CYLINDER 2008 AND UP MASTER CYLINDER	Avail to order Our Price: $435.18
086141671L	THROW OUT BEARING - EGEAR CONCENTRIC SLAVE CYLINDER FOR A LOWER COST ALTERNATIVE SEE OE SPEC BUT NON-OEM PN 086141671L-ALT IF REPLACING ORIGINAL 04-08 ALLARDO EQUIPMENT ALSO SEE PN: N10124306 X3	Avail to order Our Price: $1,898.82
07M115561B	SPIN-ON FILTER CARTUCCIS FIL.OLIO SPIN-ON FILTER CARTUCCIS FIL.OLIO	Current Stock: 8 Our Price: $198.37
N0138495	O-RING / WASHER O-RING	Current Stock: 47 Our Price: $3.13

Fuel-Air

PN	Item
07M133843	AIR FILTER - LM002, COUNTACH, DIABLO, MURCIELAGO PLEASE CHECK YOUR PART MANUAL FOR A DESCRIPTION FOR PERFORMANCE FILTERS SEE PN: 07M133843A	Current Stock: 2 Our Price: $28.15
400201511A	FUEL FILTER - DIABLO - GALLARDO - MURCIELAGO FUEL FILTER	Current Stock: 9 Our Price: $260.55
07M906031A	INJECTOR INJECTOR	Avail to order Our Price: $219.27
AMAIRD	HI-PERFORMANCE AFE AIR FILTER - DIABLO/MURCIELAGO - SPORT AIR FILTER MURCIELAGO - DIABLO AFTER MARKET AFE AIR FILTER 30-10133	Current Stock: 1 Our Price: $114.44
07M133843A	AIR FILTER - SPORT PERFORMANCE FILTER PERFORMANCE FILTER REPLACEMENT FOR 07M133843 AIR FILTER - MURCIELAGO SV LP 670-4	Avail to order Our Price: $695.65
07M133843KN	K&N AIR FILTER - LM002, COUNTACH, DIABLO, MURCIELAGO K&N'S REPLACEMENT AIR FILTERS ARE DESIGNED TO INCREASE HORSEPOWER AND ACCELERATION WHILE PROVIDING EXCELLENT FILTRATION. THESE FILTERS ARE WASHABLE AND REUSABLE AND ARE CUSTOM DESIGNED TO FIT INTO YOUR EXISTING FACTORY AIR BOX. THEIR DROP-IN DESIGN MEANS ADDING PERFORMANCE IS SIMPLE.	Avail to order Our Price: $55.37
410805396	FILTER BOX A.C. LEFT FILTER BOX A.C. LEFT	Current Stock: 1 Our Price: $136.41
410820367A	PARTICULATE FILTER PARTICULATE FILTER	Current Stock: 2 Our Price: $63.63

Fuses-Bulbs-Relays

PN	Item
006617091	BULB 21W TAIL LIGHT 21W BULB	Current Stock: 4 Our Price: $12.04
006617094	LAMP BA 15S 21W BULB LAMP BA 15S 21W USED IN VARIOUS LAMPS (DEPENDING ON YOUR YEAR AND MODEL)	Current Stock: 76 Our Price: $8.80
006617095	LICENSE PLATE LAMP REPLACEMENT BULB LICENSE PLATE LAMP REPLACEMENT BULB	Current Stock: 42 Our Price: $9.86
N0177522	BULB HEADLIGHT LAMP 12V/3W	Current Stock: 10 Our Price: $1.91
410953227B	RELAY RELAY	Avail to order Our Price: $346.30
N01713118	FUSE FUSE	Current Stock: 18 Our Price: $1.50
N0177532	LAMP BULB LAMP BULB	Avail to order Our Price: $1.60
N10445703	HEADLIGHT BULB HEADLIGHT BULB	Current Stock: 8 Our Price: $178.53
N10525502	FUSE STRIP FUSE STRIP	Avail to order Our Price: $5.72

Gaskets

PN	Item	Diagram
0R1470106	GEAR BOX SUPPORT-GASKET SET GEAR BOX SUPPORT		Avail to order Our Price: $3,871.18
600940141L	LATCH GASKET LEFT LATCH GASKET SET LEFT THIS IS THE RUBBER/PLASTIC GASKET THAT IS LOCATED ON THE LEFT SIDE BETWEEN THE OUTER DOOR LATCH AND THE DOOR FRAME		Current Stock: 4 Our Price: $19.07

Ignition

PN	Item
410905619	SPARK PLUG SPARK PLUG - MURCIELAGO, MURCIELAGO LP640 - LP 670-4 - REVENTON SOLD EACH	Current Stock: 2 Our Price: $48.45
7L0915105	SEE PN 000915105CC BATTERY VARTA 12V 68 AH 38A DIN	Avail to order Our Price: $776.30
7P0915105	BATTERY BATTERY	Avail to order Our Price: $536.96
07M905115B	IGNITION COIL IGNITION COIL	Current Stock: 1 Our Price: $221.94

Misc

PN	Item
401955425C	WIPER BLADE (GALLARDO / MURCIELAGO) WIPER BLADE	Current Stock: 1 Our Price: $104.37
0R0000149	CLEANER FLUID 250ML CLEANER FLUID	Current Stock: 1 Our Price: $86.14
0R1470029	TRANSPARENT ENGINE BONNET KIT 2002-2010 MURCIELAGO COUPE TRANSPARENT ENGINE BONNET KIT FOR 2002-2010 MURCIELAGO COUPE INCLUDES 418827023A TRUNK LID X 1 418827401 GAS SPRING X 2 418827631A GLASS BONNET X 1 418827632A GLASS BONNET X 1 418827651 PROFILE SEAL X 2 418827652 PROFILE SEAL X 2 895827439B BALL PINN X 2 410827602 SHOCK ABSORBER FASTENING BRACKET X 1 410827601 SHOCK ABSORBER FASTENING BRACKET X 1 418827322A HOOK X 1 N90319404 HEXAGON FLANGE X 7 WHT003407 WASHER X 7	Avail to order Our Price: $13,107.77
400093050D	CTEK US-CD BATTERY CHARGER INPUT 110-120VAC OUTPUT MAX 4.3A, 12V BACK DRAIN LESS THAN 1.5AM/MONTH	Avail to order Our Price: $434.04
410601147CV	MOLDING AND HUP-CAP - COLORED (HERMERA SILVER) WHEEL TRIM SET OF 4 FITS ALL RIMS EXCEPT HERCULES & CASSIOPEA	Current Stock: 4 Our Price: $267.03

Sensors

PN	Item
06A906262AT	OXYGEN SENSOR O2 SENSOR - LAMBDA PROBE OXYGEN SENSOR O2 SENSOR - LAMBDA PROBE	Current Stock: 24 Our Price: $139.08
410919529	TEMPERATURE SENSOR TEMPERATURE SENSOR	Current Stock: 2 Our Price: $367.74
410919529A	TEMPERATURE SENSOR - MURCIELAGO TEMPERATURE SENSOR	Avail to order Our Price: $354.39
036906262J	FRONT OXYGEN SENSOR FRONT OXYGEN SENSOR	Current Stock: 4 Our Price: $422.52
07L905163A	SEE PN 07L905163C PHASE SENSOR	Avail to order Our Price: $35.02
07L919501A	WATER TEMPERATURE SENSOR WATER TEMPERATURE SENSOR	Current Stock: 3 Our Price: $336.99
07L919561B	OIL PRESSURE GAUGE SENDER OIL PRESSURE GAUGE SENDER	Avail to order Our Price: $834.43
07M905381	PHASE SENSOR PHASE SENSOR	Avail to order Our Price: $755.93
086141297	CLUTCH SENSOR CLUTCH SENSOR	Current Stock: 1 Our Price: $465.34
086927321	CRANK / FLYWHEEL / TIMING SENSOR ELECTROMAGNETIC PROBE	Avail to order Our Price: $117.14
1K2945511	BRAKE PEDAL SWITCH SWITCH BRAKE PEDAL	Avail to order Our Price: $26.32
400698137	WORN PADS SENSOR WORN PADS SENSOR	Current Stock: 2 Our Price: $114.21
400907475A	PEDAL VALUE (POTENTIOMETER) PEDAL VALUE	Avail to order Our Price: $1,785.14
7PP907275F	WHEEL ELECTRONICS WHEEL ELECTRONICS	Avail to order Our Price: $168.46

Tools and Tookits

PN	Item
61195072	CAMSHAFT MECHANICAL PHASE TOOL CAMSHAFT MECHANICAL PHASE TOOL	Avail to order Our Price: $2,460.58
69795000805	V12 VALVE SEALING FITTING TOOL V12 VALVE SEALING FITTING TOOL	Avail to order Our Price: $448.52
wheeltool	WHEEL INSTALL TOOL SCREWS INTO HUB FOR EASY INSTALLATION.	Current Stock: 93 Our Price: $15.26

Open All

Select Group and TAV

< Previous Next >

TAV: 311.03.00 - DRIVEN SHAFT

2009 Lamborghini MURCIELAGO LP 640 COUPE CANADA DRIVEN SHAFT (311.03.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Murcielago Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	086311244B	SYNCHRONIZER HUB SYNCHRONIZER T.C. D.100+CROWN GEAR	1 req	Avail to order Our Price: $1,738.37
2	086311250F	INDEXING WHEEL,1ST FIRST GEAR ASSEMBLY (Order linked to the ref. 9 tav. 311.02.00)	1 req	Avail to order Our Price: $2,065.98
3	086311228A	NEEDLE CAGE ROLLER CAGE	5 req	Avail to order Our Price: $103.00
4	086301374A	BUSH BUSHING	2 req	Avail to order Our Price: $316.24
5	086311279A	OUTER RING SHIM ADJUSTMENT	1 req	Avail to order Our Price: $343.63
6	086311762C	SYNCHRONIZER HUB SYNCHRONIZING GEAR D.82 + CROWN GEAR	1 req	Avail to order Our Price: $867.85
7	086311532F	INTERMEDIATE WHEEL REVERSE GEAR ASSEMBLY + SYNCHRO	1 req	Avail to order Our Price: $648.58
8	086311423B	BUSH INNER RING	1 req	Avail to order Our Price: $462.65
9	086311195F	OUTPUT SHAFT SHAFT	1 req	Avail to order Our Price: $1,457.53
10	WHT003585	SEEGER RING SEAL RING	2 req	Avail to order Our Price: $44.78
11	086301609	BEARING BEARING Ø85	1 req	Current Stock: 2 Our Price: $175.17
12	086311348B	GEAR GEAR	1 req	Avail to order Our Price: $3,677.24
13	WHT003573	O-RING RING RETAINING RING	1 req	Current Stock: 4 Our Price: $2.52
14	086301897	BEARING BEARING	1 req	Current Stock: 1 Our Price: $522.85
15	086301618	RING NUT RING NUT	2 req	Avail to order Our Price: $276.13
17	086311270E	INDEXING WHEEL, 2 GEAR ASSEMBLY	1 req	Avail to order Our Price: $1,798.49
18	086311533A	BUSH INNER RING	2 req	Avail to order Our Price: $370.41
19	WHT003584	CHECK PART MANUAL SEAL RING	4 req	Avail to order Our Price: $30.75
20	086311187B	RING INNER RING	1 req	Avail to order Our Price: $336.99
21	086311129B	INDEXING WHEEL,3RD THIRD GEAR ASSEMBLY	1 req	Avail to order Our Price: $1,678.17
22	086311309B	SYNCHRONIZER HUB SYNCHRONIZING GEAR D.71/76 + CROWN GEAR	1 req	Avail to order Our Price: $1,390.69
23	086311145C	INDEXING WHEEL, FOURTH GEAR ASSEMBLY	1 req	Avail to order Our Price: $1,678.17
24	086311153	5TH SPEED GEAR FIFTH GEAR	1 req	Avail to order Our Price: $3,657.21
25	086311165	6TH SPEED GEAR SIXTH GEAR	1 req	Avail to order Our Price: $3,657.21
26	086311876C	SPACER SPACER	1 req	Avail to order Our Price: $184.56
27	086301845	CHECK MANUAL FOR DESCRIPTION BEARING	1 req	Avail to order Our Price: $72.61
28	086311388	RETAINING RING SHIM ADJUSTMENT	2 req	Avail to order Our Price: $35.84
29	086311770A	NEEDLE BEARING ROLLER CAGE	2 req	Current Stock: 2 Our Price: $43.64
30	086311531C	REVERSE IDLE GEAR	1 req
31	WHT003165	TAP END STUD STUD BOLT M6X25	1 req	Current Stock: 3 Our Price: $1.90
32	086311509	IDLE GEAR SHAFT RM REVERS IDLE GEAR SHAFT	1 req	Current Stock: 1 Our Price: $351.68
33	WHT001197A	WASHER WASHER	1 req	Current Stock: 2 Our Price: $0.40
34	WHT002953	CLAMPING NUT NUT M6	1 req	Current Stock: 4 Our Price: $3.36
36	WHT003587	CHECK PART MANUAL SEAL RING	1 req	Avail to order Our Price: $13.12
37	086311440	CHECK MANUAL FOR DESCRIPTION BEARING	1 req	Avail to order Our Price: $172.49
39	WHT003582	CHECK PART MANUAL RETAINING RING	1 req	Avail to order Our Price: $20.52
40	086311834A	INDEXING WHEEL GEAR	1 req	Avail to order Our Price: $1,119.24
41	086311439	BEARING BEARING	1 req	Current Stock: 1 Our Price: $63.52
42	086311667	THREADED BUSHING RING NUT	1 req	Avail to order Our Price: $132.92
43	WHT003580	SECURING RING SEAL RING	1 req	Avail to order Our Price: $14.57
44	086301133	BEARING BEARING Ø80	1 req	Avail to order Our Price: $115.27
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
