TAV: 32.01.00 - REAR BRAKES

2006 Lamborghini MURCIELAGO COUPE JAPAN REAR BRAKES (32.01.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Murcielago Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	WHT001330	HEXAGON SOCKET SCREW	4 req	Avail to order Our Price: $36.32
2		ELECTRIC CABLE (CANNOT BE SOLD SEPARATELY - SEE REF. 11)	0 req
3	400611775A	BRAKE HOSE HOSE	2 req	Avail to order Our Price: $169.73
4	410615403A	LH HANDBRAKE SHOE LH BRAKE CALIPER	1 req	Avail to order Our Price: $841.18
4	410615404A	RH HANDBRAKE SHOE RH BRAKE CALIPER	1 req	Avail to order Our Price: $841.18
5	WHT002636	HEXAGON HEAD BOLT SCREW	2 req	Avail to order Our Price: $8.54
6	008700854	SCREW SCREW	2 req	Avail to order Our Price: $1.10
7	410615115D	E-BRAKE PAD - LATE DIABLO - MURCIELAGO SOLD EACH PADS	4 req	Current Stock: 3 Our Price: $57.74
8	N10572401	SCREW SCREW	6 req	Current Stock: 9 Our Price: $1.10
9	WHT000771	SPRING LOCK WASHER WASHER	6 req	Current Stock: 10 Our Price: $1.30
10	410615601	BRAKE DISC BRAKE DISK	2 req	Current Stock: 7 Our Price: $2,270.39
11	410615405	LH REAR BRAKE CALIPER BLACK BLACK LH REAR BRAKE CALIPER	1 req	Avail to order Our Price: $1,607.88
11	410615405A	BRAKE CALIPER ASS. GREY LH REAR BRAKE CALIPER	1 req	Avail to order Our Price: $1,764.21
11	410615405B	BRAKE CALIPER ASS. YELLOW LH REAR BRAKE CALIPER	1 req	Current Stock: 1 Our Price: $1,682.35
11	410615406	RH REAR BRAKE CALIPER BLACK BLACK RH REAR BRAKE CALIPER	1 req	Avail to order Our Price: $1,607.88
11	410615406A	BRAKE CALIPER ASS. GREY RH REAR BRAKE CALIPER	1 req	Avail to order Our Price: $1,764.21
11	410615406B	BRAKE CALIPER ASS. YELLOW RH REAR BRAKE CALIPER	1 req	Current Stock: 1 Our Price: $1,682.35
12	400698451	BRAKE PAD KIT REAR - MURCIELAGO - GALLARDO - SOLD AS 2 PAIR BRAKE PAD SET	1 req	Avail to order Our Price: $733.53
13	400698135A	FASTENING PART JOURNAL AND CLIP	2 req	Avail to order Our Price: $63.41
14	WHT003303	BANJO BOLT SCREW WITH HOLE	2 req	Avail to order Our Price: $13.89
15	WHT001191	COPPER WASHER WASHER	2 req	Current Stock: 5 Our Price: $0.40
16	WHT001191	COPPER WASHER WASHER	2 req	Current Stock: 5 Our Price: $0.40
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
