TAV: 45.01.00 - AIR CONDITIONING SYSTEM

2006 Lamborghini MURCIELAGO COUPE CANADA AIR CONDITIONING SYSTEM (45.01.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Murcielago Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	410260805A	COMPRESSOR COMPRESSOR	1 req	Avail to order Our Price: $4,198.31
2	410260193	SHEATH SHEATH	1 req	Avail to order Our Price: $4.47
3	410971919	AMP CONNECTOR WASHER RUBBER	1 req	Avail to order Our Price: $0.20
4	410971996	THERM. AMP N.282110-1 TAB	1 req	Avail to order Our Price: $0.30
5	410971833	ONE-PIN CONNECTOR CONNECTION	1 req	Avail to order Our Price: $3.01
6		STRUT (VALID FOR A DIFFERENT MODEL YEAR)	0 req
7	WHT000768	SPRING WASHER WASHER	8 req	Current Stock: 17 Our Price: $2.14
8	008701020	SCREW M10X50 UNI 5931/8G/Z D SCREW	8 req	Current Stock: 8 Our Price: $1.70
9	008701026	SCREW 10 X 1,5 X 80 SCREW	2 req	Current Stock: 1 Our Price: $2.33
10	008701032	SCREW SCREW	1 req	Avail to order Our Price: $8.84
11	008201008	NUT NUT	5 req	Current Stock: 2 Our Price: $0.90
12		PROTECTION (VALID FOR A DIFFERENT MARKET/MODEL YEAR)	0 req
13		WASHER (VALID FOR A DIFFERENT MARKET/MODEL YEAR)	0 req
14		SCREW (VALID FOR A DIFFERENT MARKET/MODEL YEAR)	0 req
15	07M145169A	BRACKET,POWER TAKE BRACKET (FROM VIN 5LA01545)	1 req	Current Stock: 1 Our Price: $1,140.44
16	0045014832	SPECER SPACER (FROM VIN 5LA01545)	1 req	Avail to order Our Price: $36.22
17	410260963	SHEET PANEL (FROM VIN 5LA01545)	1 req	Avail to order Our Price: $307.42
18	008100826	SCREW M8X16 UNI 5739/8G/Z SCREW (FROM VIN 5LA01545)	1 req	Avail to order Our Price: $0.50
19	WHT000771	SPRING LOCK WASHER WASHER (FROM VIN 5LA01545)	1 req	Current Stock: 10 Our Price: $1.30
20	008100876	SCREW SCREW (FROM VIN 5LA01545)	1 req	Avail to order Our Price: $0.70
21	WHT000771	SPRING LOCK WASHER WASHER (FROM VIN 5LA01545)	1 req	Current Stock: 10 Our Price: $1.30
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
