TAV: 59.02.00 - HI-FI SYSTEM

2005 Lamborghini MURCIELAGO ROADSTER JAPAN HI-FI SYSTEM (59.02.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Murcielago Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1		GRUNDIG GHK24.00 CAR HI-FI SYSTEM (VALID FOR A DIFFERENT MARKET)	0 req
2	410035183	car radio CAR HI-FI SYSTEM ALPINE JPN CDA 9831J	1 req	Avail to order Our Price: $3,379.49
3	0059013379	ADAPTER ANTENNA CABLE (NOT FOR CARS WITH NAVIGATION SYSTEM)	1 req	Avail to order Our Price: $13.48
4	410035110B	DVD PLAYER WITH MAP CD CD CHANGER CHA-S634 ALPINE (For Alpine Radio System)	1 req	Avail to order Our Price: $1,469.41
5		GRUNDIG CD LOADER (VALID FOR A DIFFERENT MARKET)	0 req
6	410035361A	LOUDSPEAKER CAR LOUDSPEAKER KIT	1 req	Avail to order Our Price: $1,137.42
7	0061013285	HARNESS CABLE (For Alpine Radio System)	1 req	Avail to order Our Price: $363.26
8	410035225	AMPLIFIER ANTENNA AMPLIFIER	1 req	Avail to order Our Price: $143.67
9	410035550	Aerial Wire CABLE	1 req	Avail to order Our Price: $41.62
10		CD/MP3 USA CDA-7897 PLAYER (VALID FOR A DIFFERENT MARKET/MODEL YEAR)	0 req
11		BECKER(P.H.S.) EU CD ROAD MAP (VALID FOR A DIFFERENT MARKET)	0 req
12		BECKER(P.H.S.) USA CD-2 ROAD MAP (VALID FOR A DIFFERENT MARKET)	0 req
13	410971952	Amplifier Frame ShimD.6.1x10x5 SHIM	8 req	Current Stock: 5 Our Price: $2.76
14	008220402	Clip CLIP	8 req	Current Stock: 8 Our Price: $5.14
15	N0139821	SCREW SCREW	8 req	Current Stock: 20 Our Price: $2.00
16	410035459	FRAME ORNAMENT KTA-145D	1 req	Avail to order Our Price: $75.93
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
