2005 MURCIELAGO ROADSTER - AUSTRALIA

Maintenance Parts:

Belts

PN	Item	Diagram
07M903137	CONTROL BELT (ACCESSORIES) Please Check your Part Manual for a Description		Avail to order Our Price: $158.99

Brakes

PN	Item
410615301	brake disk Please Check your Part Manual for a Description	Avail to order Our Price: $2,238.75
0031016774	Brake Pad Kit Front - Murcielago Brake pad kit	Avail to order Our Price: $1,335.19
410615301A	BRAKE CARBON ROTOR Please Check your Part Manual for a Description	Avail to order Our Price: $8,517.31
4E0698151G	See PN 4S0698151K Front Brake pads Set carbon ceramic brakes	Avail to order Our Price: $839.54
410615601	BRAKE DISC BRAKE DISC	Current Stock: 7 Our Price: $2,131.12
410615115D	E-Brake Pad - Late Diablo - Murcielago Sold Each E-Brake Pad Murcielago and late Diablo Sold Each	Avail to order Our Price: $54.17
410798041A	Brake Pad Set Rear Carboceramic - Murcielago Brake Pad Set Rear Carboceramic - Murcielago Sold as 2 pair for both rear rotors.	Avail to order Our Price: $1,254.62
400698451	Brake Pad Kit Rear - Murcielago - Gallardo - Sold as 2 pair Rear Brake Pad Kit Set of 2 Pair for both Rear Rotors	Avail to order Our Price: $689.18

Drivetrain

PN	Item
07M105269A	Murcielago Balanced Clutch Kit (Flywheel, Disk, Pressure plate) FLYWHEEL,COMPL.	Avail to order Our Price: $7,060.69
086141671C	Murci ThrowOut Bearing E-Gear Please Check your Part Manual for a Description	Avail to order Our Price: $4,633.53
086141671B	Murci ThrowOut Bearing Manual Please Check your Part Manual for a Description	Avail to order Our Price: $4,416.34
410721401	SEE PN 410721401A Please Check your Part Manual for a Description	Avail to order Our Price: $233.20
07M115561	see PN 07M115561B Oil Filter Cartridge	Avail to order Our Price: $48.56
07M105269	MURCIELAGO LP640/670 CLUTCH (MANUAL AND EGEAR) BALANCED MECHANISM CLUTCH MURCIELAGO LP640 CLUTCH (MANUAL AND EGEAR)	Avail to order Our Price: $7,620.37
07M115561B	SPIN-ON FILTER CARTUCCIS FIL.OLIO SPIN-ON FILTER CARTUCCIS FIL.OLIO	Current Stock: 2 Our Price: $48.56

Fuel-Air

PN	Item
07M133843	Air Filter - LM002, Countach, Diablo, Murcielago Please Check your Part Manual for a Description For performance filters see PN: 07M133843A	Current Stock: 1 Our Price: $29.72
400201511A	Fuel Filter - Diablo - Gallardo - Murcielago FUEL FILTER	Avail to order Our Price: $274.81
07M906031	Fuel Injector (sold ea) Please Check your Part Manual for a Description	Avail to order Our Price: $1,277.24
AMAIRD	Hi-Performance aFe Air Filter - Diablo/Murcielago - SPORT Air Filter Murcielago - Diablo After Market aFe Air Filter 30-10133	Current Stock: 1 Our Price: $140.40
07M133843KN	K&N Air Filter - LM002, Countach, Diablo, Murcielago K&N's replacement air filters are designed to increase horsepower and acceleration while providing excellent filtration. These filters are washable and reusable and are custom designed to fit into your existing factory air box. Their drop-in design means adding performance is simple.	Avail to order Our Price: $67.93
0062003086	Filter Filter	Current Stock: 7 Our Price: $2,201.34
400201511AZ	OE Spec Aftermarket Fuel Filter - Diablo - Gallardo - Murcielago FUEL FILTER	Avail to order Our Price: $88.39
410805396	FILTER BOX Please Check your Part Manual for a Description	Current Stock: 1 Our Price: $141.50
410820367A	PARTICULATE FILTER PARTICULATE FILTER	Current Stock: 2 Our Price: $67.20
07M133843A	Air Filter - SPORT PERFORMANCE FILTER Performance filter replacement for 07M133843 Air Filter - Murcielago SV LP 670-4	Avail to order Our Price: $733.78

Fuses-Bulbs-Relays

PN	Item
006617095	Bulb for license plate lamp Bulb LAMP SV8,5-8 5W	Current Stock: 42 Our Price: $10.36
006617091	Bulb 21w tail light 21w Bulb	Current Stock: 5 Our Price: $12.67
006617094	Check Parts Manual for location Bulb LAMP BA 15S 21W Used in various lamps (depending on your year and model)	Current Stock: 77 Our Price: $9.28
N0177522	bulb Headlight LAMP 12V/3W	Current Stock: 10 Our Price: $2.01
N10445601	SEE PN N10445602 Headlight BULB H21W-12V21W	Avail to order Our Price: $26.91
N10525502	FUSE STRIP FUSE STRIP	Avail to order Our Price: $5.89
N01713118	FUSE Please Check your Part Manual for a Description	Current Stock: 18 Our Price: $2.00
N10445703	HEADLIGHT BULB D2SLL-12V35W Please Check your Part Manual for a Description	Current Stock: 8 Our Price: $188.49
N0177532	LAMP BULB LAMP BULB	Avail to order Our Price: $2.00

Gaskets

PN	Item	Diagram
0011014183	Engine Gasket Set Murcielago Engine Gasket Set Murcielago		Avail to order Our Price: $2,697.99
600940141L	latch Gasket Left latch Gasket Set Left This is the rubber/plastic gasket that is located on the Left side between the outer door latch and the door frame		Current Stock: 5 Our Price: $23.40

Ignition

PN	Item
0R1470187	Ignition Coil Kit (Set of 12) KIT 12 IGNITION COILS	Avail to order Our Price: $618.53
410915105A	BATTERY Please Check your Part Manual for a Description	Avail to order Our Price: $889.17
0016003036	Spark Plug sold ea - Diablo and Murcielago Spark Plug	Avail to order Our Price: $60.79

Misc

PN	Item
410601147CV	MOLDING AND HUP-CAP - COLORED (HERMERA SILVER) WHEEL TRIM set of 4 Fits All Rims Except Hercules & Cassiopea	Current Stock: 4 Our Price: $327.60
900000382	NLA use PN 400093050D for USA replacement	Avail to order Our Price: $190.57
900000381	NLA (No Longer Available) Comes with Eyelet connects, Clamp connectors and Cigar Lighter Adapter.	Avail to order Our Price: $190.57
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month	Avail to order Our Price: $317.22

Sensors

PN	Item
06A906262AT	O2 SENSOR-LAMBDA PROBE LAMBDA PROBE	Avail to order Our Price: $144.23
410919529	TEMPERATURE SENSOR TEMPERATURE SENSOR	Current Stock: 3 Our Price: $383.18
410919529A	TEMPERATURE SENSOR - MURCIELAGO TEMPERATURE SENSOR	Avail to order Our Price: $368.82
07M919529	Engine Air Temperature Sensor Engine Air Temperature Sensor	Current Stock: 1 Our Price: $287.75
07L919501A	Water Temperature Sensor Water Temperature Sensor	Current Stock: 3 Our Price: $350.89
07M905381	Phase Sensor Phase Sensor	Avail to order Our Price: $658.83
086141297	CLUTCH SENSOR CLUTCH SENSOR	Avail to order Our Price: $479.33
3B0945511C	SEE PN 1K2945511 SWITCH,BRAKE PEDAL	Avail to order Our Price: $10.76
400698137	Worn Pads Sensor Worn Pads Sensor	Current Stock: 2 Our Price: $118.98
086927321	Crank/Flywheel/Timing Sensor ELECTROMAGNETIC PROBE	Avail to order Our Price: $121.99
07L919561B	OIL PRESSURE GAUGE SENDER OIL PRESSURE GAUGE SENDER	Avail to order Our Price: $858.19
400907475A	PEDAL VALUE (Potentiometer) PEDAL VALUE	Avail to order Our Price: $1,858.46
0R1470156	MURCIELAGO AND DIABLO 6.0 MIN-MAX LIFT SYSTEM SENSORS KIT MURCIELAGO AND DIABLO 6.0 MIN-MAX LIFT SYSTEM SENSORS KIT	Avail to order Our Price: $993.10

Open All

Select Group and TAV

- 23.01.00 FRONT DIFFERENTIAL CASE
- 40.02.00 POWER STEERING
11-CYLINDER HEAD
- 11.01.00 RIGHT CYLINDER HEAD
- 11.02.00 LEFT CYLINDER HEAD
- 11.03.00 GASKET KIT
12-TIMING SYSTEM
- 12.01.00 LEFT HEAD TIMING SYSTEM
- 12.02.00 RIGHT HEAD TIMING SYSTEM
- 12.03.00 TIMING SYSTEM
13-INTAKE MANIFOLD
- 13.01.00 INTAKE MANIFOLD
- 13.02.00 INTAKE MANIFOLD
- 13.03.00 AIR FILTERS
14-CRANK GEARS
- 14.01.00 CRANK GEARS
15-ENGINE OIL PUMP
- 15.01.00 ENGINE OIL PUMP
- 15.03.00 ENGINE OIL SYSTEM
16-ELECTRICAL SYSTEM
- 16.01.00 PHASE SENSORS AND ELECTRICAL COMPONENTS
- 16.02.00 ALTERNATOR
- 16.04.00 INJECTION AND E-GEAR E.C.U.
17-WATER PUMP
- 17.01.00 WATER PUMP
- 17.02.00 WATER COOLING SYSTEM
- 17.03.00 RADIATORS AND ELECTRIC FANS
18-CRANKCASE AND OIL SUMP
- 18.01.00 CRANKCASE
- 18.02.00 CRANKCASE AND LOWER MOUNTING
- 18.03.00 OIL SUMP
- 18.04.00 ENGINE
21-CLUTCH
- 21.02.00 E-GEAR CLUTCH
22-PROPELLER SHAFT
- 22.01.00 FRONT PROPELLER SHAFT
23-FRONT DIFFERENTIAL
- 23.01.00 FRONT DIFFERENTIAL CASE
- 23.02.00 FRONT DIFFERENTIAL
- 23.03.00 FRONT DIFFERENTIAL
24-GEARBOX
- 24.01.00 MANUAL SHIFT LEVER SUPPORT
- 24.02.00 GEARBOX SHIFTING RODS AND FORKS
- 24.03.00 GEARBOX
- 24.04.00 GEARBOX OIL PUMP
- 24.05.00 MAIN SHAFT
- 24.06.00 DRIVEN SHAFT
- 24.08.00 E-GEAR VALVE ASSY
- 24.09.00 GEARBOX ASSEMBLY
25-AXLE SHAFTS
- 25.01.00 AXLE SHAFTS AND PROPELLER SHAFT
26-REAR DIFFERENTIA
- 26.01.00 REAR DIFFERENTIAL CASE
- 26.02.00 REAR DIFFERENTIAL
- 26.03.00 REAR DIFFERENTIAL
31-BRAKES
- 31.01.00 FRONT BRAKES
- 31.02.00 BRAKE SYSTEM
- 31.03.00 ELECTROHYDRAULIC ABS CU
32-BRAKES
- 32.01.00 REAR BRAKES
33-HAND BRAKE
- 33.01.00 HAND BRAKE
40-POWER STEERING
- 40.02.00 POWER STEERING
41-FRAME ELEMENTS
- 41.01.00 FRAME ELEMENTS
- 41.02.00 AUXILIARY FRAME
42-PEDALS
- 42.01.00 MANUAL PEDAL CLUSTER
- 42.03.00 E-GEAR CONTROL PEDAL
- 42.04.00 PEDAL SUPPORT
43-STEERING
- 43.01.00 STEERING
- 43.02.00 STEERING
- 43.03.00 STEERING
- 43.04.00 STEERING
- 43.05.00 KEY KIT
44-EXHAUST SYSTEM
- 44.01.00 EXHAUST SYSTEM
- 44.03.00 EXHAUST SYSTEM
- 44.04.00 EXHAUST SYSTEM
45-CLIMATE CONTROL
- 45.01.00 AIR CONDITIONING SYSTEM
- 45.02.00 AIR CONDITIONING SYSTEM
- 45.03.00 AIR CONDITIONING SYSTEM
51-FRONT SUSPENSION
- 51.02.00 FRONT SUSPENSION
- 51.04.00 JACKING SYSTEM
- 51.05.00 FRONT WHEEL AND HUB CARRIER
52-REAR SUSPENSION
- 52.02.00 REAR SUSPENSION
- 52.03.00 REAR WHEEL AND HUB CARRIER
59-ACCESSORIES
- 59.01.00 ACCESSORIES
- 59.02.00 HI-FI SYSTEM
- 59.03.00 NAMEPLATES
60-INSTRUMENTS
- 60.01.00 DASHBOARD INSTRUMENTS
- 60.02.00 ROLL BAR
61-ELECTRICAL SYSTEM
- 61.01.00 ELECTRICAL SYSTEM
- 61.02.00 ELECTRICAL SYSTEM
- 61.04.00 ELECTRICAL SYSTEM
- 61.05.00 ELECTRICAL SYSTEM
62-FUEL SYSTEM
- 62.01.00 FUEL SYSTEM
- 62.02.00 FUEL SYSTEM
- 62.03.00 FUEL SYSTEM
- 62.04.00 FUEL SYSTEM
- 62.05.00 FUEL SYSTEM
63-LIGHTS
- 63.01.00 LIGHTS
66-OUTER PANELS AND PLATES
- 66.01.00 REAR BODY ELEMENTS
- 66.02.00 FUEL CAP
- 66.03.00 FRONT BODY ELEMENTS
- 66.06.00 BODY ELEMENTS - LEFT SIDE
- 66.07.00 BODY ELEMENTS - RIGHT SIDE
68-FRAME FLOOR PANELS
- 68.01.00 FRAME FLOOR PANELS
- 68.03.00 ENGINE COMPARTMENT INSULATING PANELS
- 68.04.00 ENGINE COMPARTMENT PANELS
70-WINDOWS
- 70.02.00 WINDOWS
71-WINDSHIELD WIPER
- 71.02.00 WINDSHIELD WIPER
72-DOORS
- 72.01.00 DOORS
- 72.02.00 DOORS
- 72.04.00 DOORS
73-REAR HOOD
- 73.01.00 REAR HOOD AND SPOILER
74-AIR INTAKE
- 74.01.00 AIR INTAKE
75-SEATS
- 75.02.00 SEATS AND SAFETY BELTS
77-INSULATIONS AND SOUNDPROOFING
- 77.02.00 PASSENGER COMPARTMENT INSULATIONS
78-PASSENGER COMPARTMENT FINISHING
- 78.01.00 PASSENGER COMPARTMENT TRIMS
- 78.04.00 COCKPIT CARPETS
- 78.05.00 PASSENGER COMPARTMENT TRIMS
- 78.06.00 PASSENGER COMPARTMENT TRIMS
79-FRONT HOOD
- 79.01.00 FRONT HOOD
- 79.02.00 COVERING
92-ENGINE HOOD
- 92.02.00 ENGINE HOOD
93-BUMPERS
- 93.01.00 BUMPERS
97-EXTERNAL REAR VIEW MIRRORS
- 97.01.00 EXTERNAL REAR VIEW MIRRORS
- 97.02.00 SOFT-TOP

< Previous Next >

TAV: 24.03.00 - GEARBOX

2005 Lamborghini MURCIELAGO ROADSTER AUSTRALIA GEARBOX (24.03.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Murcielago Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	086311520	DISCONTINUED - NLA - CONTACT US SEAL RING	1 req	*See Description
2	086311621	Bushing 16x18x25 mm BUSHING	1 req	Avail to order Our Price: $27.42
3	086311281A	DETENT PAWL	3 req	Avail to order Our Price: $46.14
4	086311281B	DETENT PAWL	2 req	Avail to order Our Price: $46.14
5	086301201B	GEARBOX UPPER COVER ASSEMBLY COVER (MANUAL GEARBOX)	1 req	Avail to order Our Price: $1,628.84
5	086301201C	GEAR BOX COVER COVER (E-GEAR)	1 req	Avail to order Our Price: $1,396.35
6	WHT000771	SPRING LOCK WASHER WASHER	18 req	Current Stock: 10 Our Price: $2.00
7	008100658	VITE TE M6X1X40 8G UNI 5739 SCREW	6 req	Avail to order Our Price: $2.00
8	086301465	COVER COVER (MANUAL GEARBOX)	1 req	Avail to order Our Price: $106.63
8	086301465A	COVER FOR TOOTH INSPECTION COVER (E-GEAR)	1 req	Avail to order Our Price: $62.29
9	WHT001197A	WASHER WASHER	4 req	Current Stock: 2 Our Price: $2.00
10	008100630	Screw M6x14 Uni 5739/8g/Z SCREW	4 req	Avail to order Our Price: $2.00
11	400127217	SECURING CLIP CLAMP	1 req	Avail to order Our Price: $2.00
12	008100629	SEE PN N01022217 SCREW	12 req	Avail to order Our Price: $2.00
13	086301472	Oil Vapour Breather Pipe BREATHER PIPE	1 req	Avail to order Our Price: $43.42
14	086301827	SHEET COVER	1 req	Avail to order Our Price: $59.85
15	008300667	STUD STUD BOLT	4 req	Avail to order Our Price: $15.87
17	008200616	NUT NUT	4 req	Current Stock: 4 Our Price: $2.00
18	N0147035	SCREW SCREW	2 req	Avail to order Our Price: $2.00
19	WHT001197A	WASHER WASHER	2 req	Current Stock: 2 Our Price: $2.00
20	086927321	Crank/Flywheel/Timing Sensor TIMING SENSOR	2 req	Avail to order 4 Used Available Our Price: $121.99
21	WHT003078	Reference Pin 8h7x16C40 DOWEL	2 req	Avail to order Our Price: $17.16
22	008300826	see PN WHT003166 STUD BOLT	1 req	Avail to order Our Price: $11.56
23	008300807	SEE PN WHT002944 STUD BOLT	1 req	Avail to order Our Price: $16.73
24	008300827	Stud M8x60 Uni 5911 8g Z STUD BOLT	10 req	Avail to order Our Price: $10.98
25	086301141	MAGNETIC PLUG MAGNETIC PLUG	1 req	Avail to order Our Price: $27.56
26	008200806	M8 Uni 5588/8g/Z Nut NUT	8 req	Current Stock: 25 Our Price: $2.00
27	086301173	HOUSING COVER COVER	1 req	Avail to order Our Price: $106.63
28	086301141	MAGNETIC PLUG MAGNETIC PLUG	1 req	Avail to order Our Price: $27.56
29	WHT001197A	WASHER WASHER	4 req	Current Stock: 2 Our Price: $2.00
30	N01021626	HEXAGON HEAD BOLT SCREW	4 req	Current Stock: 8 Our Price: $2.00
31	086301103F	TRANSMISSION CASE 6-GEAR TRANSMISSION CASE (E-GEAR - MANUAL)	1 req	Avail to order Our Price: $4,391.40
32	008300807	SEE PN WHT002944 STUD BOLT	1 req	Avail to order Our Price: $16.73
33	008200821	M8 Self-Locking Nut NUT	1 req	Avail to order Our Price: $2.94
34	WHT003078	Reference Pin 8h7x16C40 DOWEL	2 req	Avail to order Our Price: $17.16
35	WHT003167	TAP END STUD STUD BOLT	8 req	Current Stock: 1 Our Price: $10.55
36	008100826	Screw M8x16 Uni 5739/8g/Z SCREW	1 req	Avail to order Our Price: $2.00
37	N0138302	washer WASHER	1 req	Current Stock: 17 Our Price: $3.23
38	0061009109	GEARBOX WIRE HARNESS WIRING HARNESS (MANUAL GEARBOX)	1 req	Avail to order Our Price: $49.37
39	N0138271	SEALING WASHER GASKET	1 req	Avail to order Our Price: $3.23
40	086927321A	NLA (No Longer Available) E-GEAR SENSOR	1 req	*See Description
41	400326138	BRACKET,PLUG SUPPORT	1 req	Avail to order Our Price: $9.76
42	400971890	BRACKET, EL.CONNECTOR SELESP. BRACKET	1 req	Avail to order Our Price: $15.93
43	1J0937510A	support SUPPORT	1 req	Avail to order Our Price: $3.95
44	410868630	Support BRACKET	2 req	Avail to order Our Price: $57.12
45	008700476	SCREEW SCREW	4 req	Avail to order Our Price: $2.00
46	008410405	Allen Washer 4.3x8 Din 137/A WASHER	4 req	Avail to order Our Price: $2.00
47	086301327	Shield PROTECTION (E-GEAR)	1 req	Avail to order Our Price: $38.90
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
