2021 HURACAN EVO COUPE 2WD - AUSTRALIA

Maintenance Parts:

Tools and Tookits

Tools and Tookits

PN	Item	Diagram
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month		Avail to order Our Price: $317.22

Open All

Select Group and TAV

< Previous Next >

TAV: 115.02.00 - OIL FILTER ELEMENT

2021 Lamborghini HURACAN EVO COUPE 2WD AUSTRALIA OIL FILTER ELEMENT (115.02.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Huracan Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	07L115401F	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT OIL FILTER BRACKET	1 req	*See Description
2	079115433D	OIL FILTER COVER END CAP	1 req	Avail to order Our Price: $99.03
3	079198405E	Oil Filter Gallardo/Huracan LP Series FILTER ELEMENT WITH GASKET	1 req	Avail to order Our Price: $86.68
4	N10538201	O-RING O-RING (19X3,55)	1 req	Avail to order Our Price: $5.96
5	079103121BE	GASKET SEAL	1 req	Avail to order Our Price: $17.22
6	N0138063	O-RING SEAL RING (10X14)	1 req	Avail to order Our Price: $3.23
7	N10622101	HEXALOBULAR SOCKET OVAL HEXAGON SOCKET HEAD BOLT (M6X65)	2 req	Avail to order Our Price: $2.00
8		HYDRAULIC SYSTEM AND FLUID CONTAINER WITH CONNECT. PIECES (SEE ILLUSTRATION : 115.01)	0 req
9	N91124501	12-POINT SOCKET HEXAGON SOCKET HEAD BOLT (M8X40)	2 req	Avail to order Our Price: $6.24
10	079919081	OIL PRESSURE OIL PRESSURE SWITCH (1,2-1,6BAR 1 PIN BLACK M10X1)	1 req	Avail to order Our Price: $26.41
11	059919523F	TEMPERATURE SENDER TEMPERATURE SENSOR	2 req	Avail to order Our Price: $60.06
12		REMOVABLE LID (SEE ILLUSTRATION : 100.01)	0 req
13	WHT002287B	O-RING O-RING (FOR WATER TEMPERATURE SENSOR-5,6X2 BLACK)	1 req	Avail to order Our Price: $4.67
14	WHT002287C	O-RING O-RING (FOR OIL TEMPERATURE SENSOR-5,6X2)	1 req	Current Stock: 4 Our Price: $5.10
15		O-RING (SEE ILLUSTRATION : 121.07-27X3,5)	0 req
16	N0138063	O-RING SEAL RING (10X14)	1 req	Avail to order Our Price: $3.23
17	N91119401	SCREW PLUG SEALING PLUG (M10X1X10)	2 req	Current Stock: 3 Our Price: $4.46
18	07L103707B	COVER COVER	1 req	Avail to order Our Price: $83.10
19	07L115138H	CLUTCH PART COUPLING	1 req	Avail to order Our Price: $184.41
20	07L115467B	TUBE PIPE	1 req	Avail to order Our Price: $26.34
21	WHT008700	O-RING O-RING (27X2,5)	1 req	Avail to order Our Price: $3.01
22	N10704501	HEXALOBULAR SOCKET OVAL HEXAGON SOCKET HEAD BOLT (M6X35)	1 req	Current Stock: 14 Our Price: $2.00
23		OIL PUMP (SEE ILLUSTRATION : 121.07)	0 req
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
