2017 HURACAN LP610-4 SPYDER - AUSTRALIA

Maintenance Parts:

Brakes

PN	Item	Diagram
4S0698451	Rear Brake Pad Set Rear Brake Pad Set 1 SET OF BRAKE PADS FOR DISK BRAKE		Avail to order Our Price: $676.23
4T0698010	Ceramic Brake Pad Kit BIADHESIVEE PADS KIT		Avail to order Our Price: $116.39

Common repairs and upgrades

PN	Item
900000384A	NLA (No Longer Available) Huracan Indoor Cover - Green Stitching	Avail to order Our Price: $398.89
900000384B	HURACAN CAR COVER ORANGE STITCHING INDOOR INT. 62X CAR COVER ORANGE STIT. NOTE: The orange color Lamborghini uses for this cover is very light and is almost yellow. This is normal and their intended color for this cover	Avail to order Our Price: $398.89
900000384C	NLA (No Longer Available) INT. 62X CAR COVER YELLOW STIT.	Avail to order Our Price: $398.89
900000384D	NLA (No Longer Available) INT. 62X CAR COVER WHITE STITCHING INDOOR	Avail to order Our Price: $398.89
900000384E	NLA (No Longer Available) INT. 62X CAR COVER GREY STIT.	Avail to order Our Price: $398.89
900000384F	NLA (No Longer Available) INT. 62X CAR COVER RED STITCHING INDOOR	Avail to order Our Price: $398.89

Drivetrain

PN	Item	Diagram
079198405E	Oil Filter Gallardo/Huracan LP Series Oil Filter Gallardo LP Series		Avail to order Our Price: $86.68

Fuel-Air

PN	Item	Diagram
420133844E	ENGINE AIR FILTER HURACAN AIR FILTER SEE PN 420133844EZ for K&N performance filter		Avail to order Our Price: $142.80

Ignition

PN	Item	Diagram
06H905601C	SPARK PLUG SPARK PLUG		Avail to order Our Price: $35.09
101905631G	Spark Plug - Gallardo/Huracan LP Series Spark Plug Champion		Current Stock: 48 Our Price: $33.87

Misc

PN	Item
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month	Avail to order Our Price: $317.22
4H0805615	TOWING EYE FOR HURACAN TOWING EYE	Avail to order Our Price: $40.41
4T0054690	CRUISE CONTROL KIT, LEATHER 610-4 CRUISE CONTROL KIT, LEATHER	Avail to order Our Price: $1,491.40
4T0054690A	CRUISE CONTROL KIT, ALCANTARA 610-4 CRUISE CONTROL KIT, ALCANTARA	Avail to order Our Price: $1,491.40
4T0853251A	NLA (No Longer Available) Not available in USA market	Avail to order Our Price: $133.67
4T0853252A	NLA (No Longer Available) Not available in USA market	Avail to order Our Price: $133.67
4T0898200	SEE PN 4T0998200 DOOR LIGHT WITH LAMBORGHINI LOGO KIT Replaces - 4E0947415A	Avail to order Our Price: $221.94
4T0898201	SEE PN 4T0998200A PAIR OF DOOR LIGHTS WITH LAMBORGHINI SCRIPT WRITING KIT LIGHTS THE GROUND WITH THE LAMBORGHINI SCRIPT ILLUMINATED FROM THE DOOR Replaces - 4E0947415A	Avail to order Our Price: $221.94
4T0945119B	NLA (No Longer Available) Not available in the USA market.	Avail to order Our Price: $228.02
4T0945120B	NLA (No Longer Available) Not available in USA market.	Avail to order Our Price: $228.02
4T1864435E	HURACAN SET OF 2 FLOOR MATS PICK BORDER COLOR HURACAN SET OF 2 FLOOR MATS PICK BORDER COLOR customizable sticthing or border	Avail to order Our Price: $865.25
N0300574	KEY - Spanner Murcielago-Aventador-Huracan Wrench Spanner Murcielago-Aventador-Huracan	Avail to order Our Price: $9.19

Tools and Tookits

PN	Item	Diagram
470012257	DEMOUNTING HOOK DEMOUNTING HOOK		Current Stock: 1 Our Price: $253.70

Open All

Select Group and TAV

< Previous Next >

TAV: 867.01.00 - TREAD TRIM

2017 Lamborghini HURACAN LP610-4 SPYDER AUSTRALIA TREAD TRIM (867.01.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Huracan Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
0		837-020)	0 req
0		837-020)	0 req
1	4T2867108M	DOOR TRIM PANEL- COVER FOR DOOR TRIM PANEL (WITH ANTI- THEFT SYSTEM - LEATHER INTERIOR - SUPPLY VIN-RIGHT RHD)	1 req	Avail to order Our Price: $4,168.96
1	4T2867108N	DOOR TRIM PANEL- COVER FOR DOOR TRIM PANEL (LEATHER INTERIOR - SUPPLY VIN-RIGHT RHD)	1 req	Avail to order Our Price: $4,168.96
1	4T2867107AA	DOOR TRIM PANEL, WITH ALARM COVER FOR DOOR TRIM PANEL (LOUDSPEAKERS PREMIUM - ANTITHEFT ALARM SYSTEM - LEATHER-LEFT RHD)	1 req	Avail to order Our Price: $4,168.96
1	4T2867107AL	DOOR TRIM PANEL, NO ALARM COVER FOR DOOR TRIM PANEL (Q-CITURA - LOUDSPEAKERS PREMIUM - IMOBILIZATIO N DEVICE-LEFT RHD)	1 req	Avail to order Our Price: $4,168.96
1	4T2867107M	DOOR TRIM PANEL- COVER FOR DOOR TRIM PANEL (WITH ANTI- THEFT SYSTEM - LEATHER INTERIOR - SUPPLY VIN-LEFT RHD)	1 req	Avail to order Our Price: $4,168.96
1	4T2867107N	DOOR TRIM PANEL- COVER FOR DOOR TRIM PANEL (LEATHER INTERIOR - SUPPLY VIN-LEFT RHD)	1 req	Avail to order Our Price: $4,168.96
1	4T2867107P	DOOR TRIM PANEL, COVER FOR DOOR TRIM PANEL (LEATHER - ANTITHEFT ALARM SYSTEM - LOUDSPEAKERS PREMIUM-LEFT RHD)	1 req	Avail to order Our Price: $4,168.96
1	4T2867107Q	DOOR TRIM PANEL, COVER FOR DOOR TRIM PANEL (LOUDSPEAKERS PREMIUM - IMMOBILIZATI ON DEVICE-LEFT RHD)	1 req	Avail to order Our Price: $4,168.96
1	4T2867107T	DOOR TRIM PANEL, WITH ALARM COVER FOR DOOR TRIM PANEL (LOUDSPEAKERS BASIC - ANTITHEFT ALARM SYSTEM - LEATHER-LEFT RHD)	1 req	Avail to order Our Price: $4,168.96
2	4T0867165B	ARM REST-FRONT SOFT CUSHION (LEATHER INTERIOR - SUPPLY VIN-LEFT)	1 req	Avail to order Our Price: $997.40
2	4T0867165C	ARM REST-FRONT SOFT CUSHION (OPT LEATHER AND ALCANTARA INTERIOR - SUPPLY VIN-LEFT)	1 req	Avail to order Our Price: $997.40
2	4T0867166B	ARM REST-FRONT SOFT CUSHION (LEATHER INTERIOR - SUPPLY VIN-RIGHT)	1 req	Avail to order Our Price: $997.40
2	4T0867166C	ARM REST-FRONT SOFT CUSHION (OPT LEATHER AND ALCANTARA INTERIOR - SUPPLY VIN-RIGHT)	1 req	Avail to order Our Price: $997.40
3		BOWDEN CABLE (SEE ILLUSTRATION :- 837-020)	0 req
4		DOOR HANDLE, INNER (SEE ILLUSTRATION :-LEFT 837-020)	0 req
5	7L6868243	MOUNTING CLIP CLIP (LEATHER INTERIOR - SUPPLY VIN)	1 req	Avail to order Our Price: $2.00
6	4H0962109	TIP SWITCH BUTTON FOR DEACTIVATION OF ANTI-THEFT ALARM SYSTEM (ANTI-THEFT SYSTEM OPT)	1 req	Avail to order Our Price: $28.78
7	4T0837307	COVER MANIGLIA PORT ANT COVER (LEFT)	1 req	Avail to order Our Price: $32.80
7	4T0837308	COVER MANIGLIA PORT ANT COVER (RIGHT)	1 req	Avail to order Our Price: $32.80
8		SAFETY SWITCH FOR CENTRAL LOCKING SYSTEM (SEE ILLUSTRATION :-LEFT	0 req
8		SAFETY SWITCH FOR CENTRAL LOCKING SYSTEM (SEE ILLUSTRATION :-RIGHT	0 req
9	4T0867157B	HANDLE RECESS DOOR HANDLE, INNER (LEFT)	1 req	Avail to order Our Price: $739.08
9	4T0867157G	HANDLE RECESS DOOR HANDLE, INNER (BIG / SMALL FORGED PACKAGE-LEFT)	1 req	Avail to order Our Price: $1,328.90
9	4T0867158B	HANDLE RECESS DOOR HANDLE, INNER (RIGHT)	1 req	Avail to order Our Price: $739.08
9	4T0867158G	HANDLE RECESS DOOR HANDLE, INNER (BIG / SMALL FORGED PACKAGE-RIGHT)	1 req	Avail to order Our Price: $1,328.90
10	4T0867171F	HANDLE RECESS, HANDLE SHELL, UPPER PART (FORGED - MATT-LEFT)	1 req	Avail to order Our Price: $1,579.69
10	4T0867172F	HANDLE RECESS, HANDLE SHELL, UPPER PART (FORGED - MATT-RIGHT)	1 req	Avail to order Our Price: $1,579.69
11	4T0868299	LOUDSPEAKER GRILLE LOUDSPEAKER GRILLE (LEFT)	1 req	Avail to order Our Price: $65.27
11	4T0868300	LOUDSPEAKER GRILLE LOUDSPEAKER GRILLE (RIGHT)	1 req	Avail to order Our Price: $65.27
12	4T0868151	LOUDSPEAKER GRILLE LOUDSPEAKER GRILLE (LEFT)	1 req	Avail to order Our Price: $60.55
12	4T0868151A	LOUDSPEAKER GRILLE LOUDSPEAKER GRILLE (LEFT)	1 req	Avail to order Our Price: $80.07
12	4T0868152	LOUDSPEAKER GRILLE LOUDSPEAKER GRILLE (RIGHT)	1 req	Avail to order Our Price: $60.55
12	4T0868152A	LOUDSPEAKER GRILLE LOUDSPEAKER GRILLE (RIGHT)	1 req	Avail to order Our Price: $80.07
13	N90986803	FLANGE TAPPING HEXAGON SOCKET HEAD PANEL BOLT (4,2X13)	10 req	Avail to order Our Price: $2.00
14	N91180901	HEXALOBULAR SOCKET FLAT HEAD MULTI-POINT SOCKET BOLT (M5X20)	8 req	Current Stock: 4 Our Price: $2.00
15	N10602101	SCREW HEXAGON SOCKET FLAT HEAD BOLT (4X10)	4 req	Current Stock: 17 Our Price: $2.00
17	470959565A	EXTERIOR MIRROR SWITCH MIRROR ADJU SWITCH FOR EXTERIOR MIRROR WITH ELECTRIC ADJUSTMENT (BLACK H77)	1 req	Avail to order Our Price: $149.98
18	8T0919173A	OPTICAL FIBRE FIBRE OPTIC CONDUCTOR	1 req	Avail to order Our Price: $7.04
19	4T1867185B	TRIM,MIRROR COVER STRIPS (FRAME-LEFT LHD)	1 req	Avail to order Our Price: $62.51
19	4T1867186B	TRIM,MIRROR COVER STRIPS (FRAME-RIGHT LHD)	1 req	Avail to order Our Price: $62.51
19	4T2867185A	TRIM,MIRROR COVER STRIPS (KIT CARBON FORGED-LEFT RHD)	1 req	Avail to order Our Price: $62.51
19	4T2867185B	TRIM,MIRROR COVER STRIPS (FRAME-LEFT RHD)	1 req	Avail to order Our Price: $62.51
19	4T2867186B	TRIM,MIRROR COVER STRIPS (FRAME-RIGHT RHD)	1 req	Avail to order Our Price: $62.51
20	4T0853740	TYPE SIGN LOGO PSS DX HANGING SIGN (LOGO SENSONUM RIGHT-RIGHT)	1 req	Avail to order Our Price: $178.70
20	4T0853741	TYPE SIGN HANGING SIGN (LOGO SENSONUM LEFT-LEFT)	1 req	Avail to order Our Price: $178.70
21	8N0919238	WARNING LIGHT WARNING LAMP	2 req	Avail to order Our Price: $43.92
22	8Z0919242	SEE PN 8Z0919242A SLEEVE	4 req	Avail to order Our Price: $2.01
23	4E0947415A	ENTRANCE LIGHT FUSSRAUM LIGHT (LOWER)	2 req	Avail to order Our Price: $27.34
24	6Y0947411	DOOR WARNING LIGHT DOOR WARNING LIGHT (RED)	2 req	Avail to order Our Price: $28.49
25	4T2867152A	DOOR PULL DOOR HANDLE, INNER (LEATHER INTERIOR - SUPPLY VIN-RIGHT RHD)	1 req	Avail to order Our Price: $848.15
25	4T2867171	HANDLE RECESS, EXT.LH DOOR HANDLE, INNER (LEATHER INTERIOR - SUPPLY VIN-LEFT RHD)	1 req	Avail to order Our Price: $782.13
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
