2017 HURACAN LP610-4 COUPE - AUSTRALIA

Maintenance Parts:

Brakes

PN	Item	Diagram
4T0698010	Ceramic Brake Pad Kit BIADHESIVEE PADS KIT		Avail to order Our Price: $116.39
4S0698451	Rear Brake Pad Set Rear Brake Pad Set 1 SET OF BRAKE PADS FOR DISK BRAKE		Avail to order Our Price: $676.23

Common repairs and upgrades

PN	Item
900000384D	NLA (No Longer Available) INT. 62X CAR COVER WHITE STITCHING INDOOR	Avail to order Our Price: $398.89
900000384A	NLA (No Longer Available) Huracan Indoor Cover - Green Stitching	Avail to order Our Price: $398.89
900000384B	HURACAN CAR COVER ORANGE STITCHING INDOOR INT. 62X CAR COVER ORANGE STIT. NOTE: The orange color Lamborghini uses for this cover is very light and is almost yellow. This is normal and their intended color for this cover	Avail to order Our Price: $398.89
900000384C	NLA (No Longer Available) INT. 62X CAR COVER YELLOW STIT.	Avail to order Our Price: $398.89
900000384E	NLA (No Longer Available) INT. 62X CAR COVER GREY STIT.	Avail to order Our Price: $398.89
900000384F	NLA (No Longer Available) INT. 62X CAR COVER RED STITCHING INDOOR	Avail to order Our Price: $398.89

Drivetrain

PN	Item	Diagram
079198405E	Oil Filter Gallardo/Huracan LP Series Oil Filter Gallardo LP Series		Avail to order Our Price: $86.68

Fuel-Air

PN	Item	Diagram
420133844E	ENGINE AIR FILTER HURACAN AIR FILTER SEE PN 420133844EZ for K&N performance filter		Avail to order Our Price: $142.80

Ignition

PN	Item	Diagram
06H905601C	SPARK PLUG SPARK PLUG		Avail to order Our Price: $35.09
101905631G	Spark Plug - Gallardo/Huracan LP Series Spark Plug Champion		Current Stock: 48 Our Price: $33.87

Misc

PN	Item
4T1864435E	HURACAN SET OF 2 FLOOR MATS PICK BORDER COLOR HURACAN SET OF 2 FLOOR MATS PICK BORDER COLOR customizable sticthing or border	Avail to order Our Price: $865.25
4H0805615	TOWING EYE FOR HURACAN TOWING EYE	Avail to order Our Price: $40.41
N0300574	KEY - Spanner Murcielago-Aventador-Huracan Wrench Spanner Murcielago-Aventador-Huracan	Avail to order Our Price: $9.19
4T0898201	SEE PN 4T0998200A PAIR OF DOOR LIGHTS WITH LAMBORGHINI SCRIPT WRITING KIT LIGHTS THE GROUND WITH THE LAMBORGHINI SCRIPT ILLUMINATED FROM THE DOOR Replaces - 4E0947415A	Avail to order Our Price: $221.94
4T0898200	SEE PN 4T0998200 DOOR LIGHT WITH LAMBORGHINI LOGO KIT Replaces - 4E0947415A	Avail to order Our Price: $221.94
4T0853251A	NLA (No Longer Available) Not available in USA market	Avail to order Our Price: $133.67
4T0853252A	NLA (No Longer Available) Not available in USA market	Avail to order Our Price: $133.67
4T0945119B	NLA (No Longer Available) Not available in the USA market.	Avail to order Our Price: $228.02
4T0945120B	NLA (No Longer Available) Not available in USA market.	Avail to order Our Price: $228.02
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month	Avail to order Our Price: $317.22
4T0054690	CRUISE CONTROL KIT, LEATHER 610-4 CRUISE CONTROL KIT, LEATHER	Avail to order Our Price: $1,491.40
4T0054690A	CRUISE CONTROL KIT, ALCANTARA 610-4 CRUISE CONTROL KIT, ALCANTARA	Avail to order Our Price: $1,491.40

Tools and Tookits

PN	Item	Diagram
470012257	DEMOUNTING HOOK DEMOUNTING HOOK		Current Stock: 1 Our Price: $253.70

Open All

Select Group and TAV

< Previous Next >

TAV: 853.03.00 - WING

2017 Lamborghini HURACAN LP610-4 COUPE AUSTRALIA WING (853.03.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Huracan Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	4T8809601E	SIDE PANEL SIDE PART (CONTACT YOUR AREA MANAGER-LEFT)	1 req	Avail to order Our Price: $10,260.95
1	4T8809602E	SIDE PANEL SIDE PART (CONTACT YOUR AREA MANAGER-RIGHT)	1 req	Avail to order Our Price: $10,260.95
2	4T8853945	BRACKET MUD WING COMPENSATION PLATE (RIGHT)	1 req	Avail to order Our Price: $14.85
2	4T8853946	BRACKET MUD WING COMPENSATION PLATE (LEFT)	1 req	Avail to order Our Price: $14.85
3	4T8810695	BRACKET ARM (LEFT)	1 req	Avail to order Our Price: $45.28
3	4T8810696	BRACKET ARM (RIGHT)	1 req	Avail to order Our Price: $45.28
3		ARM	1 req
4		ORNAMENTAL GRILLE (SEE ILLUSTRATION :- 853-050)	0 req
5	4T0809609B	REINF.PILLAR B ARM (LEFT)	1 req	Avail to order Our Price: $62.86
5	4T0809610B	REINF.PILLAR B ARM (RIGHT)	1 req	Avail to order Our Price: $62.86
6	4T0809791C	BRACKET BRACKET (LEFT)	1 req	Avail to order Our Price: $22.97
6	4T0809792C	BRACKET BRACKET (RIGHT)	1 req	Avail to order Our Price: $22.46
7		BRACKET FOR CLOSURE PLATE (SEE ILLUSTRATION :- 853-050)	1 req
8	4T0809075B	BRACKET BRACKET (LEFT)	1 req	Avail to order Our Price: $29.64
8	4T0809076B	BRACKET BRACKET (RIGHT)	1 req	Avail to order Our Price: $29.64
9	4T0809465B	ANGLE BRACKET RETAINING PLATE (LEFT)	1 req	Avail to order Our Price: $14.07
9	4T0809466B	ANGLE BRACKET RETAINING PLATE (RIGHT)	1 req	Avail to order Our Price: $14.07
10		REAR PLATE FOR WHEEL HOUSING (SEE ILLUSTRATION :- 825-030)	0 req
11	N10009209	HEXAGON HEAD BOLT M6X20-S1-L HEXAGON HEAD BOLT (COMBI) (M6X20)	8 req	Avail to order Our Price: $2.00
11	N10009507	HEX. BOLT WITH WASHER HEXAGON HEAD BOLT (COMBI) (M6X18)	8 req	Current Stock: 6 Our Price: $2.00
12	N01508210	HEXAGON FLANGE NUT HEXAGON COLLAR NUT (M6)	4 req	Current Stock: 17 Our Price: $1.94
13	N10009209	HEXAGON HEAD BOLT M6X20-S1-L HEXAGON HEAD BOLT (COMBI) (M6X20)	4 req	Avail to order Our Price: $2.00
13	N10009507	HEX. BOLT WITH WASHER HEXAGON HEAD BOLT (COMBI) (M6X18)	8 req	Current Stock: 6 Our Price: $2.00
14	8H0806221	ADJUSTMENT PART COMPENSATING PIECE	10 req	Avail to order Our Price: $8.55
15	N10405702	screw HEXAGON SOCKET HEAD BOLT (M6X45)	10 req	Current Stock: 7 Our Price: $2.87
16	N01166623	WASHER WASHER (6,4X18X1,6)	4 req	Avail to order Our Price: $2.00
17	N90958903	HEXALOBULAR SOCKETM6X16-S11 HEXAGON SOCKET OVAL HEAD BOLT (COMBI) (M6X16)	4 req	Avail to order Our Price: $2.00
18		HEXAGON SOCKET OVAL HEAD BOLT (COMBI) (M6X45)	0 req
19	N90688703	SNAP NUT CLAMP SPEED NUT (M6X24X16)	1 req	Current Stock: 2 Our Price: $2.00
20	N91206801	DUO HEXAGON FLANGEM6X22 HEXAGON FLANGE SCREW	4 req	Avail to order Our Price: $2.00
21	N01508210	HEXAGON FLANGE NUT HEXAGON COLLAR NUT (M6)	2 req	Current Stock: 17 Our Price: $1.94
22	4T8809081C	INSERT PART ARM (LEFT)	1 req	Avail to order Our Price: $175.80
22	4T8809081C	INSERT PART ARM (RIGHT)	1 req	Avail to order Our Price: $175.80
23	4T8809643B	SEALING CHANNEL SEAL (LEFT)	1 req	Avail to order Our Price: $79.08
23	4T8809644B	SEALING CHANNEL SEAL (RIGHT)	1 req	Avail to order Our Price: $79.08
24	N90533003	HEX.HEAD SCREW W. BOLT, HEX. HD. (COMBI.) SELF-LOCKING (M6X20)	2 req	Avail to order Our Price: $3.09
24	N90533005	HEX. BOLT WITH HEXAGON HEAD BOLT (COMBI) (M6X20)	2 req	Current Stock: 8 Our Price: $1.94
25	4T8809821B	EXTENSION ADDED ON RR FENDER BRACKET	1 req	Avail to order Our Price: $53.31
25	4T8809822B	EXTENSION ADDED ON RR FENDER BRACKET	1 req	Avail to order Our Price: $53.31
26	N91140401	HEXALOBULAR SOCKET M6X20-S11 HEXAGON SOCKET OVAL HEAD BOLT (COMBI) (M6X20)	2 req	Current Stock: 4 Our Price: $2.00
27	4T8821129B	Bracket,Wheel BRACKET FOR WHEEL HOUSING (LEFT)	1 req	Avail to order Our Price: $96.16
27	4T8821130B	Bracket,Wheel BRACKET FOR WHEEL HOUSING (RIGHT)	1 req	Avail to order Our Price: $96.16
28	N90821401	nut EXPANDING NUT (4,8X19,6)	8 req	Current Stock: 25 Our Price: $2.00
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
