2017 HURACAN LP580-2 COUPE - USA

Maintenance Parts:

Brakes

PN	Item	Diagram
4T0698010	Ceramic Brake Pad Kit BIADHESIVEE PADS KIT		Avail to order Our Price: $116.39
4S0698451	Rear Brake Pad Set Rear Brake Pad Set 1 SET OF BRAKE PADS FOR DISK BRAKE		Avail to order Our Price: $676.23

Common repairs and upgrades

PN	Item
900000384D	NLA (No Longer Available) INT. 62X CAR COVER WHITE STITCHING INDOOR	Avail to order Our Price: $398.89
900000384A	NLA (No Longer Available) Huracan Indoor Cover - Green Stitching	Avail to order Our Price: $398.89
900000384B	HURACAN CAR COVER ORANGE STITCHING INDOOR INT. 62X CAR COVER ORANGE STIT. NOTE: The orange color Lamborghini uses for this cover is very light and is almost yellow. This is normal and their intended color for this cover	Avail to order Our Price: $398.89
900000384C	NLA (No Longer Available) INT. 62X CAR COVER YELLOW STIT.	Avail to order Our Price: $398.89
900000384E	NLA (No Longer Available) INT. 62X CAR COVER GREY STIT.	Avail to order Our Price: $398.89
900000384F	NLA (No Longer Available) INT. 62X CAR COVER RED STITCHING INDOOR	Avail to order Our Price: $398.89

Drivetrain

PN	Item	Diagram
079198405E	Oil Filter Gallardo/Huracan LP Series Oil Filter Gallardo LP Series		Avail to order Our Price: $86.68

Fuel-Air

PN	Item	Diagram
420133844E	ENGINE AIR FILTER HURACAN AIR FILTER SEE PN 420133844EZ for K&N performance filter		Avail to order Our Price: $142.80

Ignition

PN	Item	Diagram
06H905601C	SPARK PLUG SPARK PLUG		Avail to order Our Price: $35.09

Misc

PN	Item
4T1864435E	HURACAN SET OF 2 FLOOR MATS PICK BORDER COLOR HURACAN SET OF 2 FLOOR MATS PICK BORDER COLOR customizable sticthing or border	Avail to order Our Price: $865.25
4H0805615	TOWING EYE FOR HURACAN TOWING EYE	Avail to order Our Price: $40.41
N0300574	KEY - Spanner Murcielago-Aventador-Huracan Wrench Spanner Murcielago-Aventador-Huracan	Avail to order Our Price: $9.19
4T0072192B	Aero Kit RWD Huracan LP580-2 Coupes and Spyders includes: front splitter, side skirts, rear diffuser, rear wing, and fixing parts. Fender louvers not included	Avail to order Our Price: $13,392.99
4T0898201	SEE PN 4T0998200A PAIR OF DOOR LIGHTS WITH LAMBORGHINI SCRIPT WRITING KIT LIGHTS THE GROUND WITH THE LAMBORGHINI SCRIPT ILLUMINATED FROM THE DOOR Replaces - 4E0947415A	Avail to order Our Price: $221.94
4T0898200	SEE PN 4T0998200 DOOR LIGHT WITH LAMBORGHINI LOGO KIT Replaces - 4E0947415A	Avail to order Our Price: $221.94
4T0853251A	NLA (No Longer Available) Not available in USA market	Avail to order Our Price: $133.67
4T0853252A	NLA (No Longer Available) Not available in USA market	Avail to order Our Price: $133.67
4T0945119B	NLA (No Longer Available) Not available in the USA market.	Avail to order Our Price: $228.02
4T0945120B	NLA (No Longer Available) Not available in USA market.	Avail to order Our Price: $228.02
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month	Avail to order Our Price: $317.22

Tools and Tookits

PN	Item	Diagram
470012257	DEMOUNTING HOOK DEMOUNTING HOOK		Current Stock: 1 Our Price: $253.70

Open All

Select Group and TAV

< Previous Next >

TAV: 121.02.00 - COOLER FOR COOLANT

2017 Lamborghini HURACAN LP580-2 COUPE USA COOLER FOR COOLANT (121.02.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Huracan Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	4S0121252B	RADIATOR LINKS/RECHTS ADDITIONAL COOLER FOR COOLANT (LEFT A. RIGHT)	2 req	Avail to order Our Price: $401.83
2	4S0121203B	SEE PN 4S0121203C RADIATOR FAN WITH FAN RING (400W)	1 req	Avail to order Our Price: $575.48
3	4T0807945	AIR DUCT PART AIR GUIDE (LEFT)	1 req	Avail to order Our Price: $29.31
3	4T0807946	AIR DUCT PART AIR GUIDE (RIGHT)	1 req	Avail to order Our Price: $29.31
4	4T0809963	AIR DUCT ELEMENT AIR GUIDE (LEFT)	1 req	Avail to order Our Price: $46.61
4	4T0809964	AIR DUCT ELEMENT AIR GUIDE (RIGHT)	1 req	Avail to order Our Price: $46.61
5	4T0807167	PROTECTIVE CAP SPORTEL RADIAT ANT AIR GUIDE (LEFT)	1 req	Avail to order Our Price: $13.45
5	4T0807168	PROTECTIVE CAP SPORTEL RADIAT ANT AIR GUIDE (RIGHT)	1 req	Avail to order Our Price: $13.45
6		AIR GUIDE (ONLY FOR 4WD VERSION-LEFT)	0 req
6		AIR GUIDE (ONLY FOR 4WD VERSION-RIGHT)	0 req
7	4T0807157C	AIR DUCT ELEMENT AIR GUIDE (LEFT)	1 req	Avail to order Our Price: $81.35
7	4T0807158C	AIR DUCT ELEMENT AIR GUIDE (RIGHT)	1 req	Avail to order Our Price: $74.34
8	4T0815533	BRACKET BRACKET	2 req	Avail to order Our Price: $45.13
9	4S0121259C	BRACKET HWK LI UNTEN AUSS. BRACKET (LEFT)	1 req	Avail to order Our Price: $129.02
9	4S0121260C	BRACKET HWK RE UNTEN AUSS. BRACKET (RIGHT)	1 req	Avail to order Our Price: $129.02
10	N10347003	HEXALOBULAR SOCKETM6X16-S11-N SOCKET HEAD BOLT WITH INNER HEX ROUND HEAD (M6X16)	8 req	Current Stock: 12 Our Price: $5.46
10	N90918702	SCREW TP4X12-Q HEXAGON SOCKET HEAD PANEL BOLT	12 req	Current Stock: 8 Our Price: $2.00
11	N10664901	12-POINT SOCKET SOCKET HEAD COLLARED BOLT WITH INNER MULTIPOINT HEAD (M8X16)	4 req	Current Stock: 18 Our Price: $3.01
12	N90342503	SNAP NUT CLAMP SPEED NUT (M6X19,5X18)	8 req	Avail to order Our Price: $2.00
13	N91073301	SEE PN N91096601 HEXAGON SOCKET FLAT HEAD BOLT (M6X12)	14 req	Avail to order Our Price: $2.00
14	N10464802	HEXAGONAL SOCKET SCREW OVAL HEXAGON SOCKET HEAD BOLT (4X12)	2 req	Current Stock: 16 Our Price: $2.00
14	N91136801	screw HEXAGON SOCKET HEAD PANEL BOLT (4,2X11)	4 req	Current Stock: 8 Our Price: $2.00
15	701867299E	CLIP CLIP	6 req	Avail to order Our Price: $2.00
15	N0154487	SPEED NUT SPEED NUT (4,2X16,3X11)	1 req	Current Stock: 6 Our Price: $2.00
16	N91057001	SCREW TP5X16-Q OVAL HEAD PANEL SCREW (5X16)	2 req	Current Stock: 8 Our Price: $2.00
17	N91042302	HEXALOBULAR SOCKETM6X16 OVAL HEXAGON SOCKET HEAD BOLT (M6X16)	4 req	Avail to order Our Price: $2.00
18	4T0805289	MOUNTING PLATE BRACKET	2 req	Avail to order Our Price: $37.32
19	420121275A	BEARING KUEHLER RUBBER BUSH	4 req	Avail to order Our Price: $6.39
19	701867299E	CLIP CLIP	6 req	Avail to order Our Price: $2.00
20	4S0121275	BEARING KUEHLER RUBBER BUSH	2 req	Avail to order Our Price: $10.70
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
