2016 HURACAN LP610-4 SPYDER - JAPAN

Maintenance Parts:

Brakes

PN	Item	Diagram
4T0698010	Ceramic Brake Pad Kit BIADHESIVEE PADS KIT		Avail to order Our Price: $116.39
4S0698451	Rear Brake Pad Set Rear Brake Pad Set 1 SET OF BRAKE PADS FOR DISK BRAKE		Avail to order Our Price: $676.23

Common repairs and upgrades

PN	Item
900000384D	NLA (No Longer Available) INT. 62X CAR COVER WHITE STITCHING INDOOR	Avail to order Our Price: $398.89
900000384A	NLA (No Longer Available) Huracan Indoor Cover - Green Stitching	Avail to order Our Price: $398.89
900000384B	HURACAN CAR COVER ORANGE STITCHING INDOOR INT. 62X CAR COVER ORANGE STIT. NOTE: The orange color Lamborghini uses for this cover is very light and is almost yellow. This is normal and their intended color for this cover	Avail to order Our Price: $398.89
900000384C	NLA (No Longer Available) INT. 62X CAR COVER YELLOW STIT.	Avail to order Our Price: $398.89
900000384E	NLA (No Longer Available) INT. 62X CAR COVER GREY STIT.	Avail to order Our Price: $398.89
900000384F	NLA (No Longer Available) INT. 62X CAR COVER RED STITCHING INDOOR	Avail to order Our Price: $398.89

Drivetrain

PN	Item	Diagram
079198405E	Oil Filter Gallardo/Huracan LP Series Oil Filter Gallardo LP Series		Avail to order Our Price: $86.68

Fuel-Air

PN	Item	Diagram
420133844E	ENGINE AIR FILTER HURACAN AIR FILTER SEE PN 420133844EZ for K&N performance filter		Avail to order Our Price: $142.80

Ignition

PN	Item	Diagram
06H905601C	SPARK PLUG SPARK PLUG		Avail to order Our Price: $35.09
101905631G	Spark Plug - Gallardo/Huracan LP Series Spark Plug Champion		Current Stock: 48 Our Price: $33.87

Misc

PN	Item
4T1864435E	HURACAN SET OF 2 FLOOR MATS PICK BORDER COLOR HURACAN SET OF 2 FLOOR MATS PICK BORDER COLOR customizable sticthing or border	Avail to order Our Price: $865.25
4H0805615	TOWING EYE FOR HURACAN TOWING EYE	Avail to order Our Price: $40.41
N0300574	KEY - Spanner Murcielago-Aventador-Huracan Wrench Spanner Murcielago-Aventador-Huracan	Avail to order Our Price: $9.19
4T0898201	SEE PN 4T0998200A PAIR OF DOOR LIGHTS WITH LAMBORGHINI SCRIPT WRITING KIT LIGHTS THE GROUND WITH THE LAMBORGHINI SCRIPT ILLUMINATED FROM THE DOOR Replaces - 4E0947415A	Avail to order Our Price: $221.94
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month	Avail to order Our Price: $317.22
4T0054690	CRUISE CONTROL KIT, LEATHER 610-4 CRUISE CONTROL KIT, LEATHER	Avail to order Our Price: $1,491.40
4T0054690A	CRUISE CONTROL KIT, ALCANTARA 610-4 CRUISE CONTROL KIT, ALCANTARA	Avail to order Our Price: $1,491.40
4T0853251A	NLA (No Longer Available) Not available in USA market	Avail to order Our Price: $133.67
4T0853252A	NLA (No Longer Available) Not available in USA market	Avail to order Our Price: $133.67
4T0898200	SEE PN 4T0998200 DOOR LIGHT WITH LAMBORGHINI LOGO KIT Replaces - 4E0947415A	Avail to order Our Price: $221.94
4T0945119B	NLA (No Longer Available) Not available in the USA market.	Avail to order Our Price: $228.02
4T0945120B	NLA (No Longer Available) Not available in USA market.	Avail to order Our Price: $228.02

Tools and Tookits

PN	Item	Diagram
470012257	DEMOUNTING HOOK DEMOUNTING HOOK		Current Stock: 1 Our Price: $253.70

Open All

Select Group and TAV

< Previous Next >

TAV: 881.02.00 - BACKREST

2016 Lamborghini HURACAN LP610-4 SPYDER JAPAN BACKREST (881.02.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Huracan Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
0		880-010)	0 req
0		ELECTRIC)	0 req
0		ELECTRIC)	0 req
1		SEAT (SEE ILLUSTRATION :- 881-010)	0 req
2	4T0881805	LH SEAT COVER SEAT BACK TRIM (SUPPLY VIN-LEFT FRONT MANUAL)	1 req	Avail to order Our Price: $4,908.04
2	4T0881805A	BACKREST UPHOLSTERED LH - ELECT. SEAT BACK TRIM (WITH HEATER ELEMENT SUPPLY VIN-LEFT FRONT ELECTRIC)	1 req	Avail to order Our Price: $4,908.04
2	4T0881805B	LH SEAT COVER SEAT BACK TRIM (ALCANTARA - SUPPLY VIN-LEFT FRONT MANUAL)	1 req	Avail to order Our Price: $4,908.04
2	4T0881805C	LH SEAT COVER SEAT BACK TRIM (WITH HEATER ELEMENT ALCANTARA - SUPPLY VIN-LEFT FRONT	1 req	Avail to order Our Price: $4,908.04
2	4T0881806	RH SEAT COVER SEAT BACK TRIM (SUPPLY VIN-RIGHT FRONT MANUAL)	1 req	Avail to order Our Price: $4,908.04
2	4T0881806A	KIT - BACKREST UPHOLSTERED RH - ELECT. SEAT BACK TRIM (WITH HEATER ELEMENT SUPPLY VIN-RIGHT FRONT ELECTRIC)	1 req	Avail to order Our Price: $4,908.04
2	4T0881806B	RH SEAT COVER SEAT BACK TRIM (ALCANTARA - SUPPLY VIN-RIGHT FRONT)	1 req	Avail to order Our Price: $4,908.04
2	4T0881806C	RH SEAT COVER SEAT BACK TRIM (WITH HEATER ELEMENT ALCANTARA - SUPPLY VIN-RIGHT FRONT	1 req	Avail to order Our Price: $4,908.04
3	4T0881901	HEADREST (WITH LOGO) HEAD RESTRAINT WITH COVER (WITH LOGO - SUPPLY VIN)	1 req	Avail to order Our Price: $704.64
3	4T0881901A	HEADREST (NO LOGO) HEAD RESTRAINT WITH COVER (SUPPLY VIN)	1 req	Avail to order Our Price: $803.66
4	4T0898039E	BACKREST PANEL LH SEAT BACK TRIM (SUPPLY VIN-LEFT REAR)	1 req	Avail to order Our Price: $2,174.18
4	4T0898040E	BACKREST PANEL RH SEAT BACK TRIM (SUPPLY VIN-RIGHT REAR)	1 req	Avail to order Our Price: $2,245.93
5	4T0881607	BACKREST FRAME TRIM	1 req	Avail to order Our Price: $43.49
6	4T0898039D	LH LEVER TRIM TRIM (LEFT)	1 req	Avail to order Our Price: $17.22
6	4T0898040D	RH LEVER TRIM TRIM (RIGHT)	1 req	Avail to order Our Price: $17.22
7	4T0881605	LH SEAT RELEASE LEVER LEVER FOR FOLDING BACKREST (LEFT)	1 req	Avail to order Our Price: $13.50
7	4T0881606	RH SEAT RELEASE LEVER LEVER FOR FOLDING BACKREST (RIGHT)	1 req	Avail to order Our Price: $13.50
8		ARM (VEDI TAVOLA 880.01 CANNOT BE SOLD SEPARATELY RIF. 9-LEFT)	1 req
8		ARM (VEDI TAVOLA 880.01 CANNOT BE SOLD SEPARATELY RIF. 9-RIGHT)	1 req
9		AIRBAG (CANNOT BE SOLD SEPARATELY - SEE ILLUSTRATION :-RIGHT	1 req
10	4T0898039	LH SEAT CARTER KIT SEAT PAD (LEFT)	1 req	Avail to order Our Price: $36.46
10	4T0898039A	LH SEAT CARTER KIT SEAT PAD (LEFT)	1 req	Avail to order Our Price: $393.22
10	4T0898040	RH SEAT CARTER KIT SEAT PAD (RIGHT)	1 req	Avail to order Our Price: $36.46
10	4T0898040A	RH SEAT CARTER KIT SEAT PAD (RIGHT)	1 req	Avail to order Our Price: $393.22
11	4T0881879A	MOTOR FOR LUMBAR ADJUSTMENT LUMBAR SUPPORT WITH ADJUSTMENT MOTOR	1 req	Avail to order Our Price: $430.53
12	4T0898400	SCREW HEXAGON BOLT	3 req	Avail to order Our Price: $2.00
13	4T0898400D	FASTENER FASTENING CLIP	2 req	Avail to order Our Price: $5.60
14	4T0898400E	FASTENER FASTENING CLIP	2 req	Avail to order Our Price: $2.00
15	4T0898400F	FASTENER FASTENING CLIP	2 req	Avail to order Our Price: $2.00
16	4T0898400G	FASTENER FASTENING CLIP	4 req	Avail to order Our Price: $5.60
17	4T0898400H	SCREW HEXAGON BOLT	4 req	Avail to order Our Price: $7.47
18		HEXAGON BOLT (CANNOT BE SOLD SEPARATELY RIF.4)	4 req
19	4T0898627	SCREW HEXAGON BOLT (M6X10)	2 req	Avail to order Our Price: $3.73
20	4T0898400B	SCREW HEXAGON BOLT	1 req	Avail to order Our Price: $2.00
21	4T0898400A	SCREW HEXAGON BOLT	1 req	Avail to order Our Price: $2.00
22		CLIP NUT (CANNOT BE SOLD SEPARATELY RIF. 4-(M4.2X1.4))	4 req
23		SUPPORT SPRING (CANNOT BE SOLD SEPARATELY RIF. 11)	2 req
24		RETAINING CLIP (CANNOT BE SOLD SEPARATELY RIF. 11)	2 req
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
