2016 HURACAN LP610-4 AVIO EDITION - AUSTRALIA

Maintenance Parts:

Brakes

PN	Item	Diagram
4T0698010	Ceramic Brake Pad Kit BIADHESIVEE PADS KIT		Avail to order Our Price: $116.39
4S0698451	Rear Brake Pad Set Rear Brake Pad Set 1 SET OF BRAKE PADS FOR DISK BRAKE		Avail to order Our Price: $676.23

Common repairs and upgrades

PN	Item
900000384D	NLA (No Longer Available) INT. 62X CAR COVER WHITE STITCHING INDOOR	Avail to order Our Price: $398.89
900000384A	NLA (No Longer Available) Huracan Indoor Cover - Green Stitching	Avail to order Our Price: $398.89
900000384B	HURACAN CAR COVER ORANGE STITCHING INDOOR INT. 62X CAR COVER ORANGE STIT. NOTE: The orange color Lamborghini uses for this cover is very light and is almost yellow. This is normal and their intended color for this cover	Avail to order Our Price: $398.89
900000384C	NLA (No Longer Available) INT. 62X CAR COVER YELLOW STIT.	Avail to order Our Price: $398.89
900000384E	NLA (No Longer Available) INT. 62X CAR COVER GREY STIT.	Avail to order Our Price: $398.89
900000384F	NLA (No Longer Available) INT. 62X CAR COVER RED STITCHING INDOOR	Avail to order Our Price: $398.89

Drivetrain

PN	Item	Diagram
079198405E	Oil Filter Gallardo/Huracan LP Series Oil Filter Gallardo LP Series		Avail to order Our Price: $86.68

Fuel-Air

PN	Item	Diagram
420133844E	ENGINE AIR FILTER HURACAN AIR FILTER SEE PN 420133844EZ for K&N performance filter		Avail to order Our Price: $142.80

Ignition

PN	Item	Diagram
06H905601C	SPARK PLUG SPARK PLUG		Avail to order Our Price: $35.09
101905631G	Spark Plug - Gallardo/Huracan LP Series Spark Plug Champion		Current Stock: 48 Our Price: $33.87

Misc

PN	Item
4T1864435E	HURACAN SET OF 2 FLOOR MATS PICK BORDER COLOR HURACAN SET OF 2 FLOOR MATS PICK BORDER COLOR customizable sticthing or border	Avail to order Our Price: $865.25
4H0805615	TOWING EYE FOR HURACAN TOWING EYE	Avail to order Our Price: $40.41
N0300574	KEY - Spanner Murcielago-Aventador-Huracan Wrench Spanner Murcielago-Aventador-Huracan	Avail to order Our Price: $9.19
4T0898201	SEE PN 4T0998200A PAIR OF DOOR LIGHTS WITH LAMBORGHINI SCRIPT WRITING KIT LIGHTS THE GROUND WITH THE LAMBORGHINI SCRIPT ILLUMINATED FROM THE DOOR Replaces - 4E0947415A	Avail to order Our Price: $221.94
4T0898200	SEE PN 4T0998200 DOOR LIGHT WITH LAMBORGHINI LOGO KIT Replaces - 4E0947415A	Avail to order Our Price: $221.94
4T0853251A	NLA (No Longer Available) Not available in USA market	Avail to order Our Price: $133.67
4T0853252A	NLA (No Longer Available) Not available in USA market	Avail to order Our Price: $133.67
4T0945119B	NLA (No Longer Available) Not available in the USA market.	Avail to order Our Price: $228.02
4T0945120B	NLA (No Longer Available) Not available in USA market.	Avail to order Our Price: $228.02
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month	Avail to order Our Price: $317.22
4T0054690	CRUISE CONTROL KIT, LEATHER 610-4 CRUISE CONTROL KIT, LEATHER	Avail to order Our Price: $1,491.40
4T0054690A	CRUISE CONTROL KIT, ALCANTARA 610-4 CRUISE CONTROL KIT, ALCANTARA	Avail to order Our Price: $1,491.40

Tools and Tookits

PN	Item	Diagram
470012257	DEMOUNTING HOOK DEMOUNTING HOOK		Current Stock: 1 Our Price: $253.70

Open All

Select Group and TAV

< Previous Next >

TAV: 803.01.00 - FRONT FRAME

2016 Lamborghini HURACAN LP610-4 AVIO EDITION AUSTRALIA FRONT FRAME (803.01.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Huracan Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	4T0807109B	BUMPER BAR,FRONT PARAURT.OSSAT.ANT STORAGE FRAME (FRONT)	1 req	Avail to order Our Price: $1,980.44
2	4T0805177A	CLIP ANGLE TELAIO ANTERIORE MOUNTING BAR (LEFT)	1 req	Avail to order Our Price: $72.91
2	4T0805178A	CLIP ANGLE TELAIO ANT. MOUNTING BAR (RIGHT)	1 req	Avail to order Our Price: $72.91
3	4T0805851B	CROSSMEMBER VORN - RESTRICTED CRASH PART CROSS MEMBER (CONTACT YOUR AREA MANAGER-FRONT)	1 req	Avail to order Our Price: $964.39
4		CHASSIS (SEE ILLUSTRATION :-FRONT 803-020)	0 req
5	4T0806191B	RETAINING PART MULTIFUNKTION - RESTRICTED CRASH PART BRACE (CONTACT YOUR AREA MANAGER-LEFT)	1 req	Avail to order Our Price: $502.29
5	4T0806192B	RETAINING PART MULTIFUNKTION BRACE (CONTACT YOUR AREA MANAGER-RIGHT)	1 req	Avail to order Our Price: $502.29
6	4T0806125D	SUPPORT SUPPORT (LEFT)	1 req	Avail to order Our Price: $73.05
6	4T0806126D	SUPPORT SUPPORT (RIGHT)	1 req	Avail to order Our Price: $73.05
7	4T0805327C	BRACKET SCHEINWERFER II ARM (CONTACT YOUR AREA MANAGER-LEFT FRONT)	1 req	Avail to order Our Price: $67.52
7	4T0805328C	BRACKET SCHEINWERFER II ARM (CONTACT YOUR AREA MANAGER-RIGHT FRONT)	1 req	Avail to order Our Price: $67.52
8	4T0805379C	REINFORCEMENT ABST. KOTFLUEGEL ARM (CONTACT YOUR AREA MANAGER-LEFT FRONT)	1 req	Avail to order Our Price: $60.42
8	4T0805380C	REINFORCEMENT ABST. KOTFLUEGEL ARM (CONTACT YOUR AREA MANAGER-RIGHT FRONT)	1 req	Avail to order Our Price: $60.42
9	4T0805667C	BRACKET SCHEINWERFER REINFORCEMENT (LEFT)	1 req	Avail to order Our Price: $427.67
9	4T0805668C	BRACKET SCHEINWERFER REINFORCEMENT (RIGHT)	1 req	Avail to order Our Price: $97.45
10	4T0805255D	REINF.PART REINFORCEMENT (LEFT)	1 req	Avail to order Our Price: $45.85
10	4T0805256D	REINF.PART REINFORCEMENT (RIGHT)	1 req	Avail to order Our Price: $45.85
11	4T0805532B	MOUNTING SCHLOSS ARM (CONTACT YOUR AREA MANAGER)	1 req	Avail to order Our Price: $70.11
12	N91104901	12-POINT SOCKET SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD (KOMBI) (M8X25)	4 req	Avail to order Our Price: $2.00
13	N91042302	HEXALOBULAR SOCKETM6X16 OVAL HEXAGON SOCKET HEAD BOLT (M6X16)	26 req	Avail to order Our Price: $2.00
14	4T0805563B	HOOD LOCK SUPPORT, RESTRICTED CRASH PART LOCK CARRIER (CONTACT YOUR AREA MANAGER)	1 req	Avail to order Our Price: $110.93
15	4T0807551E	DEFORMATION ARM (CONTACT YOUR AREA MANAGER-LEFT)	1 req	Avail to order Our Price: $274.11
16	4T0807552E	DEFORMATION ARM (CONTACT YOUR AREA MANAGER-RIGHT)	1 req	Avail to order Our Price: $323.62
17	4S0806507B	LEFT SUPPORT RETAINING PLATE (LEFT)	1 req	Avail to order Our Price: $17.16
17	4S0806508B	RIGHT SUPPORT RETAINING PLATE (RIGHT)	1 req	Avail to order Our Price: $30.14
18	N90533005	HEX. BOLT WITH HEXAGON HEAD BOLT (COMBI) (M6X20)	8 req	Current Stock: 8 Our Price: $1.94
19	N90692402	BLIND RIVET 4.8X11.3 POP RIVET (4,8X10 N906924)	2 req	Current Stock: 8 Our Price: $2.00
20	N10049308	HEX. BOLT WITH WASHER HEXAGON HEAD BOLT (COMBI) (M8X20)	9 req	Current Stock: 7 Our Price: $2.00
21	N10609201	HEXAGON FLANGE NUT HEXAGON COLLAR NUT (M8)	4 req	Current Stock: 11 Our Price: $2.15
22	4S0805371B	LEFT SUPPORT RETAINING PLATE (LEFT)	1 req	Avail to order Our Price: $27.28
22	4S0805372B	RIGHT SUPPORT RETAINING PLATE (RIGHT)	1 req	Avail to order Our Price: $27.28
23	4T0805259B	BRACKET MUFU UNTEN BRACKET (CONTACT YOUR AREA MANAGER-LEFT LOWER)	1 req	Avail to order Our Price: $9.26
23	4T0805260B	BRACKET MUFU UNTEN BRACKET (CONTACT YOUR AREA MANAGER-RIGHT LOWER)	1 req	Avail to order Our Price: $9.26
24	N91097301	SCREW HEXAGON SOCKET FLAT HEAD BOLT (M6X45)	9 req	Avail to order Our Price: $2.01
25	N10009507	HEX. BOLT WITH WASHER HEXAGON HEAD BOLT (COMBI) (M6X18)	4 req	Current Stock: 6 Our Price: $2.00
26		REINFORCEMENT (ONLY FOR USA/CANADA)	0 req
27		ARM (ONLY FOR 2WD VERSION)	0 req
28		HEXAGON SOCKET OVAL HEAD BOLT (COMBI) (ONLY FOR 2WD VERSION)	0 req
29	4T0806591B	SUPPORT KUEHLER AUFNAHME BRACKET (LEFT)	1 req	Avail to order Our Price: $66.60
29	4T0806592B	SUPPORT KUEHLER AUFNAHME BRACKET (RIGHT)	1 req	Avail to order Our Price: $66.60
30	N01508210	HEXAGON FLANGE NUT HEXAGON COLLAR NUT (M6)	8 req	Current Stock: 17 Our Price: $1.94
31	WHT007052	HEXAGON HEAD BOLT M5GFX18 FLOW DRILL SCREW	5 req	Avail to order Our Price: $2.00
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
