2014 GALLARDO STS II SQUADRA CORSE - USA

Maintenance Parts:

Brakes

PN	Item	Diagram
4S0698151K	SET OF BRAKE PADS FOR CARBOCERAMIC DISC SET OF BRAKE PADS FOR DISC CARBOCERAMIC BRAKES OLD PN 4E0698151G		Current Stock: 1 Our Price: $948.35
420698151F	FRONT BRAKE LININGS SET BREMBO FRONT BRAKE LININGS SET BREMBO		Current Stock: 10 Our Price: $399.00

Common repairs and upgrades

PN	Item	Diagram
900000170	Tutela CS Speed Fluid -Oil Lifting System 1 liter Tutela CS Speed Fluid -Oil Lifting System 1 liter		Avail to order Our Price: $67.89
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 2 Our Price: $22.58

Drivetrain

PN	Item	Diagram
079198405E	Oil Filter Gallardo/Huracan LP Series Oil Filter Gallardo LP Series		Current Stock: 7 Our Price: $89.92
N0138495	O-RING DRAIN PLUG WASHER O-RING		Current Stock: 53 Our Price: $3.51

Fuel-Air

PN	Item
420133844D	Air filter Gallardo LP 560-4 FILTER ELEMENT PERFORMANCE FILTER AVAILABLE, SEE PN: 420133844DZ	Avail to order Our Price: $131.32
4F0898438C	CABIN FILTER ELEMENT SOLD AS PAIR FILTER ELEMENT	Current Stock: 8 Our Price: $120.44
4D0906321C	FUEL FILTER FILTER	Avail to order Our Price: $41.62
4F0201511E	Fuel Filter - Gallardo LP 560-4 FUEL FILTER - Gallardo LP 560-4	Current Stock: 8 Our Price: $85.46
420133844DZ	Pair High Flow K&N Air filter Gallardo LP 550,560-4,570 FILTER ELEMENT	Current Stock: 2 Our Price: $289.31
0R1400314	GALLARDO 2009-2014 SERVICE KIT - Air-Cabin-OIL Filter +Plugs+Belt Kit SERVICE KIT Air-Cabin-OIL Filter +Plugs+Belt Kit	Avail to order Our Price: $671.44

Ignition

PN	Item
000915105DK	SEE PN 000915105DK BATTERY	Avail to order Our Price: $607.04
07K905715G	IGNITION COIL VW OEM BRAND IGNITION COIL VW OEM BRAND	Current Stock: 6 Our Price: $100.95
0R1400355	GALLARDO IGNITION COILS KIT SET OF 10 KIT 10 IGNITION COILS KIT BLACK (FROM THE ENGINE 07L01313 - INCLUDES 10 COIL For Individual Coils See PN 07K905715F OR 07K905715	Current Stock: 5 Our Price: $485.34

Misc

PN	Item
0R1400308	TOOL KIT GALLARDO 2009-2014 TOOL KIT GALLARDO 2009-2014 KIT TROUSSE GALLARDO DA MY'09	Avail to order Our Price: $452.59
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month	Avail to order Our Price: $373.98
0R1400466	VIDEORECORDING AND TELEMETRY VIDEORECORDING AND TELEMETRY	Avail to order Our Price: $8,901.04
0R0000149	CLEANER FLUID 250ml CLEANER FLUID	Current Stock: 1 Our Price: $70.78

Sensors

PN	Item
4E0927803	ABS SENSOR LEFT ABS SENSOR LEFT	Current Stock: 2 Our Price: $48.16
4E0927803F	RH ABS SENSOR SPEED SENSOR	Avail to order Our Price: $145.31
4E0927804F	LH ABS SENSOR SPEED SENSOR	Current Stock: 1 Our Price: $145.31
7PP907275F	WHEEL ELECTRONICS WHEEL ELECTRONICS	Avail to order Our Price: $169.72

Tools and Tookits

PN	Item	Diagram
V03839111CJ	CRANKSHAFT V10 LOCKING PIN T40237 CRANKSHAFT V10 LOCKING PIN T40237		Avail to order Our Price: $31.79
62195015	CLUTCH ALIGNING TOOL CLUTCH ALIGNING TOOL		Current Stock: 2 Our Price: $203.22

Open All

Select Group and TAV

< Previous Next >

TAV: 971.05.00 - ELECTRICAL SYSTEM

2014 Lamborghini GALLARDO STS II SQUADRA CORSE USA ELECTRICAL SYSTEM (971.05.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Gallardo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	7P0915105	BATTERY BATTERY (68AH/380A)	1 req	Avail to order Our Price: $604.06
2	408971225C	HARNESS,BATTERY CABLE	1 req	Avail to order Our Price: $601.47
3		BRACKET (VALID UP TO MODEL YEAR 08)	0 req
4	400937495	FUSE HOLDER ASS. FUSE HOLDER BOX	1 req	Avail to order Our Price: $83.38
5	N90693702	6-POINT FLANGE M5X20.0 SCREW M5X20	2 req	Avail to order Our Price: $2.00
6	400915447	CARRIER PLATE BAR	1 req	Avail to order Our Price: $28.89
7	400971793D	HARNESS,STARTER CABLE	1 req	Avail to order Our Price: $228.52
8	N10347804	HEXALOBULAR SOCKET SCREW M8X20	2 req	Current Stock: 8 Our Price: $2.00
9	400915447B	CARRIER PLATE BRACKET	1 req	Avail to order Our Price: $13.03
10	400971235B	GROUND STRAP, CABLE	1 req	Avail to order Our Price: $35.73
11		COVER (FOR SPYDER MODEL)	0 req
12	400971336	BRACKET BRACKET	3 req	Avail to order Our Price: $11.77
13	N10082911	HEX. BOLT WITH WASHER SCREW M6X16	3 req	Current Stock: 2 Our Price: $2.00
14	420971237A	GROUND STRAP CABLE (CABLE (-) FROM ENGINE TO CHASSIS)	1 req	Avail to order Our Price: $38.86
15	N10049308	HEX. BOLT WITH WASHER SCREW M8X20	2 req	Current Stock: 7 Our Price: $2.00
16	4F0915531	TUBE VENT PIPE	1 req	Avail to order Our Price: $10.35
17	N90847903	HEXAGON FLANGE SCREW M6X15	1 req	Avail to order Our Price: $2.00
18	N01152527	WASHER WASHER	1 req	Current Stock: 15 Our Price: $2.00
19	N10049308	HEX. BOLT WITH WASHER SCREW M8X20	1 req	Current Stock: 7 Our Price: $2.00
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
