2014 GALLARDO STS II SQUADRA CORSE - USA

Maintenance Parts:

Brakes

PN	Item	Diagram
4S0698151K	SET OF BRAKE PADS FOR CARBOCERAMIC DISC SET OF BRAKE PADS FOR DISC CARBOCERAMIC BRAKES OLD PN 4E0698151G		Current Stock: 1 Our Price: $948.35
420698151F	FRONT BRAKE LININGS SET BREMBO FRONT BRAKE LININGS SET BREMBO		Current Stock: 10 Our Price: $399.00

Common repairs and upgrades

PN	Item	Diagram
900000170	Tutela CS Speed Fluid -Oil Lifting System 1 liter Tutela CS Speed Fluid -Oil Lifting System 1 liter		Avail to order Our Price: $67.89
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 2 Our Price: $22.58

Drivetrain

PN	Item	Diagram
079198405E	Oil Filter Gallardo/Huracan LP Series Oil Filter Gallardo LP Series		Current Stock: 7 Our Price: $89.92
N0138495	O-RING DRAIN PLUG WASHER O-RING		Current Stock: 53 Our Price: $3.51

Fuel-Air

PN	Item
420133844D	Air filter Gallardo LP 560-4 FILTER ELEMENT PERFORMANCE FILTER AVAILABLE, SEE PN: 420133844DZ	Avail to order Our Price: $131.32
4F0898438C	CABIN FILTER ELEMENT SOLD AS PAIR FILTER ELEMENT	Current Stock: 8 Our Price: $120.44
4D0906321C	FUEL FILTER FILTER	Avail to order Our Price: $41.62
4F0201511E	Fuel Filter - Gallardo LP 560-4 FUEL FILTER - Gallardo LP 560-4	Current Stock: 8 Our Price: $85.46
420133844DZ	Pair High Flow K&N Air filter Gallardo LP 550,560-4,570 FILTER ELEMENT	Current Stock: 2 Our Price: $289.31
0R1400314	GALLARDO 2009-2014 SERVICE KIT - Air-Cabin-OIL Filter +Plugs+Belt Kit SERVICE KIT Air-Cabin-OIL Filter +Plugs+Belt Kit	Avail to order Our Price: $671.44

Ignition

PN	Item
000915105DK	SEE PN 000915105DK BATTERY	Avail to order Our Price: $607.04
07K905715G	IGNITION COIL VW OEM BRAND IGNITION COIL VW OEM BRAND	Current Stock: 6 Our Price: $100.95
0R1400355	GALLARDO IGNITION COILS KIT SET OF 10 KIT 10 IGNITION COILS KIT BLACK (FROM THE ENGINE 07L01313 - INCLUDES 10 COIL For Individual Coils See PN 07K905715F OR 07K905715	Current Stock: 5 Our Price: $485.34

Misc

PN	Item
0R1400308	TOOL KIT GALLARDO 2009-2014 TOOL KIT GALLARDO 2009-2014 KIT TROUSSE GALLARDO DA MY'09	Avail to order Our Price: $452.59
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month	Avail to order Our Price: $373.98
0R1400466	VIDEORECORDING AND TELEMETRY VIDEORECORDING AND TELEMETRY	Avail to order Our Price: $8,901.04
0R0000149	CLEANER FLUID 250ml CLEANER FLUID	Current Stock: 1 Our Price: $70.78

Sensors

PN	Item
4E0927803	ABS SENSOR LEFT ABS SENSOR LEFT	Current Stock: 2 Our Price: $48.16
4E0927803F	RH ABS SENSOR SPEED SENSOR	Avail to order Our Price: $145.31
4E0927804F	LH ABS SENSOR SPEED SENSOR	Current Stock: 1 Our Price: $145.31
7PP907275F	WHEEL ELECTRONICS WHEEL ELECTRONICS	Avail to order Our Price: $169.72

Tools and Tookits

PN	Item	Diagram
V03839111CJ	CRANKSHAFT V10 LOCKING PIN T40237 CRANKSHAFT V10 LOCKING PIN T40237		Avail to order Our Price: $31.79
62195015	CLUTCH ALIGNING TOOL CLUTCH ALIGNING TOOL		Current Stock: 2 Our Price: $203.22

Open All

Select Group and TAV

< Previous Next >

TAV: 121.07.00 - WATER COOLING SYSTEM

2014 Lamborghini GALLARDO STS II SQUADRA CORSE USA WATER COOLING SYSTEM (121.07.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Gallardo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	07L121530B	HOSE CLAMP CLAMP	8 req	Current Stock: 3 Our Price: $4.02
2	400121057A	COOLANT HOSE FEED PIPE	1 req	Avail to order Our Price: $376.66
3	400121063A	COOLANT HOSE FEED PIPE	1 req	Avail to order Our Price: $176.42
4	400121059A	COOLANT HOSE RETURN HOSE	1 req	Avail to order Our Price: $56.65
5	N90926501	SPRING CLAMP CLAMP	4 req	Avail to order Our Price: $11.02
6	400121053A	COOLANT HOSE PIPE	1 req	Avail to order Our Price: $79.36
7	400121073A	COOLANT HOSE RETURN HOSE	1 req	Avail to order Our Price: $68.12
8	07L121109D	COOLANT HOSE SLEEVE	1 req	Avail to order Our Price: $51.00
9	400121508A	COOLING WATER LINE RETURN HOSE	1 req	Avail to order Our Price: $2,121.49
10	400121510B	COOLING WATER LINE FEED PIPE	1 req	Avail to order Our Price: $1,518.54
11	07L121102B	COOLANT HOSE VENT PIPE	1 req	Avail to order Our Price: $79.36
12	07L121101A	COOLANT HOSE VENT PIPE	1 req	Avail to order Our Price: $79.36
13	400121050A	COOLING WATER PIPE PIPE	1 req	Avail to order Our Price: $894.75
14	400121465	BREATHER TUBE VENT PIPE	1 req	Avail to order Our Price: $1,025.56
15	400121058A	COOLANT HOSE FEED PIPE	1 req	Avail to order Our Price: $90.67
16	07L121337	SLEEVE VENT PIPE	1 req	Avail to order Our Price: $59.18
17	N90986501	SPRING CLAMP CLAMP	2 req	Avail to order Our Price: $2.61
18	410133381B	T union CONNECTOR	1 req	Avail to order Our Price: $35.29
19	N90986501	SPRING CLAMP CLAMP	4 req	Avail to order Our Price: $2.61
20	N01508315	HEXAGON FLANGE NUT NUT M8	2 req	Avail to order Our Price: $2.31
21	400121123	COOLANT HOSE PIPE	1 req	Avail to order Our Price: $79.36
22	420121486	COOLING WATER PIPE PIPE	1 req	Avail to order Our Price: $98.56
23	N91096701	HEXALOBULAR SOCKET SCREW M6X16	2 req	Current Stock: 8 Our Price: $2.00
24		PIPE (SEE TABLE 121.06.00 - SEE REF. 32)	0 req
25	420121109A	COOLANT HOSE PIPE	1 req	Avail to order Our Price: $31.20
26	N90686902	SPRING CLAMP CLAMP	1 req	Avail to order Our Price: $6.33
27	N90686901	CLAMP CLAMP	1 req	Avail to order Our Price: $2.00
28	7L0121093A	BRACKET, NOURICE BRACKET	1 req	Avail to order Our Price: $12.95
29	N10124308	screw SCREW M6X20	2 req	Current Stock: 33 Our Price: $2.01
30	400121261	BRACKET BRACKET	1 req	Avail to order Our Price: $49.21
31	420121262B	BRACKET BRACKET	1 req	Avail to order Our Price: $10.05
32	N10653201	HEXAGON FLANGE SCREW M6X16	4 req	Current Stock: 12 Our Price: $2.17
33	420121403	OVERFLOW RESERVOIR WATER TANK	1 req	Avail to order Our Price: $501.72
34	420121321	COVER PLUG	1 req	Avail to order Our Price: $143.22
35	420121107A	COOLANT HOSE PIPE	1 req	Avail to order Our Price: $22.11
36	N90770201	SPRING CLAMP CLAMP	2 req	Current Stock: 2 Our Price: $4.18
37		WATER RADIATOR (SEE TABLE 121.08.00 - SEE REF. 21)	0 req
38		WATER PUMP (SEE TABLE 260.06.00 - SEE REF. 24)	0 req
39	N90770201	SPRING CLAMP CLAMP	2 req	Current Stock: 2 Our Price: $4.18
40	N10648001	12-POINT SOCKET SCREW M8X25	4 req	Avail to order Our Price: $2.00
41	N90687001	SPRING CLAMP CLAMP	2 req	Avail to order Our Price: $8.12
42	N10653201	HEXAGON FLANGE SCREW M6X16	2 req	Current Stock: 12 Our Price: $2.17
43	N91096701	HEXALOBULAR SOCKET SCREW M6X16	4 req	Current Stock: 8 Our Price: $2.00
44		SCREW	2 req
45	400121239	BRACKET BRACKET	1 req	Avail to order Our Price: $18.92
46	07L121428A	DRAIN PART PIPE	1 req	Avail to order Our Price: $725.03
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
