Maintenance Parts:

Common repairs and upgrades

PN Item Diagram
4T0898201 DOOR LIGHT WITH LAMBORGHINI WRITING KIT Huracan
PAIR OF DOOR LIGHTS WITH LAMBORGHINI SCRIPT WRITING KIT LIGHTS THE GROUND WITH THE LAMBORGHINI SCRIPT ILLUMINATED FROM THE DOOR
Current Stock: 2
Our Price: $192.37
DOOR LIGHT WITH LAMBORGHINI WRITING KIT Huracan

Drivetrain

PN Item Diagram
079198405E Oil Filter Gallardo/Huracan LP Series
Oil Filter Gallardo LP Series
Current Stock: 18
Our Price: $67.74
Oil Filter Gallardo/Huracan LP Series

Fuel-Air

PN Item Diagram
420133844D Air filter Gallardo LP 560-4
FILTER ELEMENT PERFORMANCE FILTER AVAILABLE, SEE PN: 420133844DZ
Current Stock: 1
Our Price: $93.96
Air filter Gallardo LP 560-4
4F0898438C CABIN FILTER ELEMENT SOLD AS PAIR
FILTER ELEMENT
Current Stock: 4
Our Price: $73.57
CABIN FILTER ELEMENT SOLD AS PAIR
0R1400314 GALLARDO 2009-2014 SERVICE KIT - Air-Cabin-OIL Filter +Plugs+Belt Kit
SERVICE KIT Air-Cabin-OIL Filter +Plugs+Belt Kit
Avail to order
Our Price: $413.83
GALLARDO 2009-2014 SERVICE KIT - Air-Cabin-OIL Filter +Plugs+Belt Kit
420133844DZ Pair High Flow K&N Air filter Gallardo LP 550,560-4,570
FILTER ELEMENT
Current Stock: 2
Our Price: $280.95
Pair High Flow K&N Air filter Gallardo LP 550,560-4,570
4D0906321C FUEL FILTER
FILTER
Current Stock: 3
Our Price: $30.45
FUEL FILTER
4F0201511E Fuel Filter - Gallardo LP 560-4
FUEL FILTER - Gallardo LP 560-4
Current Stock: 3
Our Price: $56.08
Fuel Filter - Gallardo LP 560-4

Ignition

PN Item Diagram
000915105DK BATTERY
BATTERY
Avail to order
Our Price: $315.21
BATTERY

Misc

PN Item Diagram
900000381 BATTERY CHARGER ROW BC - EURO
Comes with Eyelet connects, Clamp connectors and Cigar Lighter Adapter.
Current Stock: 6
Our Price: $153.78
BATTERY CHARGER ROW BC - EURO
900000382 BATTERY CHARGER USA BC
BATTERY CHARGER USA BC
Current Stock: 1
Our Price: $153.78
BATTERY CHARGER USA BC
0R1400308 Tool Kit Gallardo 2009-2014
Tool Kit Gallardo 2009-2014 KIT TROUSSE GALLARDO DA MY'09
Avail to order
Our Price: $335.60
Tool Kit Gallardo 2009-2014

Sensors

PN Item Diagram
4E0927804 ABS SENSOR RIGHT
ABS SENSOR RIGHT
Avail to order
Our Price: $33.49
ABS SENSOR RIGHT
4E0927803 ABS SENSOR LEFT
ABS SENSOR LEFT
Current Stock: 5
Our Price: $33.49
ABS SENSOR LEFT
Open All

Select Group and TAV

TAV: 837.08.00 - DOORS

2014 Lamborghini GALLARDO LP 550-2 SPYDER CANADA DOORS (837.08.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Gallardo Parts Manual. Sorry, but there are NO exceptions.

Item # PN Item Qty Req *
1 400837967C RUBBING STRIP
LEFT DOOR CRASH PAD
1 req Avail to order
Our Price: $52.22
RUBBING STRIP
1 400837968C RUBBING STRIP
RIGHT DOOR CRASH PAD
1 req Avail to order
Our Price: $52.22
RUBBING STRIP
2 407867105AB DOOR TRIM PANEL
LH DOOR PANEL ASSEMBLY (PERFORATED LEATHER INTERIOR - SUPPLY VIN)
1 req Avail to order
Our Price: $3,809.29
2 407867105AD DOOR TRIM PANEL
LH DOOR PANEL ASSEMBLY (LEATHER INTERIOR - SUPPLY VIN)
1 req Avail to order
Our Price: $6,682.69
2 407867105AE DOOR TRIM PANEL
LH DOOR PANEL ASSEMBLY (ALCANTARA UPHOLSTERY - SUPPLY VIN)
1 req Avail to order
Our Price: $6,682.69
2 407867105AH DOOR TRIM PANEL
LH DOOR PANEL ASSEMBLY (LEATHER INTERIOR RHOMBUS STYLE - SUPPLY VIN)
1 req Avail to order
Our Price: $6,682.69
2 407867105AM DOOR TRIM PANEL
LH DOOR PANEL ASSEMBLY (LEATHER INTERIOR - ALCANTARA RHOMBUS STYLE - SUPPLY VIN)
1 req Avail to order
Our Price: $6,682.69
2 407867106AB DOOR TRIM PANEL
RH DOOR PANEL ASSEMBLY (LEATHER INTERIOR - SUPPLY VIN)
1 req Avail to order
Our Price: $3,809.29
2 407867106AC DOOR TRIM PANEL
RH DOOR PANEL ASSEMBLY (ALCANTARA UPHOLSTERY - SUPPLY VIN)
1 req Avail to order
Our Price: $6,682.69
2 407867106AF DOOR TRIM PANEL
RH DOOR PANEL ASSEMBLY (PERFORATED LEATHER INTERIOR - SUPPLY VIN)
1 req Avail to order
Our Price: $6,682.69
2 407867106AH DOOR TRIM PANEL
RH DOOR PANEL ASSEMBLY (LEATHER INTERIOR RHOMBUS STYLE - SUPPLY VIN)
1 req Avail to order
Our Price: $6,682.69
2 407867106AM DOOR TRIM PANEL
RH DOOR PANEL ASSEMBLY (LEATHER INTERIOR - ALCANTARA RHOMBUS STYLE - SUPPLY VIN)
1 req Avail to order
Our Price: $6,682.69
3 400867131B DOOR TRAY
POCKET (SUPPLY VIN)
1 req Avail to order
Our Price: $1,725.52
3 400867132B DOOR TRAY
POCKET (SUPPLY VIN)
1 req Avail to order
Our Price: $1,725.52
4 400867171D HANDLE RECESS,
LH HANDLE UPPER PORTION (CARBON INTERIOR)
1 req Current Stock: 5
Our Price: $3,131.85
HANDLE RECESS,
4 400867171H HANDLE RECESS,
LH HANDLE UPPER PORTION (LEATHER UPHOLSTERY ­ SUPPLY VIN)
1 req Avail to order
Our Price: $1,171.30
4 400867171HSK1 HANDLE RECESS,
LH HANDLE UPPER PORTION (BLACK LEATHER UPHOLSTERY)
1 req Avail to order
Our Price: $1,171.30
4 400867171J HANDLE RECESS, LH HANDLE UPPER PORTION (STANDARD)
LH HANDLE UPPER PORTION (STANDARD)
1 req Current Stock: 1
Our Price: $146.96
4 400867172D HANDLE RECESS, carbon
RH HANDLE UPPER PORTION (CARBON INTERIOR)
1 req Current Stock: 3
Our Price: $3,131.85
HANDLE RECESS, carbon
4 400867172H HANDLE RECESS,
RH HANDLE UPPER PORTION (LEATHER UPHOLSTERY ­ SUPPLY VIN)
1 req Avail to order
Our Price: $1,171.30
4 400867172HSK1 HANDLE RECESS,
RH HANDLE UPPER PORTION (BLACK LEATHER UPHOLSTERY)
1 req Avail to order
Our Price: $1,171.30
4 400867172J HANDLE RECESS,
RH HANDLE UPPER PORTION (STANDARD)
1 req Avail to order
Our Price: $146.96
HANDLE RECESS,
5 400962107A ROCKER SWITCH,
DOOR LOCK/UNLOCK SWITCH (DRIVER SIDE)
2 req Current Stock: 1
Our Price: $50.68
ROCKER SWITCH,
5 400962107B ROCKER SWITCH,
PLUG (PASSENGER SIDE)
2 req Current Stock: 4
Our Price: $28.01
ROCKER SWITCH,
6 400867195C HANDLE RECESS,
LH HANDLE CENTER PORTION (CARBON INTERIOR)
1 req Current Stock: 1
Our Price: $2,585.59
HANDLE RECESS,
6 400867195G HANDLE RECESS, LH
LH HANDLE CENTER PORTION (STANDARD)
1 req Current Stock: 5
Our Price: $97.69
HANDLE RECESS, LH
6 400867195J HANDLE RECESS,
LH HANDLE CENTER PORTION (LEATHER UPHOLSTERY ­ SUPPLY VIN)
1 req Avail to order
Our Price: $682.90
6 400867195JSK1 HANDLE RECESS,
LH HANDLE CENTER PORTION (BLACK LEATHER UPHOLSTERY)
1 req Avail to order
Our Price: $682.90
6 400867196C HANDLE RECESS,
RH HANDLE CENTER PORTION (CARBON INTERIOR)
1 req Avail to order
Our Price: $2,585.59
6 400867196G HANDLE RECESS,
RH HANDLE CENTER PORTION (STANDARD)
1 req Current Stock: 2
Our Price: $97.69
HANDLE RECESS,
6 400867196J HANDLE RECESS,
RH HANDLE CENTER PORTION (LEATHER UPHOLSTERY ­ SUPPLY VIN)
1 req Avail to order
Our Price: $682.90
HANDLE RECESS,
6 400867196JSK1 HANDLE RECESS,
RH HANDLE CENTER PORTION (BLACK LEATHER UPHOLSTERY)
1 req Avail to order
Our Price: $682.90
7 400868099C FINGER PLATE blue
INNER HANDLE WITH GRID LH (LEATHER UPHOLSTERY ­ SUPPLY VIN)
1 req Current Stock: 1
Our Price: $3,699.61
FINGER PLATE blue
7 400868099CSK1 HANDLE RECESS MIT GITTER
INNER HANDLE WITH GRID LH (BLACK LEATHER UPHOLSTERY)
1 req Avail to order
Our Price: $3,699.61
7 400868099D FINGER PLATE
INNER HANDLE WITH GRID LH (CARBON INTERIOR)
1 req Current Stock: 3
Our Price: $4,311.75
FINGER PLATE
7 400868099F FINGER PLATE
INNER HANDLE WITH GRID LH (DECORATIVE INSERTS - SUPPLY VIN)
1 req Current Stock: 3
Our Price: $3,699.61
FINGER PLATE
7 400868099J HANDLE RECESS
INNER HANDLE WITH GRID LH
1 req Current Stock: 1
Our Price: $195.22
HANDLE RECESS
7 400868100C FINGER PLATE
INNER HANDLE WITH GRID RH (LEATHER UPHOLSTERY ­ SUPPLY VIN)
1 req Avail to order
Our Price: $3,699.61
7 400868100CSK1 HANDLE RECESS MIT GITTER
INNER HANDLE WITH GRID RH (BLACK LEATHER UPHOLSTERY)
1 req Avail to order
Our Price: $3,699.61
7 400868100D FINGER PLATE
INNER HANDLE WITH GRID RH (CARBON INTERIOR)
1 req Avail to order
Our Price: $4,311.75
7 400868100F FINGER PLATE
INNER HANDLE WITH GRID RH (DECORATIVE INSERTS - SUPPLY VIN)
1 req Current Stock: 1
Our Price: $273.45
FINGER PLATE
7 400868100N HANDLE RECESS
INNER HANDLE WITH GRID RH
1 req Current Stock: 1
Our Price: $195.22
HANDLE RECESS
8 400035243 BRACKET
TWEETER SUPPORT BRACKET
2 req Avail to order
Our Price: $8.56
BRACKET
9 N90526602 SNAP NUT CLAMP
CLIP
2 req Current Stock: 4
Our Price: $2.00
SNAP NUT CLAMP
10 4B0947415A ENTRANCE LIGHT
DOOR COURTESY LIGHT
2 req Current Stock: 2
Our Price: $15.59
ENTRANCE LIGHT
11 400867299 CLIP
FASTENER LYS FUSION, YELLOW
4 req Current Stock: 4
Our Price: $2.00
CLIP
12 6Y0947411 DOOR WARNING LIGHT
DOOR CLEARANCE LIGHT
2 req Current Stock: 5
Our Price: $18.57
DOOR WARNING LIGHT
13 8N0919238 WARNING LIGHT
ANTITHEFT LED
1 req Current Stock: 1
Our Price: $33.72
WARNING LIGHT
14 8Z0919242 BUSHING
ANTITHEFT LED BUSHING
2 req Current Stock: 5
Our Price: $2.00
BUSHING
15 N10613801 CYL.SCREW AM5x55.0
SCREW M 5X55.0
4 req Current Stock: 12
Our Price: $2.00
CYL.SCREW AM5x55.0
16 N10544302 PAN HEAD BOLT
SCREW M 5X25
2 req Avail to order
Our Price: $2.00
PAN HEAD BOLT
17 N10586401 HEXALOBULAR SOCKET
SCREW
4 req Current Stock: 17
Our Price: $2.00
HEXALOBULAR SOCKET
18 WHT002961 WASHER
WASHER
4 req Current Stock: 21
Our Price: $2.00
WASHER
24 N01154012 WASHER
WASHER
6 req Current Stock: 14
Our Price: $2.00
WASHER
25 WHT003111 HEXAGON SOCKET
SCREW M 5X16
2 req Current Stock: 23
Our Price: $2.00
HEXAGON SOCKET
26 WHT000778 SPRING LOCK WASHER
WASHER
2 req Current Stock: 2
Our Price: $2.00
SPRING LOCK WASHER
27 N10621601 HEXALOBULAR SOCKET
SCREW M 4X12
2 req Current Stock: 5
Our Price: $2.00
HEXALOBULAR SOCKET
28 PLUG (VALID FOR A DIFFERENT MARKET) 0 req
29 PULL HANDLE (VALID UP TO MODEL YEAR 11 ) 0 req

* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
