2014 GALLARDO LP 550-2 COUPE - ENGLAND

Maintenance Parts:

Drivetrain

PN	Item	Diagram
079198405E	Oil Filter Gallardo/Huracan LP Series Oil Filter Gallardo LP Series		Avail to order Our Price: $86.68

Fuel-Air

PN	Item
420133844D	Air filter Gallardo LP 560-4 FILTER ELEMENT PERFORMANCE FILTER AVAILABLE, SEE PN: 420133844DZ	Avail to order Our Price: $126.58
4F0898438C	CABIN FILTER ELEMENT SOLD AS PAIR FILTER ELEMENT	Current Stock: 2 Our Price: $115.96
4D0906321C	FUEL FILTER FILTER	Avail to order Our Price: $40.12
4F0201511E	Fuel Filter - Gallardo LP 560-4 FUEL FILTER - Gallardo LP 560-4	Current Stock: 1 Our Price: $80.66
420133844DZ	Pair High Flow K&N Air filter Gallardo LP 550,560-4,570 FILTER ELEMENT	Current Stock: 2 Our Price: $278.88
0R1400314	GALLARDO 2009-2014 SERVICE KIT - Air-Cabin-OIL Filter +Plugs+Belt Kit SERVICE KIT Air-Cabin-OIL Filter +Plugs+Belt Kit	Avail to order Our Price: $627.14

Ignition

PN	Item	Diagram
000915105DK	SEE PN 000915105DK BATTERY		Avail to order Our Price: $408.62

Misc

PN	Item
900000382	NLA use PN 400093050D for USA replacement	Avail to order Our Price: $190.57
900000381	NLA (No Longer Available) Comes with Eyelet connects, Clamp connectors and Cigar Lighter Adapter.	Avail to order Our Price: $190.57
0R1400308	Tool Kit Gallardo 2009-2014 Tool Kit Gallardo 2009-2014 KIT TROUSSE GALLARDO DA MY'09	Avail to order Our Price: $423.36
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month	Avail to order Our Price: $317.22
0R1400466	VIDEORECORDING AND TELEMETRY VIDEORECORDING AND TELEMETRY	Avail to order Our Price: $8,812.27

Sensors

PN	Item	Diagram
4E0927804	SEE PN 4E0927804F ABS SENSOR RIGHT		Avail to order Our Price: $45.07
4E0927803	ABS SENSOR LEFT ABS SENSOR LEFT		Current Stock: 2 Our Price: $45.07

Tools and Tookits

PN	Item	Diagram
V03839111CJ	CRANKSHAFT V10 LOCKING PIN T40237 CRANKSHAFT V10 LOCKING PIN T40237		Avail to order Our Price: $31.79

Open All

Select Group and TAV

< Previous Next >

TAV: 907.03.00 - ELECTRICAL SYSTEM

2014 Lamborghini GALLARDO LP 550-2 COUPE ENGLAND ELECTRICAL SYSTEM (907.03.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Gallardo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	823881763	PROTECTIVE EDGING PROTECTION	1 req	Avail to order Our Price: $3.59
2	8H0959433M	CONTROL UNIT COMFORT CONTROL UNIT (433.92 MHZ REMOTE CONTROL)	1 req	Avail to order Our Price: $589.83
7	8N8951177	SENSOR,ATWS VOLUMETRIC SENSOR (ANTI-THEFT SYSTEM)	1 req	Avail to order Our Price: $248.27
9	400907279A	CU,INTEGRATED ILM CONTROL UNIT	1 req	Avail to order Our Price: $944.30
12	400959433BF	CONTROL UNIT, GFA CONTROL UNIT (SUPPLY VIN TO BE PROGRAMMED)	1 req	Current Stock: 2 Our Price: $7,211.37
13	N90847903	HEXAGON FLANGE SCREW M6X15.0	3 req	Avail to order Our Price: $2.00
14	400972895	SPACER SLEEVE SPACER	3 req	Avail to order Our Price: $31.08
15	400972081B	FASTENING PART PUFFER	3 req	Current Stock: 2 Our Price: $72.33
16	408959655	AIRBAG ECU CONTROL UNIT AIRBAG CONTROL UNIT + SENSOR	1 req	Avail to order Our Price: $866.80
17	N10124306	HEXALOBULAR SOCKET SCREW M6X20	3 req	Current Stock: 4 Our Price: $2.00
18	N90847903	HEXAGON FLANGE SCREW M6X15	2 req	Avail to order Our Price: $2.00
19	400807777	BRACKET, GARAGE OPENING BRACKET	1 req	Avail to order Our Price: $19.88
20	8E0909511	CONTROL UNIT,GARAGE DOOROPENE BOX DOOR CONTROL E.C.U. - EU	1 req	Avail to order Our Price: $1,303.07
22	400907441E	Control unit REAR VIEW CAMERA CONTROL UNIT	1 req	Avail to order Our Price: $1,470.98
23	N10082911	HEX. BOLT WITH WASHER SCREW M6X16	2 req	Current Stock: 2 Our Price: $2.00
27	400907371C	HOLDER,ELECTR. CONTR.UNIT BRACKET	1 req	Avail to order Our Price: $24.91
28	N90847903	HEXAGON FLANGE SCREW M6X15.0	3 req	Avail to order Our Price: $2.00
34	400907285C	HOLDER,ELECTR. BRACKET	1 req	Avail to order Our Price: $191.59
36	400971257	HARNESS,GARAGE WIRING HARNESS BOX DOOR CONTROL E.C.U.	1 req	Avail to order Our Price: $42.34
42	N10049308	HEX. BOLT WITH WASHER SCREW M8X20.00	3 req	Current Stock: 7 Our Price: $2.00
43	N01508213	HEXAGON FLANGE NUT NUT M6	1 req	Current Stock: 4 Our Price: $2.00
44	N10017304	HEXAGON FLANGE NUT NUT M5	8 req	Current Stock: 16 Our Price: $1.87
45	N90993801	PAN HEAD BOLT WITH SCREW M6X16	2 req	Avail to order Our Price: $2.00
46	420907815A	BRACKET BRACKET	1 req	Avail to order Our Price: $22.82
47	4F1906093C	CONTROL UNIT, FUEL PUMP CONTROL UNIT FUEL PUMP	1 req	Avail to order Our Price: $297.79
48	N02300212	HEX.NUT W/ FLANGE NUT M6	2 req	Avail to order Our Price: $2.00
49	400035785A	INTERFACE BOX CONTROL UNIT AMI	1 req	Avail to order Our Price: $690.29
50	400907372B	BRACKET BRACKET - TPMS - AMI	1 req	Avail to order Our Price: $54.04
51	4F0051510K	ADAPTER HARNESS WIRING HARNESS IPOD	1 req	Avail to order Our Price: $93.14
52	4F0051510G	ADAPTER HARNESS WIRING HARNESS USB	1 req	Avail to order Our Price: $64.94
53	7L6971199	PIPE WIRING HARNESS	1 req	Avail to order Our Price: $271.23
54	4F0035909	BLENDE FRAME	1 req	Avail to order Our Price: $9.69
55	N01508213	HEXAGON FLANGE NUT NUT M6	2 req	Current Stock: 4 Our Price: $2.00
56	N10663401	washer WASHER	2 req	Current Stock: 2 Our Price: $2.00
57	WHT003114	PAN HEAD SHEET SCREW	2 req	Current Stock: 20 Our Price: $5.53
58		CONTROL UNIT SDARS (VALID FOR A MARKET USA/CANADA)	0 req
59		BRACKET - SDARS (VALID FOR A MARKET USA/CANADA)	0 req
60		NUT M5 (VALID FOR A MARKET USA/CANADA)	0 req
61		AERIAL SDARS (VALID FOR A MARKET USA/CANADA)	0 req
62		BRACKET - SDARS (VALID FOR A MARKET USA/CANADA)	0 req
63		NUT M5 (VALID FOR A MARKET USA/CANADA)	0 req
64		SCREW (VALID FOR A MARKET USA/CANADA)	0 req
65	410971946	CAN LOOP BACK PLUG CONNECTOR	1 req	Avail to order Our Price: $50.73
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
