2014 GALLARDO LP 550-2 COUPE - ENGLAND

Maintenance Parts:

Drivetrain

PN	Item	Diagram
079198405E	Oil Filter Gallardo/Huracan LP Series Oil Filter Gallardo LP Series		Avail to order Our Price: $86.68

Fuel-Air

PN	Item
420133844D	Air filter Gallardo LP 560-4 FILTER ELEMENT PERFORMANCE FILTER AVAILABLE, SEE PN: 420133844DZ	Avail to order Our Price: $126.58
4F0898438C	CABIN FILTER ELEMENT SOLD AS PAIR FILTER ELEMENT	Current Stock: 2 Our Price: $115.96
4D0906321C	FUEL FILTER FILTER	Avail to order Our Price: $40.12
4F0201511E	Fuel Filter - Gallardo LP 560-4 FUEL FILTER - Gallardo LP 560-4	Current Stock: 1 Our Price: $80.66
420133844DZ	Pair High Flow K&N Air filter Gallardo LP 550,560-4,570 FILTER ELEMENT	Current Stock: 2 Our Price: $278.88
0R1400314	GALLARDO 2009-2014 SERVICE KIT - Air-Cabin-OIL Filter +Plugs+Belt Kit SERVICE KIT Air-Cabin-OIL Filter +Plugs+Belt Kit	Avail to order Our Price: $627.14

Ignition

PN	Item	Diagram
000915105DK	SEE PN 000915105DK BATTERY		Avail to order Our Price: $408.62

Misc

PN	Item
900000382	NLA use PN 400093050D for USA replacement	Avail to order Our Price: $190.57
900000381	NLA (No Longer Available) Comes with Eyelet connects, Clamp connectors and Cigar Lighter Adapter.	Avail to order Our Price: $190.57
0R1400308	Tool Kit Gallardo 2009-2014 Tool Kit Gallardo 2009-2014 KIT TROUSSE GALLARDO DA MY'09	Avail to order Our Price: $423.36
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month	Avail to order Our Price: $317.22
0R1400466	VIDEORECORDING AND TELEMETRY VIDEORECORDING AND TELEMETRY	Avail to order Our Price: $8,812.27

Sensors

PN	Item	Diagram
4E0927804	SEE PN 4E0927804F ABS SENSOR RIGHT		Avail to order Our Price: $45.07
4E0927803	ABS SENSOR LEFT ABS SENSOR LEFT		Current Stock: 2 Our Price: $45.07

Tools and Tookits

PN	Item	Diagram
V03839111CJ	CRANKSHAFT V10 LOCKING PIN T40237 CRANKSHAFT V10 LOCKING PIN T40237		Avail to order Our Price: $31.79

Open All

Select Group and TAV

< Previous Next >

TAV: 121.08.00 - WATER COOLING SYSTEM

2014 Lamborghini GALLARDO LP 550-2 COUPE ENGLAND WATER COOLING SYSTEM (121.08.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Gallardo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	N10005109	HEX. BOLT WITH WASHER € SCREW M8X35	8 req	Current Stock: 4 Our Price: $2.80
2	400121277	SPACER BUSHING	8 req	Avail to order Our Price: $10.48
3	400121268	PUFFER RUBBER BUSHING	8 req	Avail to order Our Price: $11.63
4	WHT001189	RUBBER WASHER MOUNT RUBBER BUSHING 18X30X7	8 req	Avail to order Our Price: $3.95
5	WHT001942	WASHER WASHER	8 req	Current Stock: 13 Our Price: $3.30
6	N10653201	HEXAGON FLANGE SCREW M6X16	8 req	Current Stock: 12 Our Price: $2.01
7	400121241	BRACKET LH BRACKET	1 req	Avail to order Our Price: $87.75
8	400121240	BRACKET RH BRACKET	1 req	Avail to order Our Price: $295.64
9	400121232	BRACKET RH BRACKET	1 req	Avail to order Our Price: $322.18
10	400121233	BRACKET LH BRACKET	1 req	Avail to order Our Price: $102.32
11	400807945	AIR DUCT PART LH CONVEYOR	1 req	Current Stock: 1 Our Price: $149.40
11	400807946	AIR DUCT PART RH CONVEYOR	1 req	Avail to order Our Price: $149.40
12	400809963A	AIR DUCT LH CONVEYOR	1 req	Avail to order Our Price: $454.61
12	400809964A	AIR DUCT RH CONVEYOR	1 req	Current Stock: 1 Our Price: $454.61
13	N90986803	FLANGE TAPPING SCREW ST4.2X13.0	2 req	Avail to order Our Price: $2.00
14	N0454281	SPEED NUT CLIP	2 req	Avail to order Our Price: $2.00
15	N0902324	HEX. BOLT WITH SCREW M6X10	8 req	Current Stock: 18 Our Price: $2.00
16	N10347004	HEXALOBULAR SOCKET SCREW M6X16	8 req	Current Stock: 18 Our Price: $2.00
17	WHT002225A	HEXALOBULAR SOCKET SCREW M8X16	6 req	Avail to order Our Price: $2.00
18	N10653201	HEXAGON FLANGE SCREW M6X16	4 req	Current Stock: 12 Our Price: $2.01
19	N90780903	SOCKET SCREW SCREW M6X16	4 req	Current Stock: 1 Our Price: $2.00
20	400121235	BRACKET LH BRACKET	1 req	Current Stock: 1 Our Price: $227.47
20	400121235A	BRACKET RH BRACKET	1 req	Avail to order Our Price: $205.23
21	400121252D	RADIATOR RH Side RH WATER RADIATOR	1 req	Avail to order Our Price: $2,016.31
21	400121253D	RADIATOR LH WATER RADIATOR	1 req	Avail to order 1 Used Available Our Price: $2,016.31
22	4Z7959455M	ELECTRIC FAN ELECTRIC FAN	2 req	Avail to order Our Price: $1,779.52
23	400122193C	SUPPORT LH SUPPORT	1 req	Avail to order Our Price: $512.34
23	400122194C	Support RH SUPPORT	1 req	Avail to order Our Price: $614.22
24	400807157C	LEFT FORWARD RADIATOR AIR DUCT - GALLARDO 560 LH CONVEYOR	1 req	Avail to order Our Price: $879.20
24	400807158C	RIGHT FORWARD RADIATOR AIR DUCT - GALLARDO 560 RH CONVEYOR	1 req	Avail to order Our Price: $879.20
24	403807157	AIR DUCT LH CONVEYOR	1 req	Avail to order Our Price: $629.02
24	403807158	AIR DUCT VIN REQUIRED RH CONVEYOR	1 req	Avail to order Our Price: $483.20
25	N0902324	HEX. BOLT WITH SCREW M6X10	4 req	Current Stock: 18 Our Price: $2.00
26	400260197C	BRACKET BRACKET	1 req	Avail to order Our Price: $74.06
27	N10569501	HEXALOBULAR SOCKET SCREW M5X16	4 req	Avail to order Our Price: $2.23
28	N10082911	HEX. BOLT WITH WASHER SCREW M6X16	2 req	Current Stock: 2 Our Price: $2.00
29	400807265	GASKET GASKET	2 req	Avail to order Our Price: $10.62
30	417103484	gasket GASKET	4 req	Avail to order Our Price: $8.26
31	420121261A	BRACKET SUPPORT	2 req	Current Stock: 3 Our Price: $3.66
32	1J0971830R	BRACKET,PLUG PLUG SUPPORT	2 req	Avail to order Our Price: $5.03
33	N10347004	HEXALOBULAR SOCKET SCREW M6X16	2 req	Current Stock: 18 Our Price: $2.00
34		RUBBER BUSHING (SEE REF. 2 - 3 - 4 - 5)	0 req
35	WHT002961	WASHER WASHER	8 req	Current Stock: 39 Our Price: $2.00
36	N0115484	WASHER WASHER	8 req	Current Stock: 3 Our Price: $4.46
37	400121129	Spacer BUSHING	8 req	Avail to order Our Price: $15.93
38	07L121585	GROMMET FAIRLEAD	8 req	Avail to order Our Price: $19.02
39	N01508213	HEXAGON FLANGE NUT NUT	8 req	Current Stock: 4 Our Price: $2.00
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
